Convergent Design Odyssey7Q Setup Manual page 11

Configure Odyssey7Q 4K RAW to HD Recording
1
Set Odyssey7Q to FS700 4K RAW to Apple ProRes 422 Mode
MENU » SETUP » MONITOR --> RECORD » FS700 4K RAW-->PRORES HD
Note: When selected for the first time it may take up to 3 minutes to load.
ODYSSEY
2
Make FS700 the Record Trigger
MENU » RECORD » TRIGGER » CAMERA
ODYSSEY
3
Set Timecode Source
MENU » INPUTS » TIMECODE » SOURCE » SDI
ODYSSEY
If recording S-LOG2 use Sony FS700 S-LOG setting.
( Continued on Next Page » )
