Convergent Design Odyssey7Q Setup Manual page 10

Configure FS700 4K RAW to HD Apple ProRes
1
Set up the FS700 for 4K RAW Recording
MENU » REC/OUT SET » REC SET » RAW SET
Select any of the following frames rates that you wish to record on Odyssey7Q:
Once the selection is made you will need to press EXEC on the
camera, to return to live / record.
2
Setup Record Trigger (FS700 Rec Button)
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI COMMAND » ON
3
Set Gamma (required for RAW recording)
PICTURE PROFILE » PP7 » SETTING » GAMMA » S-LOG2
NOTES:
• Picture Profiles SLog2, Rec709, Rec709 800% are all supported in this mode.*
• Custom Profiles are not supported at this time.
• Be sure to set the white balance correctly before shooting. Also note that if you wish
to trigger the Odyssey via the camera's record trigger please set the following on the
FS700
• With 4K to HD what you see on the monitor is what will be recorded.
*Note that adjusting settings within each picture profile will not be reflected in
the recording since the Odyssey7Q can only detect which profile is set, not the
individual attributes.
4
Connect FS700 to Odyssey7Q
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey 7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
( Next Step: Configure Odyssey7Q 4K RAW to HD Recording)
© 2014 Convergent Design, Inc. - All Rights Reserved.
NTSC
4096x2096/24p
4096x2096/30p
PAL
4096x2160/25p
10
