DAG Series FXO Voice Gateway
User Manual V2.0
Dinstar Technologies Co., Ltd.
Address: Floor 6 Guoxing Building Changxing Road Nanshan District Shenzhen China
518052
Telephone: 86-755-26456664
Fax:
86-755-26456659
Email:
sales@dinstar.com, support@dinstar.com
Website:
www.dinstar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAG Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dinstar DAG Series

Summary of Contents for Dinstar DAG Series

  • Page 1 DAG Series FXO Voice Gateway User Manual V2.0 Dinstar Technologies Co., Ltd. Address: Floor 6 Guoxing Building Changxing Road Nanshan District Shenzhen China 518052 Telephone: 86-755-26456664 Fax: 86-755-26456659 Email: sales@dinstar.com, support@dinstar.com Website: www.dinstar.com...
  • Page 2 Revision Records File Name DAG Series FXO Voice Gateway User Manual Document Version Firmware Version 2.11.08.05 Date 2014/03/16 Revised by Technical Support Department...

  • Page 3: Table Of Contents

    Table of Contents Equipment Introduction ..................1 1.1 Overview ......................1 1.2 Equipment appearance ................1 1.3 Power supply ....................2 1.4Network Applications ..................2 1.5 Functions and Features ................3 1.5.1Protocol standard supported ............. 3 1.5.2 Voice and Fax parameters ..............3 1.5.3 Supplementary service ..............
  • Page 4 4.5.6 Forward Rule(Routing mode) ............20 4.5.7 Static Route Table ................21 4.5.8 ARP ....................22 4.6 SIP Server ....................22 4.7 Port Configuration ..................24 4.8 Advanced ...................... 25 4.8.1 FXS/FXO .................... 25 4.8.2 Media Parameter ................29 4.8.3 SIP Parameter .................. 31 4.8.4 Fax Parameter ..................

  • Page 5: Equipment Introduction

    ) series FXS analog hereinafter referred to as the DAG voice gateway.DAG series FXO analog gateway is access gateway based on IP network. It can provide low cost, simple operation VoIP solutions for small enterprise, the family office, remote office and branch enterprise. DAG connects to analog telephone, fax and traditional analog PBX with standard voice interfaces and provided high quality voice service.

  • Page 6: Power Supply

    DAG Series FXO Voice Gateway User Manual 1.3 Power supply DAG1000-4/8O is Cassette equipment with placed on desk, and adopts AC 110-240 V power supply, with the power adapter convert to 12VDC power. Power parameters: Input: 100-240V, 50-60Hz Output: 12VDC Notes: Because power adapter interface is different in different country, please confirm the interface standard with us before shipment.

  • Page 7: Functions And Features

    DAG Series FXO Voice Gateway User Manual 1.5 Functions and Features 1.5.1Protocol standard supported SIP V2.0 (RFC 3261,3262,3264) • SDP (RFC 2327) • REFER (RFC 3515) • RTP/RTCP (RFC 1889,1890) • STUN (RFC 3489) • ARP/RARP (RFC 826/903) • SNTP (RFC 2030) •...

  • Page 8: Basic Operations

    2.1.2 Direct IP Calls DAG series device with FXS port allow two parties directly call through IP address. The user need only a simulation with the FXS port unit equipment linked together and set up calls not registered.

  • Page 9: Call Features

    DAG Series FXO Voice Gateway User Manual Both DAG serial and other VoIP Device are on the same LAN using private IP addresses; Both DAG serial and other VoIP Device can be connected through a router using public or private IP addresses (with necessary port forwarding or DMZ).

  • Page 10: Sending And Receiving Fax

    DAG Series FXO Voice Gateway User Manual *160*1# Open WAN port to access web *166*000000# Factory reset *111# Restart device Call hold *47* IP address call *51# Enable call waiting *50# Disable call waiting *87* Blind transfer *72* Enable Unconditional Call Forward...

  • Page 11: 38 And Pass-Through

    DAG Series FXO Voice Gateway User Manual 2.3.2 T. 38 and Pass-Through T.38 is the preferred method because it is more reliable and works well in most network conditions. If the service provider supports T.38, please use this method by selecting T.38 as fax mode (default).

  • Page 12: Web Configuration

    DAG Series FXO Voice Gateway User Manual Offhook; input “*152*172*16*0*100# ”; onhook Configure subnet mask： • Offhook; input “*153*255*255*0*0# ”; onhook Configure gateway IP address • Offhook; input “*156*172*16*0*1# ”; onhook. 3) Query the IP address of device: Offhook, input“*158#”...

  • Page 13: Login Web

    DAG Series FXO Voice Gateway User Manual Figure 4.1-1Modify IP address Check connection between computer and device, click “Start”-> “run”-> input “cmd”, run ping 192.168.11.10 –t order to check the connectivity between them 4.1.2 Login WEB Open web browser, then input IP address of device, Press“Enter”, it pop up logging on identity authentication interface.

  • Page 14: Navigation Tree

    DAG Series FXO Voice Gateway User Manual Figure 4.1-2 DAG Configure Interface 4.2 Navigation Tree DAG series voice gateway web configuration interface mainly includes navigation tree and the right configuration interface. Choose navigation tree in order to entry into the configuration interface.

  • Page 15: State And Statistics

    DAG Series FXO Voice Gateway User Manual Figure 4.2-1 Navigation Tree When device is in bridge mode, navigation tree won’t display "routing configuration" items and the following "DHCP service", "DMZ host", "forward rules" and "static routing" and "ARP" etc. 4.3 State and Statistics 4.3.1 System Information...

  • Page 16: Registration Information

    DAG Series FXO Voice Gateway User Manual by default. LAN Port Shows LAN IP address of DAG. If network Mode is bridge, LAN port won’t display. DNS Server Display DNS server IP address and default gateway information System Uptime Time elapsed from device power on to now.

  • Page 17: Rtp Session Statistics

    DAG Series FXO Voice Gateway User Manual 4.3.4 RTP Session Statistics Figure 4.3-4 RTP Session Statistics Figure 4.3-4 display real-time RTP conversation flow data information, includes: Port, voice codec, packet period, local port, peer IP, peer port, sent packets, receive packets, lost packets, jitter and duration.
  • Page 18 DAG Series FXO Voice Gateway User Manual Bridge mode Network configuration of bridge mode: Figure 4.5-1 Local network “Link Speed &Duplex”used to select Ethernet port work mode, include 5 kinds of • choice,“Auto Detect”、“10Mbps half-duplex”、“10Mbps full-duplex”,“100Mbpshalf- duplex”,“100Mbps full-duplex”, default is “Auto Detec”.

  • Page 19: Vlan Parameter

    DAG Series FXO Voice Gateway User Manual Route Mode Network configuration of route mode: Notes: The following settings are available on route mode only! 4.5.2 VLAN Parameter Generally, Internet provides only Best Effort Service. Since ethernet is the most spread LAN access technology, importance of providing it a quality of service mechanism ought not to Dinstar Technologies Co., Ltd.
  • Page 20 DAG Series FXO Voice Gateway User Manual be neglected. Ethernet technology also used as WAN technology, not only as LAN technology. Due to rapidly increasing use Internet through Public Switched Telecommunication Network (PSTN), Telephone Companies are forced to implement IP-based networks as their PSTN backbones.
  • Page 21 DAG Series FXO Voice Gateway User Manual Figure 4.5-3 VLAN parameter configuration Table 4.5-1VLAN parameter configuration Fill out an ID to describe a data VLAN group,ID 0 Data 802.1Q VLAN ID(0-4095) used to management VLAN, can’t used to service Data VLAN configure.

  • Page 22: Mac Clone(Routing Mode)

    DAG Series FXO Voice Gateway User Manual Management VLAN Can use dynamic or static DNS server address server 【Note】 ：restart the device to take configuration effect. 4.5.3 MAC Clone(Routing mode) Figure 4.5-4 MAC Clone Interface More client in LAN have already can’t share internet used the traditional “gateway set law”.

  • Page 23: Dmz Host (Routing Mode)

    DAG Series FXO Voice Gateway User Manual Subnet mask, gateway, DNS and other information configured by DHCP protocol. • Configuration interface as figure 4.5-5： Figure 4.5-5 DHCP Configuration Interface 【Note】 ：When configure start and end IP address, subnet mask and gateway, please set the same segment with LAN port.

  • Page 24: Forward Rule(Routing Mode)

    DAG Series FXO Voice Gateway User Manual Figure 4.5-6 DMZ Configuration Interface 【Note】 ：After configuration, restart device configuration validation. 4.5.6 Forward Rule(Routing mode) In some cases, LAN network equipment need to provide some communication in WAN network (such as port for 21 FTP service), This time can be configured forwarding rules for the network equipment.

  • Page 25: Static Route Table

    DAG Series FXO Voice Gateway User Manual Figure 4.5-7 Forward rule configuration interface 4.5.7 Static Route Table Static Route Table is IP communication direction in network, generally do not need to configure static route. When there are many segments in LAN network and need to complete some specific application among these segments, the static route need to be configured.

  • Page 26: Arp

    DAG Series FXO Voice Gateway User Manual 4.5.8 ARP ARP brief introduction: ARP is address resolution protocol. After configuring ARP, users can get physical address through device IP address. Under TCP/IP network environment, each host is assigned a 32-bit IP address. But the message transmission needs to know the purpose the physical address of the party.
  • Page 27 DAG Series FXO Voice Gateway User Manual 3）SIP server based on Linux platform, such as: OpenSER、sipXecx，VoS，Mera etc. 4）SIP server based on windows platform, such as :miniSipServer、Brekeke，VoIPswitch etc. 5）Carrier grade soft-switch platform, such as Cisco, Huawei, Zteetc. SIP server configuration interface as follows: Figure 4.6-1 SIP Server Configuration Interface...

  • Page 28: Port Configuration

    DAG Series FXO Voice Gateway User Manual Heartbeat Heartbeat message detect the connection status between device and SIP server. Secondary Server Backup SIP Server’s IP address or Domain name provided by VoIP service provider. address Secondary SIP Server port Service port, default is 5060...

  • Page 29: Advanced

    DAG Series FXO Voice Gateway User Manual It is use to control the volume of conversation, Adjust "TX gain" will affect Tx Gain the end users voice size, the default value is 0. Its value range from-10 – 10 dB It is use to control the volume of conversation, Adjust "RX gain"...
  • Page 30 DAG Series FXO Voice Gateway User Manual Call Progress Tone: Hear the dial tone when pick up the phone. Choose the national standards from the drop-down box. Default is the United States. Timeout for Dialing: With the help of dialing timeout, you can limit the time while users typing the digits from an extension.
  • Page 31 DAG Series FXO Voice Gateway User Manual FXO. Detect CID：to enable caller ID detection for incoming calls. The gateway has two modes: Before ring and after ring. Before ring: the FXO port will detect CID first, then ringing to the port. It takes about few seconds to detect CID in generally.
  • Page 32 DAG Series FXO Voice Gateway User Manual One Stage Dialing Enable this function, FXO port directly sent the dial number, without call extension. Dial Delay Timer of outgoing call dialing. To call out while match with routing rule successfully. Polarity Reversal Detect To enable or disable Polarity Reversal.

  • Page 33: Media Parameter

    DAG Series FXO Voice Gateway User Manual 4.8.2 Media Parameter Media parameter mainly include: RTP start port, DTMF parameter, PreferedVocoder. Configuration Interface as follow： Figure 4.8-2 Media Parameter Configuration Interface Media parameter description: RTP Start Port Default RTP port 8000 SINGAL、INBAND、RFC2833...
  • Page 34 DAG Series FXO Voice Gateway User Manual RFC2833 Payload Type Payloadvalue, default is 101 DTMF Gain Default is 0 DB DTMF Send Interval DTMF send signal interval, default is 200ms. DAG supports G729、 G711U、 G711A、 G723. while Coder Name it make outgoing call, G.729 will used as figure 4.8.2 displayed...

  • Page 35: Sip Parameter

    DAG Series FXO Voice Gateway User Manual 4.8.3 SIP Parameter Figure 4.8-3 SIP Parameter Configuration Interface SIP parameter description： Voicemail message indicator, it is to be realized in the SUBSCRIBE for MWI way of NOTIFY Voicemail User ID Access code to voicemail box When call come into holding, if select to receive and not send packet, then the local can hear call waiting tone.
  • Page 36 DAG Series FXO Voice Gateway User Manual Enable anonymous call,“anonymous” will include in SIP Anonymous Call message Enable this function, reject all anonymous call. Disable by Reject Anonymous Call default # as ending Dial Key Dial-up, use # as a end descriptor.
  • Page 37 DAG Series FXO Voice Gateway User Manual Figure 4.8-4 Elastix Voicemail Configuration Interface 2）check feature code in Elastix and change it as necessary. Its default feature codes setting as below: Figure 4.8-5 Elastix Voicemail Setting Figure4.8-6 Voice Mail Setting In SIP Parameter 3）...

  • Page 38: Fax Parameter

    DAG Series FXO Voice Gateway User Manual Figure 4.8-7 Voicemail Setting 4）DAG dial *200#, then dial voicemail account and thenask password for Validation. After that the user will hear voice message. 4.8.4 Fax Parameter Fax introduction： DAG fax parameter includes: fax mode, Fax sound detection party, ECM, Rate.

  • Page 39: Digit Map

    DAG Series FXO Voice Gateway User Manual 4.8.5 Digit Map Figure 4.8-9Digit Map Gateway is collect digits dialed by user, if received a number to be immediately report, the efficiency is too low and a large number of take up network resources. A reasonable method is concentration sending a message after receiving all number.
  • Page 40 DAG Series FXO Voice Gateway User Manual 2. Range [] One or more DTMF symbols enclosed between square brackets ("[" and "]"), but only one can be selected. 3. Range () One or more expressions enclosed between round brackets ("(" and ")"), but only one can be selected.

  • Page 41: Feature Codec

    DAG Series FXO Voice Gateway User Manual or first is 13, followed by 9 digits. 3. (13 | 15 | 18)xxxxxxxxx Means that first is "13","15" or "18", followed by 8 digits. 4. [1-357-9]xx Means that first is "1","2","3" or "5" or "7","8","9", followed by 2 digits.
  • Page 42 DAG Series FXO Voice Gateway User Manual Inquire LAN port IP address Dial*158# to obtain device WAN port IP address Inquire WAN port IP address Dial*159# to obtain device WAN port IP address Inquire Phone Number Dial*114# to obtain port account...

  • Page 43: System Parameter

    DAG Series FXO Voice Gateway User Manual Note：* Private services are open by default 4.8.7 System Parameter System parameters include: STUN、NTP、Provision、WEB parameter、Telnet. 1）STUN：STUN（Simple Traversal of UDP over NATs）is a network protocol. It allows users back of NAT find their own public network address, NAT type and internet end port have been bound by NAT for a local port.

  • Page 44: Call & Routing

    DAG Series FXO Voice Gateway User Manual STUN Server Address STUN server IP address STUN Server Port STUN server port Primary NTP server address Primary NTP server IP address, system default is us.pool.ntp.org Primary NTP server port Default is 123 Secondary NTP server address Default is 18.145.0.30...
  • Page 45 DAG Series FXO Voice Gateway User Manual Figure 4.9-1 port group configuration interface Port groupNumber, It uniquely identifies a route,range from Index 0-15 Port group description,its purpose is so you can identify the Description port group with a meaningful name...

  • Page 46: Ip Trunk

    DAG Series FXO Voice Gateway User Manual authentication. Can be identical to or different from SIP User ID. Primary/Secondary Authenticate Password Password of SIP user ID Offhook Auto-Dial Set Auto-dial number to complete one stage dialing. Auto-Dial delay time Delay time of FXO port send auto-dial number.

  • Page 47: Routing Configuration

    DAG Series FXO Voice Gateway User Manual Figure 4.9-2 IP Trunk Configuration Interface Index IP trunk number, it is range from 0 to 63 The description of IP trunk, its purpose is so you can identify the IP trunk with...

  • Page 48: Ip-Tel Routing

    DAG Series FXO Voice Gateway User Manual 4.9.4 IP-Tel Routing Figure 4.9-4 IP-Tel Routing Parameter Index Routing priority: 0-31, 0 is the highest priority. its purpose is so you can identify theIP0->Tel routing with a Description meaningful name Calls from...

  • Page 49: Tel-Ip/Tel Routing

    DAG Series FXO Voice Gateway User Manual 4.9.5 Tel-IP/Tel Routing Figure 4.9-5 Tel-IP/Tel Parameters Configuration Index Routing priority :0-31, 0 is the highest priority. its purpose is so you can identify the routing with a meaningful name Description Calls From...

  • Page 50: Manipulation Configuration

    DAG Series FXO Voice Gateway User Manual 4.10 Manipulation Configuration 4.10.1 IP-Tel Callee Figure 4.10-1 IP-Tel Callee number configuration Description IP-Tel manipulation name Calls From This call come from IP trunk or SIP server. Caller number Prefix, its length normally less or equal to caller number, which helps to matching routing exactly.

  • Page 51: Tel-Ip Caller

    DAG Series FXO Voice Gateway User Manual Suffix to Add Add a number suffix Number of Digits to Leave from Starting from the right to retain the called number digits Right 4.10.2 Tel-IP Caller Figure 4．10-2 Tel-IP Caller Configuration parameters are the same with “IP->Tel Callee”.

  • Page 52: Tel-Ip Callee

    DAG Series FXO Voice Gateway User Manual 4.10.3 Tel-IP Callee Figure 4.10-3 Tel-IPCallee Configuration parameters are the same with “Tel->IP Caller”. 4.11 Maintenance 4.11.1 syslog Parameter Syslog is a protocol used in (TCP/IP) network transmission of record of the standard file information.

  • Page 53: Firmware Upload

    DAG Series FXO Voice Gateway User Manual Syslog level： none Used to misarrange • debug Not including function conditions or the question of other information • notice importance common conditions • warning • Early warning information error Stop error conditions of tools or some part of the realization of the function •...

  • Page 54: Data Backup

    DAG Series FXO Voice Gateway User Manual 4.11.3 Data Backup The process data backup: 1) Click “Data Backup” 2) Click “Backup” to backup data to PC. Figure 4.11-3 Data Backup Interface 4.11.4 Data Restore The processes of data restore: 1) Click “Data Restore”...

  • Page 55: Tracert Test

    DAG Series FXO Voice Gateway User Manual 2) Fill IP address or domain connected, click start. Received a message indicates that network connection normal, or network connected to a fault. Figure 4.11-5 Ping Parameter Interface 4.11.6 Tracert Test Tracert is trace router and used to tracking routing.

  • Page 56: Password Modification

    DAG Series FXO Voice Gateway User Manual of routers and layer 3 switches) that the packets have traversed. The timestamp values returned for each router along the path are the delay (aka latency) values, typically measured in milliseconds for each packet.

  • Page 57: Factory Reset

    DAG Series FXO Voice Gateway User Manual Figure 4.11-7 Password Modification Interface 4.11.8 Factory Reset Click “Apply” to restore the factory settings. Figure 4．11-8 Factory Reset Interface 4.11.9 Device Restart Click the “Save” button in the Configuration page to save the changes to the equipment configuration.

  • Page 58: Glossary

    DAG Series FXO Voice Gateway User Manual 5. Glossary DNS：Domain Name System • SIP：Session Initiation Protocol • TCP：Transmission Control Protocol • UDP：User Datagram Protocol • RTP：Real Time Protocol • PPPOE：point-to-point protocol over Ethernet • VLAN：Virtual Local Area Network • ARP：AddressResolution Protocol •...
