DAG1000-8FXS Voice Gateway
User Manual V2.0
Dinstar Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAG1000-8FXS and is the answer not in the manual?

Questions and answers

Related Manuals for Dinstar DAG1000-8FXS

Summary of Contents for Dinstar DAG1000-8FXS

  • Page 1 DAG1000-8FXS Voice Gateway User Manual V2.0 Dinstar Technologies Co., Ltd.
  • Page 2 Revision Records File Name DAG1000-8 FXS Voice Gateway User Manual Document Version Firmware Version 20.03.03.05 Date 2012/03/16 Revised by Technical Support Department...

  • Page 3: Table Of Contents

    Table of Contents Equipment Introduction ............... 1 1.1 Overview ..................1 1.2 Equipment Structure ..............1 1.3 Installation ..................2 1.4Network Applications ..............3 1.5 Functions and Features ..............3 1.5.1 Protocol standard supported ..........3 1.5.2 Voice and Fax parameters ............. 4 1.5.3 Supplementary service ............
  • Page 4 4.5 Network Configuration ..............15 4.5.1 Local Network ..............15 4.5.2 VLAN Parameter ..............17 4.5.3MAC Clone(Routing mode will be optional) ......19 4.5.4 DHCP Server (Routing mode will be optional) ....... 20 4.5.5 DMZ Host (Routing mode will be optional) ......21 4.5.6 Forward Rule(Routing mode will be optional) .......

  • Page 5: Equipment Introduction

    1. Equipment Introduction 1.1 Overview Thanks for purchasing Dinstar DAG1000 ( hereinafter referred to as the DAG ) series FXS analog voice gateway.DAG1000 series FXS analog gateway is access gateway based on IP network. It can provide low cost, simple operation VoIP solutions for small enterprise, the family office, remote office and branch enterprise.

  • Page 6: Installation

    DAG1000/2000 adopts AC 110-240 V power supply, with the power adapter convert to 12VDC power. Power parameters: Input:100-240V,50-60Hz Output: 12VDC Notes: Because power adapter interface is different in different country, please confirm the interface standard with us before shipment. Dinstar Technologies Co., Ltd.

  • Page 7: Network Applications

    SDP (RFC 2327) • REFER (RFC 3515) • RTP/RTCP (RFC 1889,1890) • STUN (RFC 3489) • ARP/RARP (RFC 826/903) • SNTP (RFC 2030) • DHCP/PPPoE • TFTP/HTTP/HTTPS • DNS/DNS SRV (RFC 1706/RFC 2782) • VLAN 802.1P/802.1Q • Dinstar Technologies Co., Ltd.

  • Page 8: Voice And Fax Parameters

    1）Dial the number directly and wait for 3 seconds (Default “ ”); 2）Dial the number directly and press #. 2.1.2 Direct IP Calls DAG series device with FXS port allow two parties directly call through IP address. The user Dinstar Technologies Co., Ltd.

  • Page 9: Call Hold

    You may drop a call using hook flash. 2.3 Call Waiting Call waiting tone (3 short beeps) indicates an incoming call, if the call waiting feature is enabled. Toggle between incoming call and current call by pressing the “flash” button. First Dinstar Technologies Co., Ltd.

  • Page 10: Call Transfer

    1）Caller A presses FLASH on the analog phone for dial tone; 2）Dial Caller C’s number followed by # (or wait for 3 seconds); 3）If Caller C answers the call, Caller A and Caller C are in conversation. Then A can hang up to complete transfer; Dinstar Technologies Co., Ltd.

  • Page 11: 3-Way Conference

    2.5 Call Features DAG (FXS) support all traditional and senior phone function. Table 2.5-1 Feature Codec Feature Codec Operation Instructions *158# View the LAN port IP address *159# View the WAN port IP address *114# Inquire port account Dinstar Technologies Co., Ltd.
  • Page 12 Enable No Answer Call Forward *93# Disable No Answer Call Forward *78# Enable DND *79# Disable DND *200# Access Voice mail flash/hook will switch a Switch between incoming calls, If not in session, Flash/Hook new channel for new call. Dinstar Technologies Co., Ltd.

  • Page 13: Sending And Receiving Fax

    *158# to inquire LAN port IP address and dialing *159# to inquire WAN port IP address. 3.2 Factory Reset After picking up, dial *166*000000#, then onhook and restart after “Setting successful”. 3.3 Configure LAN Port’s IP Address Before configuration, please ensure: （ 1） The device is power on; （2） deviceis connectingto Dinstar Technologies Co., Ltd.

  • Page 14: Web Configuration

    IP address. 4.1.1 Login Device LAN port default IP address is 192.168.11.1, WAN port default obtain IP address by DHCP. Advice to modify the IP address of the local computer equipment and ensure that Dinstar Technologies Co., Ltd.

  • Page 15: Login Web

    192.168.11.10 –t order to check the connectivity between them . 4.1.2 Login WEB Open web browser, then input IP address of device, Press“Enter”, it pop up logging on identity authentication interface. Figure 4.1-1 DAG FXS Login Interface Dinstar Technologies Co., Ltd.

  • Page 16: Navigation Tree

    Choose navigation tree in order to entry into the configuration interface. Figure 4.2-1 Navigation Tree When device is in bridge mode, navigation tree won’t display "routing configuration" items and the following "DHCP service", "DMZ host", "forward rules" and "static routing" and "ARP" etc. Dinstar Technologies Co., Ltd.

  • Page 17: State And Statistics

    Display DNS server IP address and default gateway information System Uptime Time elapsed from device power on to now. Network Traffic Total bytes of message received and sent by network port. Statics Version Includes: product mode, software version, hardware version and built time etc. Dinstar Technologies Co., Ltd.

  • Page 18: Registration Information

    4.3.4 RTP Session Statistics Figure 4.3-4 RTP Session Statistics Figure 4.3-4 display real-time RTP conversation flow data information, includes: Port, voice codec, packet period, local port, peer IP, peer port, sent packets, receive packets, lost packets, jitter and duration. Dinstar Technologies Co., Ltd.

  • Page 19: Quick Setup Wizard

    When it set to bridge mode, only need to configure WAN port IP address and DNS.If set to route mode, default LAN port IP will display and it can be change by users.Network configure interface as below: Dinstar Technologies Co., Ltd.
  • Page 20 DAG1000-8 FXS Voice Gateway User Manual Figure 4.5-1Route Mode Figure 4.5-2 Bridge Mode “Link Speed &Duplex”used to select Ethernet port work mode, include 5 kinds of • choice,“Auto Detect” “10Mbps half-duplex” “10Mbps 、 、 Dinstar Technologies Co., Ltd.

  • Page 21: Vlan Parameter

    The IEEE 802.1Q standard defines architecture for Virtual Bridged LANs, the services provided in Virtual Bridged LANs and the protocols and algorithms involved in the provision of those services. No Quality of Service mechanisms are defined in this standard, but an important Dinstar Technologies Co., Ltd.
  • Page 22 Network Control priority to all packets and the network would be easily congested. There are three VLAN: data VLAN, voice LAN and management VLAN. VLAN configuration interface as following figure 4-4-3: Figure 4.5-3 VLAN parameter configuration Table 4.5-1VLAN parameter configuration Dinstar Technologies Co., Ltd.

  • Page 23: 3Mac Clone(Routing Mode Will Be Optional)

    Because IP address binding in only a legitimate MAC address by ISP. If the ISP’s switch discover illegal MAC address, it will refuse service. The best way is MAC clone for MAC binding. Most ADSL MODEM, broadband router, Dinstar Technologies Co., Ltd.

  • Page 24: Dhcp Server (Routing Mode Will Be Optional)

    Figure 4.5-5 DHCP Configuration Interface 【Note】 ：When configure start and end IP address, subnet mask and gateway, please set the same segment with LAN port. Otherwise, device will not work normally. After configuration, restart device configuration validation. Dinstar Technologies Co., Ltd.

  • Page 25: Dmz Host (Routing Mode Will Be Optional)

    LAN network provide services to the mouth of the network equipment IP address, the protocol is TCP or UDP. The different between forward rule and DMZ host is that DMZ Host offers continuous multiple Port (0-1024) and all the foreign communication agreement; while the forward rule offers a Dinstar Technologies Co., Ltd.

  • Page 26: Static Route Table

    When there are many segments in LAN network and need to complete some specific application among these segments, the static route need to be configured. Static Route configuration interface as follows: Figure 4.5-8 Static route configuration interface Dinstar Technologies Co., Ltd.

  • Page 27: Arp

    Presence, Find-me, Music On Hold. 3）SIP server based on Linux platform, such as: OpenSER、sipXecx，VoS，Mera etc. 4） SIP server based on windows platform, such as :miniSipServer、 Brekeke， VoIPswitch etc. Dinstar Technologies Co., Ltd.
  • Page 28 1800s. Secondary SIP heartbeat Heartbeat message detect the connection status between device and SIP server. Use Random Port Random SIP service ports for DAG Set Local SIP port Default SIP service port is 5060. Dinstar Technologies Co., Ltd.

  • Page 29: Port Configuration

    Primary /Secondary SIP Primary /Secondary SIP account description,Its purpose is so you can identify Display Name the SIP account with a meaningful name Primary /Secondary User account information, provided by VoIP service provider (ITSP). Usually in Dinstar Technologies Co., Ltd.

  • Page 30: Advanced

    Play Call Waiting Tone Enable call waiting tone, caller will hear special tone. 4.8 Advanced 4.8.1 FXS parameters FXS characteristic parameters include: Call progress Tone, Timeout for Dialing, Send Polarity Reversal etc. Configuration interface as follow: Dinstar Technologies Co., Ltd.
  • Page 31 When need to transfer the call to other extension, then telephone hook flash to transfer the call. CID Type There are DTMF and FSK, General for the default. Message Type The call display formats SDMF and MDMF, General for the default Dinstar Technologies Co., Ltd.

  • Page 32: Media Parameter

    Payloadvalue, default is 101 DTMF Gain Default is 0 DB DTMF Send Interval DTMF send signal interval, default is 200ms. DAG supports G729、G711U、G711A、G723. while Coder Name it make outgoing call, G.729 will used as figure 4.8.2 displayed Dinstar Technologies Co., Ltd.

  • Page 33: Sip Parameter

    Slience Suppression and save about VoIP bandwidth.In the low bandwidth environment, can reduce the network congestion, greatly improving VoIP call effect. 4.8.3 SIP Parameter Figure 4.8-3 SIP Parameter Configuration Interface Dinstar Technologies Co., Ltd.
  • Page 34 T1 timer of SIP protocol, default is 500ms T2 timer of SIP protocol, default is 400ms T4 timer of SIP protocol, default is 500ms Max Timeout The max timeout of sending or receiving, default is 32s Heartbeat Interval Default is 10s. Dinstar Technologies Co., Ltd.
  • Page 35 Figure 4.8-5 Elastix Voicemail Setting Figure4.8-6 Voice Mail Setting In SIP Parameter 3） Enable voice mail in DAG andElastix will ask you to leave a message after ringing 15 seconds, thenElastixwill record and display your message. Dinstar Technologies Co., Ltd.

  • Page 36: Fax Parameter

    Figure 4.8-8 Fax Parameter Configure Interface Fax parameter description: Mode Fax mode support T.38, T.30(Pass-through),Modem, Adaptive. Tone Detection by Fax sound detection mode: Caller, Callee, Automatic. Fax error correction information Rate The rate of sending and receiving. Dinstar Technologies Co., Ltd.

  • Page 37: Digit Map

    Digit Map Syntax: 1. Supported objects Digit: A digit from "0" to "9". Timer: The symbol "T" matching a timer expiry. DTMF: A digit, a timer, or one of the symbols "A", "B", "C", "D", "#", or "*". Dinstar Technologies Co., Ltd.
  • Page 38 "411". We have a partial match with "xxxxxxx", but a complete match with "x11", and hence we send "411" to the Call Agent. 2. [2-8] xxxxxx | 13xxxxxxxxx Means that first is "2","3","4","5","6","7" or "8", followed by 6 digits; Dinstar Technologies Co., Ltd.

  • Page 39: Feature Codec

    4. [1-357-9]xx Means that first is "1","2","3" or "5" or "7","8","9", followed by 2 digits. 4.8.6 Feature Codec Feature codec includes device function and call function. Feature codec as follow: Figure 4.8-10 Feature Code Configuration Interface Dinstar Technologies Co., Ltd.
  • Page 40 *92*+ forward no reply number# Call Forward No Reply Deactivate *93#, close this function Do Not Disturb Activate *78#, enable DND function Do Not Disturb Deactivate *79#, close DND function Dial Voicemail *200#, visit voice mail box Dinstar Technologies Co., Ltd.

  • Page 41: System Parameter

    2）NTP：Network Time Protocol（NTP）is a computer time synchronization protocol. 3）Provision：Auto Provisioning can be used to provide general and specific configuration parameters ("Settings") to the DAGsand to manage firmware actualization. System parameter configuration interface as follow: Figure 4.8-11System Configuration Interface Dinstar Technologies Co., Ltd.

  • Page 42: Call & Routing

    Access Web by WAN Enable or disable accessing web by WAN Telnet Port Telnet service port, default is 23. 4.9 Call & Routing 4.9.1 Port Group Port group parameter include: Index, description etc. Port group configure interface as follow: Dinstar Technologies Co., Ltd.
  • Page 43  It specifies the policy for selecting port in a port group  Ascending: the system always selects a port from the Port Select minimum number. The preferential selection of the port can be realized through this mode Dinstar Technologies Co., Ltd.

  • Page 44: 2Ip Trunk

    DAGs and also receiving incoming calls from other peer to peer gateway. IP trunk is help to DAGs establish peer-to-peer call between DAGs and other VoIP phones. IP trunk will be used in routing configuration. Figure 4.9-2 IP Trunk Configuration Interface Dinstar Technologies Co., Ltd.

  • Page 45: Routing Configuration

    Default is disable, if enable, DAG will send “OPTION” to peer device 4.9.3 Routing Configuration Figure 4.9-3 Routing Parameter Configuration Interface This option determines the following routing of call take effect before or after manipulation. 4.9.4IP-Tel Routing Figure 4.9-4 IP-Tel Routing Parameter Dinstar Technologies Co., Ltd.

  • Page 46: Tel-Ip/Tel Routing

    Figure 4.9-5 Tel-IP/Tel Parameters Configuration Index Routing priority :0-31, 0 is the highest priority. its purpose is so you can identify the routing with a meaningful name Description Calls From Tel-IP call select port or port group Dinstar Technologies Co., Ltd.

  • Page 47: Manipulation Configuration

    Caller number Prefix, its length normally less or equal to caller number, which helps to matching routing exactly. if caller number Caller Prefix is 2001, the caller prefix can be 200 or 2. “any” means match any caller number like “bob1”,”29801” Dinstar Technologies Co., Ltd.

  • Page 48: Tel-Ip Caller

    Prefix to Add Add a number prefix Suffix to Add Add a number suffix Number of Digits to Leave from Starting from the right to retain the called number digits Right 4.10.2 Tel-IP Caller Figure 4．10-2 Tel-IP Caller Dinstar Technologies Co., Ltd.

  • Page 49: Tel-Ip Callee

    4.11 Maintenance 4.11.1 syslog Parameter Syslogis a protocol used in (TCP/IP) network transmission of record of the standard file information. Syslog agreement belongs to a kind of master slave agreement: Syslog sender will sent a small Dinstar Technologies Co., Ltd.

  • Page 50: Firmware Upload

    2) Browse files and choose the loading program (Name the file extension. ldf) 3) Click “Upload”, the upload process will last about 60s and device can automatically restart after uploading.（The firmware update process don't shut off the power） Figure 4.11-2 Firmware upload Configuration Dinstar Technologies Co., Ltd.

  • Page 51: Data Backup

    Send test data packets to IP, check each other whether have response and statistical response time. It is ping. Used to test internet and analyzed network fault. Application format：Ping IP address. It is used to check the network connectivity or network connection speed command. Pinginstructions: 1) Click “ping test” Dinstar Technologies Co., Ltd.

  • Page 52: Tracert Test

    The next set have a hop limit value of 2, so that the second router will send the error reply. This continues until the destination host receives the packets and returns an ICMP Echo Reply message. Trace route uses the returned ICMP messages to produce a list of hops (which usually consists Dinstar Technologies Co., Ltd.

  • Page 53: Password Modification

    2) Fill IP address or domain connected, click start. Figure 4.11-6 Tracert Test Interface 4.11.7 Password Modification Includes WEB username and password, Telenet username and password modify. Note：Default web and telnet username and password is: admin, admin. Dinstar Technologies Co., Ltd.

  • Page 54: Factory Reset

    Click the “Save” button in the Configuration page to save the changes to the equipmentconfiguration. The following screen confirms that the changes are saved. If the changes need restart, reboot or power cycle the equipment to make the changes take effect. Figure 4.11-9 Device Restart Dinstar Technologies Co., Ltd.

  • Page 55: Glossary

    VLAN：Virtual Local Area Network • ARP：AddressResolution Protocol • CID：Caller Identity • DND：Do NOT Disturb • DTMF：Dual Tone Multi Frequency • NTP：Network Time Protocol • DMZ：Demilitarized Zone • STUN：Simple Traversal of UDP over NAT • PSTN：Public Switched Telephone Network • Dinstar Technologies Co., Ltd.
