Quick Installation Guide
Thanks for Choosing Dinstar's VoIP Gateway!
Please read this guide carefully before installing the gateway. If you need any technical
support,
please contact us
Tel: +86 755 61919966
Email: support@dinstar.com
Website: www.dinstar.com
DAG1000-4O
DAG1000-8O
DAG2000-16O
DAG3000-32O
DAG3000-128O
.
v2.0 2021
Advertisement
Table of Contents
Related Manuals for Dinstar DAG1000-4O
Summary of Contents for Dinstar DAG1000-4O
- Page 1 Quick Installation Guide DAG1000-4O DAG1000-8O DAG2000-16O DAG3000-32O DAG3000-128O Thanks for Choosing Dinstar’s VoIP Gateway! Please read this guide carefully before installing the gateway. If you need any technical support, please contact us Tel: +86 755 61919966 Email: support@dinstar.com Website: www.dinstar.com...
-
Page 2: Description Of Indicators
DAG3000-32O DAG3000-128O Dinstar’s VoIP gateways have two types of FXO ports, namely RJ11 and RJ45. For the number of ports of each model,please refer to the table above. Please check the model of your gateway before installation,and then refer to corresponding installation instructions. -
Page 3: Indicators & Interfaces
Indicators & Interfaces DAG1000-4O Network Link Indicator Reset Button Power Indicator Running Indicator Network Speed Indicator FXO In-use Indicator Power Port FXO Ports LAN Ports WAN Port DAG1000-8O Power Indicator Network Link Indicator Reset Button Running Indicator Network Speed Indicator FXO In-use Indicator... - Page 4 DAG3000-32O Main Control Board User Board Power Indicator Console Port Power Indicator FXO Ports LAN Ports Reset Button Screw Running Indicator Running Indicator FXO In-use Indicator 100-240VAC 100-240VAC 50/60Hz 50/60Hz Ground Point Power Switch Power Jack Power Switch Power Jack DAG3000-128O User Board Main Control Board...
-
Page 5: Installation Attentions
Anti-jamming: to reduce the interference with PSTN lines, it’s highly recommended that PSTN lines connected to the gateway should be placed away from power cables; Power supply: DAG1000-4O and DAG1000-8O are equipped with 12VDC power adapter, while DAG2000-16O, DAG3000-32O and DAG3000-128O accepts AC input voltage of 100-240V. - Page 6 Connection Diagram for DAG1000-8O Connect gateway with network Network Cable Network Cable Router Connect FXO port with PSTN line PSTN Line PSTN Telecom Operator User Connect gateway with power input DC12V Power Plug...
- Page 7 Connection Diagram for DAG2000-16O Connect gateway with network 100-240VAC 50/60Hz Network Cable Network Cable Switch Connect FXO port with PSTN line PSTN Line PSTN User Telecom Operator Connect gateway with power input 100-240VAC 50/60Hz Grounding Cable Ground Point AC 100-240V...
- Page 8 Connection Diagram for DAG3000-32O Connect gateway with network Network Cable Network Cable Switch Connect FXO port with PSTN line PSTN Line PSTN User Telecom Operator Connect gateway with power input 100-240VAC 100-240VAC 50/60Hz 50/60Hz Grounding Cable Ground Point AC 100-240V AC 100-240V...
- Page 9 Connection Diagram for DAG3000-128O Connect gateway with network Network Cable Network Cable Switch Connect FXO port with PSTN line PSTN Line PSTN User Telecom Operator Connect gateway with power input 100-240VAC 50/60Hz 100-240VAC 50/60Hz Grounding Cable Ground Point AC 100-240V...
- Page 10 Modify PC’s IP Address To log in the Web Management System of the gateway, you need to modify the IP address To log in the Web Management System of the gateway, you need to modify the IP address of PC first to make it at the same network segment with the gateway. of PC first to make it at the same network segment with the gateway.
-
Page 11: Basic Configurations
Log in Web Management System Open a web browser and enter the gateway’s IP address (default IP is 192.168.11.1). Then input username and password in the displayed login GUI. Both the default username and password are admin. Modify Gateway’s IP Address If you want to modify the IP address of the DAG gateway, please click ‘Network →... - Page 12 (2) Create IP Trunk Call & Routing→IP Trunk On the interface, click Add to create an IP trunk which connects to a peer SIP server. (3) Create Outbound Route On the Call & Routing→<IP→Tel Routing> interface， click Add to create an outbound route for the IP trunk.
-
Page 13: More Details
Configure FXO Parameters On the Advanced →FXS/FXO interface,configure the gateway to detect CID after ring or before ring,and enable ‘Send Original CID when call from PSTN’.Format of “from” field is set as ‘CID/CID’ when CID is available,while format of “from” field is set as ‘Display/User ID’... - Page 14 B. Dial the number of PSTN line first, and then dial *166*000000#. After that, restart the gateway. C. Log in the gateway and then click Tools → Factory Reset, then click Apply and restart the gateway. Honest, Concentrated, Innovative, Open Shenzhen Dinstar Co., Ltd. Website: http://www.dinstar.com Facebook: http://www.facebook.com/dinstarvoip/...
