Card stock & label guide

Table of Contents

Overview of Card Stock and Label Support

Paper Source

200-Sheet Heavy Duty Tray

500-Sheet Tray (450 grams) 90 g/m

500-Sheet Tray (550 grams) 135 g/m

500-Sheet Tray (650 grams) 163 g/m

500-Sheet Tray (750 grams) 199 g/m

Manual Feed Tray

For paper and transparency specifications, refer to your printer User's Guide.

As the following table indicates, the paper tray capacities vary depending on the print material

construction. Refer to your printer documentation for additional specifications.

Estimated Tray Capacities for Labels

Label Material

Paper, Dual Web

Vinyl, Polyester

The table on Page 97 lists the print material specifications for the special card stock and label trays,

as well as guidelines for the tray position (upper or lower drawer). This information is intended to

convey general guidelines for tray and drawer selection. We recommend that you test your selected

print material to determine the best tray and drawer selection for your application. The material type,

rigidity, sizing, perforations, die-cuts, surface, and so on influence printing reliability. Contact your

point of purchase for more information on the optional trays available for your printer.

Note: If you use materials with a basis weight over 135 g/m

registration and skew may be unpredictable.
