Page 2 Improvements or changes in the products or the programs described may be made at any time. A form for reader’s comments is provided at the back of this publication. If the form has been removed, comments may be addressed to Lexmark International, Inc., Department F95/035-3, 740 West New Circle Road, Lexington, Kentucky 40550, U.S.A.
Page 3: Table Of Contents
Lexmark Web site ........
Page 4 Controlling your printer ........
Page 5 Printer drivers ........
Page 6 Theory of operation ..........146 Understanding printer messages ....... . . 147 Status messages .
Page 7 Automated fax system ........199 Appendix B: Printer specifications ... . . 201 Appendix C: Fonts .
Page 8 Appendix F: Warranty ..... . . 239 Glossary ........241 Index .
Page 9: Using Your Documentation
When searching for a chapter or topic, use this feature to quickly locate the information you need. The Quick Reference Card offers an overview of the printer menu structure and tips for loading paper, and clearing paper jams. You may want to keep the Quick Reference Card near the printer so all users have access to it.
Page 10: Conventions
Note: A note provides auxil- iary information you may find useful. Warning! A warning identifies something that might damage your printer hardware or soft- ware. Caution! A caution identifies something that might cause you harm. About the manuals It may help you to recognize the conventions we have used in this book: •...
Page 11: Other Sources Of Information
In addition to the User’s Guide, Quick Reference Card, and of information Setup Guide, Lexmark offers other sources of information about your printer or about Lexmark products and ser- vices. Online documents The Drivers, MarkVision and Utilities compact disc (CD) that comes with your printer contains several online docu- ments.
Page 12: Lexmark Web Site
If you need help with your printer, you can visit our Web site at: http://www.lexmark.com/service/service.html Automated If you’re in the U.S. or Canada, you can use the Lexmark automated fax system to request information about Lex- fax system mark products, available printer drivers, or other related topics.
Page 13: Trademarks
AppleTalk, LocalTalk, Macintosh, System 7.1, and True- Type, are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. PANTONE Colors generated by the Optra C710 color printer are four-color process simulations and may not match PANTONE-identified solid color standards. Use current PANTONE Color Reference manuals for accurate color.
Page 14 Incorporated. PostScript is Adobe Systems’ designation of a set of printer commands (language) and functions included in its printer products. This printer is intended to be compatible with the PostScript language. This means the printer recognizes PostScript commands used in vari- ous application programs, and the printer emulates the functions corresponding to the commands.
Page 15: Introducing Your Printer
250-sheet trays that can increase the printer's total paper capacity to 800 sheets. Your Lexmark printer software enables you to easily mas- ter advanced color management techniques such as levels of brightness, contrast, and saturation. You can easily...
Page 16: Print Speed
Print speed Your printer can print four-color and mono jobs at up to 16 ppm for monochrome print jobs and 3 ppm for color print jobs. If you install an optional duplex unit, you can print duplex jobs at up to 5 ppm for monochrome print jobs and 1.5 ppm for color print jobs.
Page 17: Printer Drivers
Printer drivers The printer drivers included on the Driver, MarkVision, and Utilities CD shipped with your new printer were spe- cially designed for this printer. Using these printer drivers gives you the greatest control over the features and func- tions of your printer. Your printer drivers have been designed to work efficiently with your printer and pro- vide you with the best possible print quality.
Page 18 Chapter 1: Introducing your printer...
Page 19: Using Printer Drivers
To modify your printer settings this way, select File from the menu bar and Print or Printer Settings. This opens a print or printer settings window that allows you to modify some or all of the many printer settings.
Page 20 You can override these operator panel settings through the software application or printer driver. In most cases, settings you change from your software applica- tion or printer driver apply only to the job you are preparing to send to the printer.
Page 21: Changing Printer Settings
This chapter is organized according to the structure of the printer operator panel menus. You can also change many of these settings from your application, a Lexmark printer driver, or from the MarkVision printer utility. If there is a printer feature you cannot control from the applica- tion or printer driver, use the printer operator panel or the remote operator panel available from MarkVision.
Page 22: Using The Operator Panel
• Clear certain messages from the display • When entering a number 5 as part of a PIN for confidential or print and hold printing If you’ve changed printer settings from the operator panel, press Go before you send a job to print.
Page 23: Markvision's Remote Operator Panel
The message activity. For example, if you need to load paper in a tray while a job is printing, press the printer motors to idle before removing the tray. Reinsert the loaded tray, and then press Also press Stop printing.
Page 24: Menus
Chapter 3: Menus A number of menus are available to make it easy for you to change printer settings. The diagram on page 16 shows all of the menus and items available under each menu. Items in each menu and the values you can select are described in more detail in the tables beginning on page 17.
Page 25: Plain Paper
Paper Source = Tray 1* 1 Menu 2 Select 3 Return 4 Go 5 Stop 6 PAPER TYPE Tray 1 Type 1 Menu 2 Select 3 Return 4 Go 5 Stop 6 Tray 1 Type = Plain Paper* Select 3 Return 4 1 Menu 2 Stop 6...
Page 26: Print Menus
Menus Press Select The message printer returns to the ready state after the list of user default settings prints. If an error message appears on the display, see “Under- standing printer messages” on page 147. To change the user default settings from the menus:...
Page 27 Note: Press Return if you need to go back to previous menus or menu items without changing the current setting. Note: User default settings remain in effect until you save new settings or restore factory defaults . A value can be: –...
Page 28: Locking The Menus
Turn the printer off. Press and hold the printer on. Release both buttons when played. appears on the display. When the printer self test is Busy complete, the mes- To unlock the menus, repeat steps 1 through 3. If you want to disable the button sequence so users cannot easily lock or unlock the menus from the printer operator panel, change the password variable of the PJL JOB command.
Page 29: Fax Status Messages
1 Menu 2 Go 5 Stop 6 If an internal fax modem adapter card is installed and the printer is configured to process fax data, the operator panel will display different icons to indicate the current fax status. The following table shows the icons and a description of the icon meaning.
Page 30: Menu Overview
Print Resolution Tray 1 Status Tray 2 Status Tray 3 Status Coating Roll Transfer Belt JOB MENU (page 35) Cancel Job Reset Printer Print Buffer CONFIDENTIAL JOB HELD JOBS PCL EMUL MENU (page 44) SETUP MENU (page 38) Font Source...
Page 31: Supplies Menu
Empty Your printer can detect if a tray is missing, low on paper (less than 50 sheets), or the tray is empty. The Supplies Menu lists any of the installed trays (tray 1, tray 2, or tray 3) that meets any of these conditions.
Page 32 Transfer Belt Missing Life Warning Exhausted When the transfer belt is nearing its life end, the printer identifies the transfer belt as close to being exhausted. The printer displays You can press the operator panel. When the transfer belt is exhausted, the printer stops printing and displays Life Exhausted message.
Page 33: Color Menu
Note: Due to the difference between additive and subtractive colors, there are colors your printer can produce that are impossible to duplicate on your monitor and there are colors your monitor can display that cannot be duplicated on any printer. For more information, see “Color difference”...
Page 34: Paper Menu
A4* (Country specific) JIS B5 Letter* (Country specific) Legal Executive Universal (Envelope sizes are the same as *Factory default Chapter 3: Menus The Paper Menu configures the printer for the source, size, and type of media you load. Manual Env Size...
Page 35 97 for a list of the dimensions for each paper and envelope size. Trays 1, 2, and 3 have size sensing. The printer uses the rear paper guide to automatically determine the size of the paper installed in the tray and displays only that size as the default in the Paper Size menu.
Page 36 Paper Menu (continued) Menu item Values PAPER TYPE Tray 1 Type Plain Paper* Transparency Bond Letterhead Preprinted Colored Paper Custom Type 1 Custom Type 2 Custom Type 3 Custom Type 4 Tray 2 Type Plain Paper Bond Letterhead Preprinted Colored Paper Custom Type 1 Custom Type 2* Custom Type 3...
Page 37 Paper Menu (continued) Menu item Values PAPER TYPE MP Feeder Type (continued) Plain Paper Card Stock Transparency Labels Bond Envelope Letterhead Preprinted Colored Paper Custom Type 1 Custom Type 2 Custom Type 3 Custom Type 4* Manual Pap Type Plain Paper* Card Stock Transparency Labels...
Page 38 Paper Type setting to optimize print quality for the media you specified. For example, if you set Tray 1 Type to Transparency, the printer heats the fuser to a higher temperature and slows printing to produce the best transparency possible. If you change Tray 1 Type to Plain Paper, there is a slight delay while the printer cools to the appropriate temperature for printing paper.
Page 39 For example, if Substitute Size is set to Letter/A4 on a printer with only letter size installed, and the printer receives a request to print a job on A4, the printer will automat- ically print the job on letter instead of posting a change request to the user for A4 paper.
Page 40 Paper Menu (continued) Menu item Values Paper Loading Off* Duplex Bond Loading Ltrhead Loading Preprint Loading Colored Loading Custom 1 Loading Custom 2 Loading Custom 3 Loading Custom 4 Loading This setting is useful when using preprinted duplexed forms where you may want to print some information for those forms duplexed and some information simplexed (single sided).
Page 41: Finishing Menu
Collation is On, then the copies will be collated. For example, if you send a three-page job to print and set Copies to 2, the printer prints page 1, page 1, page 2, page 2, page 3, page 3.
Page 42 Set Collation On to collate multiple copies of a job. For example, if you send a three-page job to print and set Copies to 2, the printer prints page 1, page 2, page 3, page 1, page 2, page 3.
Page 43 Between Jobs Between Pages You can have the printer insert blank separator sheets between jobs, between multiple copies of a job, or between each page of a job. Separator sheets are pulled from the source identified in the Separator Source menu item.
Page 44 Note: Multipage Printing is not supported by PPDS and PCL XL. Note: Multipage Printing is not recommended when images and gray fills are dithered on the host. The print quality of the page may be severely affected when the printer scales a host dithered artifact.
Page 45 When printing the same job 4-up, the printer positions the top edge of the images along the short edge of the page. If you prefer to have the page images always oriented along the long edge or along the short edge of the sheet, select Long Edge or Short Edge as the user default.
Page 46: Utilities Menu
(second line). Print Menus Press Select options, the amount of installed printer memory, the printer software code levels, the total count of printed pages, and the printer serial number. Print Net1 Setup Press Select Note: Only displayed when a network card is installed in PCI slot 1.
Page 47 When you choose to restore the factory default settings: • All downloaded resources (fonts, macros, symbol sets) in printer memory (RAM) are deleted. (Resources residing in flash memory or on hard disk are unaffected.) • All menu settings are returned to the factory default values except : –...
Page 48 Print Clear If you have an optional disk installed in your printer and you are using the printer’s Job Accounting function, you can choose to print a list of statistics for a defined number of the most recent print jobs. (The number of jobs is determined by the value of the Job Acct Limit menu item in the Setup Menu.) The statistics include whether the job printed with or without...
Page 49: Job Menu
This menu item is only available when you enter the Job Menu while the displayed. The Waiting state occurs if an incomplete job is sent to the printer or if an ASCII job is being printed. Examples include sending a print screen command from your host computer or copying a DOS file.
Page 50 If you send a Confidential Job, the printer formats your job and holds the job in memory. The printer delays the printing of your job until you enter a PIN assigned to the job. You enter the number through the operator panel. When printed, the job is automatically deleted.
Page 51 The Held Jobs setting permits the user to delay the printing of a job and/or print additional copies of a job. If you send a Reserve Print, Repeat Print or Verify Print Job, the printer holds the job in memory.
Page 52: Setup Menu
Power Saver 1…240 (20*) The Power Saver menu item lets you reduce power usage when the printer is idle. The Power Saver setting determines the length of time (in minutes) the printer waits after a job is printed before it goes to a reduced power state.
Page 53 When a print timeout occurs, the printer stores the page in the print buffer. When Print Timeout is disabled, the printer does not print the last page of a print job until one of the following occurs: •...
Page 54 88 Black Toner Low Print Jobs on Disk? If one of these errors occurs and Auto Continue is disabled, the printer stops and waits for operator intervention. When Auto Continue is set to a numerical value, the printer waits for operator intervention for the specified length of time and then automatically resumes processing.
Page 55 When Jam Recovery is set Off, the printer does not reprint a page that has jammed. When Jam Recovery is set On, the printer keeps the image for a printed page until the printer signals the page has successfully exited the printer. The printer reprints all jammed pages.
Page 56 Normal* Whole Page Select Whole Page to modify the PCL formatting area and the printer print area. Refer to the Technical Reference for more information about printable areas. When Normal is selected the printer uses the print area of the paper indicated by the paper tray or operator panel input.
Page 57 Job Accounting Off* If you have an optional disk installed in your printer, set Job Accounting On to use the disk to store statistical information about your printer’s most recent jobs. The statistics include whether the job printed with or without errors, time required to print the job, size (in bytes) of the job, requested paper size and paper type, color settings used, total number of printed pages, and the number of copies requested.
Page 58: Pcl Emul Menu
This printer setting allows you to select the source which contains the default font selection. The value list only consists of font sources which exist on the printer. In other words, if no download fonts exist in the printer’s memory and no flash or disk is installed, then Resident is the only valid value for the Font Source.
Page 59 A symbol set is a set of alphabetic and numeric characters, punctuation, and special symbols used when printing with a selected font. Symbol sets support the different requirements for languages or specific applications, such as math symbols for scientific text. The printer displays only the symbol sets supported for the selected font name.
Page 60 The Lines per Page setting determines the number of lines that print on each page. The setting can range from 1 to 255 lines per page. The printer sets the amount of space between each line (vertical line spacing) based on the Lines per Page, Paper Size, and Orientation settings.
Page 61 For example, if you want to use a different printer driver with your printer and have optional drawers installed, use the Tray Renumber menu item to set the tray values. You can then successfully choose the correct paper source with the different printer driver.
Page 62: Postscript Menu
Note: This printer setting does not affect the searching for fonts downloaded to VM (Virtual Memory). In other words, if fonts exist in VM, it is always searched before any external device or the internal ROM storage device regardless of the setting of Font Priority.
Page 63: Parallel Menu
NPA format. If not, it is rejected as bad data. If NPA Mode is set Off, the printer does not perform any NPA processing. If NPA Mode is set to Auto, the printer examines the data to determine the format and then processes it in either format.
Page 64 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the parallel port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 65 Honor Init Off* The Honor Init setting determines whether the printer honors hardware initialization requests from the computer. The computer requests initialization by activating the INIT signal on the parallel interface. Many personal computers activate the INIT signal each time the computer is turned on and off.
Page 66: Serial Menu
NPA format. If not, it is rejected as bad data. If NPA Mode is set Off, the printer does not perform any NPA processing. If NPA Mode is set to Auto, the printer examines the data to determine the format and then processes it in either format.
Page 67 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the serial port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 68 Robust XON Off* This printer setting only applies to the serial port if Serial Protocol is set to XON/XOFF. When Robust XON is set On, the printer sends a continuous stream of XONs to the host computer to indicate the serial port is ready to receive more data.
Page 69 Honor DSR Off* The Honor DSR setting determines whether the printer uses its Data Set Ready (DSR) signal. DSR is one of the handshaking signals for most serial interface cables. The serial interface uses DSR to distinguish data sent by the computer from data created by electrical noise in the serial cable.
Page 70: Network Menu
NPA format. If not, it is rejected as bad data. If NPA Mode is set Off, the printer does not perform any NPA processing. If NPA Mode is set to Auto, the printer examines the data to determine the format and then processes it in either format.
Page 71 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the network port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 72 For more information, refer to the documentation that came with your network adapter. The following settings are used to configure your clock settings on your internal fax modem. This menu item is only available if an optional internal fax modem is installed in your printer. Time Server...
Page 73: Infrared Menu
If both PCL SmartSwitch and PS SmartSwitch are set Off, the printer uses the language specified in the Printer Language menu as the default. If only one SmartSwitch setting is set Off, the printer uses the language that has its SmartSwitch set On as the default.
Page 74 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the infrared port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 75 If Auto is selected, the printer automatically sets the Transmit Delay value during power-on to maximize link performance.
Page 76: Localtalk Menu
If both PCL SmartSwitch and PS SmartSwitch are set Off, the printer uses the language specified in the Printer Language menu as the default. If only one SmartSwitch setting is set Off, the printer uses the language that has its SmartSwitch set On as the default.
Page 77 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the LocalTalk port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 78 NPA Hosts 1…10 (2*) Use this setting to specify the maximum number of NPA hosts that can register for NPA printer alerts. When the number of hosts registered for NPA alerts exceeds the quantity specified by the NPA Hosts menu item, any additional hosts attempting to register for alerts are ignored.
Page 79: Usb Menu
NPA format. If not, it is rejected as bad data. If NPA Mode is set Off, the printer does not perform any NPA processing. If NPA Mode is set to Auto, the printer examines the data to determine the format and then processes it in either format.
Page 80 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the LocalTalk port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 81: Fax Menu
The Fax Menu configures a serial port to receive faxes from a class 1 fax modem connected to the port. This menu is only available if an optional tri-port adapter or internal fax modem is installed in your printer. Chapter 3: Menus...
Page 82 Job Buffering Off* If you have an optional disk installed in your printer, you can choose to have jobs that are sent to the LocalTalk port spool to the disk. Spooling jobs to disk may decrease the time required for the printer to accept data from an application, and therefore free the application faster for other work.
Page 83 Note: When Auto Reduction is set to On, and the receiving fax page image is too large to fit on the media size designated by the Fax Paper Size, the printer automatically reduces the image size to fit on the page if the Fax Auto Reduction is set to On. If Fax Auto Reduction is set to Off.
Page 84 Fax Setup values to configure your internal fax modem. The Station Name is an identification string for the printer or fax station. The Station Name is printed as part of the header information which is transmitted with every faxed page.The Station Name should be an alphanumeric value not more than 20 characters in length.
Page 85 You can use these values to configure your internal fax modem. When the Auto Print Log is set On and the Send or Receive Fax Log is full, the printer automatically prints the contents of the associated log and then clears the associated log to make room for the new entry.
Page 86 You can use these values to configure your internal fax modem. Note: The Automatic Redial value 0 indicates Automatic Redial is set to Disabled. Note: If this command is received and the printer is NOT configured for fax send capability, the document will only be printed.
Page 87 Fax Menu (continued) Menu item Values FAX RECEIVE Fax Storage Fax Paper Size A4* (NonUS) JIS B5 Letter* (US) Legal Executive Universal Fax Paper Type Plain Paper* Card Stock Transparency Labels Bond Letterhead Preprinted Colored Paper Custom Type 1 Custom Type 2 Custom Type 3 Custom Type 4 If you install an optional internal fax modem the Fax Receive information will need to be...
Page 88 Chapter 3: Menus...
Page 89: Using Color
Using color Your printer gives you the power to communicate in color. Color attracts attention, commands respect, and adds value to your printed material or information. Using color increases reader- ship and is read more often than the same material printed in black and white.
Page 90: How We See Color
Processed black when printed looks like a very dirty or muddy brown. Because of this, your printer has a black print cartridge to provide you with true black for all your printing needs.
Page 91: Color Difference
The easiest way for you to get consistent color from your screen to your printer is to select standard colors. When you produce color on your screen, it is produced using a color model. A color model is a system that defines color according to a set of basic properties.
Page 92: Managing Color
Managing color Color management There are many color management systems on the market today. systems They range from simple swatchbooks to specially designed and designated color servers. Color Management Systems (CMS) help you match colors across a number of devices, including scanners, monitors, and printers.
Page 93: Popular Color Management Systems
Translation between color models Translation is the most complex element of a CMS. Because each device is based on a device-dependent color model, such as RGB or CMYK, the range of colors each device supports is dif- ferent. It is difficult and sometimes impossible to produce a par- ticular color on different devices when each device uses a different color model.
Page 94: Controlling Your Printer
Controlling your Your printer driver is designed to provide you with the best qual- printer ity output for various types of printing needs. However, you may want more control over how your printed document will look. You can control the screening methods, halftone settings, graph- ics effects, and fill resolution used during the printing of your documents.
Page 95 Use Black and White for documents that will be reproduced on a copier. Any time you prefer the printer to decide which images to enhance using the Image Enhancement screening methods. Use the 1200 dpi setting anytime you have a need for greater text, line, and image detail.
Page 96: Halftone Screens
With- out halftoning, it would not be possible to produce quality pho- tographic images on a page printer. This process of representing an image as a series of halftones, is known as halftone screen- ing.
Page 97: Screen Angle
Your printer default is set to give you the best screen frequency setting for high quality business graphics. The default angle of the halftone screen and cells places the dots so they are the least noticeable to the human eye.
Page 98: Color Correction
CMY colors. When printing any text (black or colored), we recommend set- ting your color correction to automatic and your print resolution to 600 dpi. Because colored text is also a composite of two or more colors, you may notice some blurring or distortion in col- ored text.
Page 99: Cmyk
This setting uses common color tables to translate the color settings displayed on your monitor into the color values used by the printer’s CMYK color model. This setting is generally used when your application does not do...
Page 100: 2-Color Draft
See “When to replace supplies” on page 116 for more information. Transparencies To ensure high quality output on transparencies, we recommend using the following Lexmark transparencies. They have been designed specifically for your printer: P/N 12A5150 (letter size) P/N 12A5151 (A4 size) These transparencies have characteristics that minimize curl and optimize toner transfer in a wide range of printing environments.
Page 101: Printer Drivers
Color Correction to Vivid when printing transparencies. Printer drivers The Lexmark drivers that came with your printer support all of the settings described in this chapter. They also offer some addi- tional features that may help you fine-tune your printer output.
Page 102 Chapter 4: Using color...
Page 103: Managing Memory
Printer memory Managing memory Your printer ships with at least 32MB of memory. To deter- mine the amount of memory currently installed in your printer, select Print Menus from the Utility Menu. The total installed memory appears on the printout. For more information about printing the menu settings page, see page 10.
Page 104: Adding Memory
384MB. Lexmark offers three memory options for your printer, they are 32MB, 64MB and 128MB. For memory installation instructions, refer to the Setup Guide.
Page 105: Allocating Memory
128MB 1MB allocated to standard parallel port if no optional adapter is installed. A portion of printer memory is reserved for input buffers that hold print jobs sent from your software application. Your printer has an input buffer for each interface (paral- lel, serial, network, LocalTalk, or infrared).
Page 106: Flash Memory
Press Go to return the printer to ready. If you are collating a large job and the printer memory is not sufficient, the printer automatically uses storage area available on an installed hard disk to finish collating the...
Page 107: Storing Job Statistics
See page 43 for more information about setting up your printer to gather job statistics and printing the accumu- lated data. Or, if you’re using the MarkVision utility, refer to the MarkVision online Help or the MarkVision docu- mentation on the printer CD.
Page 108 Chapter 5: Managing resources downloaded to flash or disk...
Page 109: Handling Paper
Setup Guide for information about installing the optional drawer unit. The table on page 96 details the types and quantities of media you can load in each of the printer’s paper sources. For more information about selecting specific media, see “Media guide- lines” on page 98.
Page 110: Paper Sizes
Multipurpose Paper feeder Transparencies Labels Envelopes For 20 lb paper, unless otherwise noted. Note: The printer can only duplex print A4 and letter size paper. Paper sizes Chapter 6: Paper sizes Sizes Weight A4, B5, letter, legal, executive 60–90 g/m (16–24 lb)
Page 111 Select this value when you’re feeding a non-standard size sheet from the multipurpose feeder. The printer formats the page for 8.5 x 14 in. (216 x 356 mm). Set the margins for the actual page size from your software application.
Page 112: Media Guidelines
For detailed information about media characteristics, refer to the Card Stock & Label Guide available on the CD provided with your printer. Brief guidelines for choosing paper and other media follow. Paper When printing photographic quality images, use a high quality laser printer paper.
Page 113: Letterhead
If you’re loading preprinted letterhead in the trays, place the top of the page at the front of the tray with the letterhead up. If you are loading preprinted letterhead in the multipurpose feeder, place the top of the page toward the printer with the letterhead down. Stack height indicator...
Page 114: Transparencies
Transparencies Chapter 6: Media guidelines For best results, use the following Lexmark transparencies with your printer: Recommended transparencies Part number Size 12A5150 Letter 12A5151 These transparencies are designed to provide optimal print qual- ity when used with your printer. Using other transparencies designed for laser printers may yield unpredictable results and possibly cause damage to your printer.
Page 115 Loading transparencies Before loading transparencies, fan the stack to prevent sheets from sticking together. To prevent print quality problems, avoid getting fingerprints on the transparencies. Load transparencies only in the multipurpose feeder or tray 1. Multipurpose feeder Paper tray Chapter 6: Media guidelines...
Page 116: Envelopes
You can load up to 9 envelopes in the multipurpose feeder. Load envelopes with the flap side up with the return address posi- tioned to enter the printer last. Do not load stamped envelopes. Refer to the Setup Guide for additional loading instructions.
Page 117: Labels
Labels must also withstand 25 psi of pressure. For detailed information on label printing, characteristics, and design, refer to the Card Stock & Label Guide on the printer CD. Only feed labels from the multipurpose feeder. Do not load labels in the trays.
Page 118: Storing Media
• To load paper in a tray while a job is printing, press the operator panel button and wait for the printer motors Stop to idle. Remove tray from printer. Load paper and rein- stall tray. Press to continue printing. • Use only recommended media. See page 98 for more information.
Page 119: Loading Paper In The Trays
250-sheet tray and the optional 250-sheet trays) are the same. Refer to the Setup Guide for detailed instructions. The printer lets you know when you need to load paper in the trays. If a tray has less than 50 sheets of paper, the status message appears on the display.
Page 120 However, load only paper in those trays. To load the tray: Pull the paper tray completely out of the printer. Set the paper tray on a flat surface. Squeeze the snap lock on the end of the rear paper guide.
Page 121 The position of the rear paper guide tells the printer the size of the paper in the tray. If the rear paper guide is in the wrong position, you may experience paper feeding problems or incorrect formatting of pages. Set the rear paper guide into the holes on the side and bottom of the paper tray.
Page 122 Place the short edge of the paper at the front of the tray. If you’re loading preprinted letterhead, place the top of the page at the front of the tray with the letterhead up. Slide the paper tray into the printer.
Page 123: Tray Linking
If you want to increase your printer’s paper capacity, you can add an optional drawer unit with two 250-sheet paper trays to your printer. If you load the same paper size and paper type in more than one tray, the printer automatically links the trays when one tray is empty, and feeds paper from the other tray.
Page 124: Using The Multipurpose Feeder
Using the multipurpose Note: Do not close the multi- purpose feeder while paper or envelopes are in the feeder. Chapter 6: Using the multipurpose feeder The multipurpose feeder holds 50 sheets of paper, 30 transparencies, 30 sheets of labels, 9 envelopes or 30 card stock sheets.
Page 125: Printing From The Multipurpose Feeder
TYPE” on page 22. Since the multipurpose feeder does not have auto size sensing, you must set the correct paper size and type. Use the printer operator panel or MarkVision to set the paper size and paper type before you send a job to print.
Page 126 Chapter 6: Using the multipurpose feeder...
Page 127: Replacing Supplies
Coating roll Transfer belt Fuser unit Your printer has been designed to let you replace supply items without the need of a service technician. Periodi- cally you’ll need to install new print cartridges and other items to keep your printer operating properly. You may want to keep extra replacement supplies so you can oper- ate your printer without interruption.
Page 128 See page 100 for more information about transparencies. If you need more information about the supplies available to you from Lexmark, you can visit Lexmark on the World Wide Web at www.Lexmark.com. At www.Lexmark.com, you can also get the latest information on the location and telephone numbers for Authorized Supplies Dealers in your area.
Page 129: Storing Supplies
Sweden Switzerland United Kingdom 44 1628 481 500 Choose a cool, clean storage area for your printer supplies. Store print cartridges and other supplies in their original packaging until you are ready to install them. Do not expose printer supplies to: •...
Page 130: When To Replace Supplies
The paper size affects the printer ’s page count calcula- tions. The printer counts an A4 or letter size sheet as one page and a legal size sheet as 1.2 pages. Therefore, if you...
Page 131: Print Cartridges
Open the Supplies Menu to see which print cartridge is low. The printer also continues to display the sage each time you turn the printer on and each time you open and close the fuser cover, until you replace the print cartridge or until it’s empty.
Page 132: Coating Roll
The coating roll lubricates the fuser with oil. It is located inside the fuser under the printer ’s fuser cover. You will receive a new coating roll each time you order the black print cartridge.
Page 133: Recycling Used Supplies
Follow the instructions on the outside of the box to send the used supply back to Lexmark. If a prepaid shipping label is not available for your coun- try, contact the place where you bought your printer for additional recycling information.
Page 134: Replacing Supply Items
Menu and quickly determine the supply items that need to be replaced. The printer continues to display the sage each time you turn the printer on and each time you open and close the cover, until you replace the required supply items.
Page 135: Replacing Print Cartridges
When this occurs, you must install the appropriate new supplies before you can continue printing. Your printer monitors the toner level and life of your print cartridges. When the toner in your print cartridge is get- ting low, the printer will display printer display under the Supplies Menu.
Page 136: Change Toner
Remove any paper in the output bin. Return 4 Press the cartridge cover release button. Open the cartridge cover. until the color you need to <Menu to have the printer rotate the carousel...
Page 137 Warning! Do not handle the cartridge by the photoconductor or shutter assembly. Shutter and photoconductor Lift the print cartridge from the carousel. Remove the appropriate print cartridge from the packing material. Do not touch the glossy green surface under the shutter, it is the photoconductor and may become damaged.
Page 138 The cartridge is installed with the shutter up and towards the front of the printer. The edge of the cartridge toward the rear of the printer must be angled downward for the cartridge to align with the carousel. Do not leave the cartridge cover open longer than necessary.
Page 139 Note: The cover must be closed for the carousel to rotate to the next position. If you have a duplex unit installed you must close both the duplex unit and cartridge covers for the carousel to rotate. Make sure the cartridge is lying flush on the car- ousel.
Page 140: Replacing The Coating Roll
“Ordering supplies” on page 113. To replace the coating roll: Make sure the printer is turned off (O). Make sure the power cord from the outlet to the printer or optional device is unplugged.
Page 141 Note: If the duplex unit is installed, lift the duplex top cover first. Fuser cover release button Fuser door Press the fuser cover release button and lift the fuser cover. Lift the fuser door. Chapter 7: Replacing the coating roll...
Page 142 Caution! The coating roll and packing material may contain excess oil that could soil cloth- ing. Coating roll Chapter 7: Replacing the coating roll Lift coating roll from fuser. Use the handle to lift the coating roll out of the fuser. Remove the new coating roll from its package.
Page 143 Align the bar on the side of the coating roll with the slots in the fuser. Lower the coating roll into the fuser. Close the fuser door. Chapter 7: Replacing the coating roll...
Page 144 Chapter 7: Replacing the coating roll Close the fuser cover. Plug the power cord into a properly grounded electrical outlet. Place the printer power switch to on (I).
Page 145: Replacing The Fuser Kit
Release button Power switch Your printer monitors the life of your fuser. When the fuser in your printer is nearing the end of its life, the printer will display 87 Fuser Exhausted play. This message indicates it is time for you to replace the fuser kit.
Page 146 Chapter 7: Replacing the fuser kit Loosen the green thumbscrews on each side of the fuser. Lift the fuser from the printer. To lift the fuser, use the green lifting handles. Set the fuser aside. You will need to remove the coating roll from the old fuser and transfer it to the new fuser.
Page 147 Caution! The fuser area may be hot. Allow the fuser area to cool before touching. Filter To replace the air filter: Pull the filter assembly from the mount. Align the new filter assembly with the filter mount as shown. Push the filter assembly into the filter mount until it snaps into place.
Page 148 To install the fuser: Align the connector on the bottom of the fuser with the printer fuser connector. Press the fuser onto the printer fuser connector. Tighten the green thumbscrews on both sides of the fuser. Lift the fuser door.
Page 149 Remove the orange tabs and any packing material from inside the fuser. Rotate the tabs toward each other as shown. Pull the tabs up to remove them from the fuser. Open the fuser door on the old fuser. Remove the coating roll from the old fuser. Chapter 7: Replacing the fuser kit...
Page 150 Slots Chapter 7: Replacing the fuser kit Align the bar on the side of the coating roll with the slots in the fuser. Lower the coating roll into the fuser. Close the fuser door.
Page 151: Configuration Menu
Go 5 Stop 6 Close the fuser cover. Reset the fuser counter to zero. Make sure the printer power switch is off (O) and the printer is plugged into a properly grounded outlet. Press and hold the Select and Return buttons on the operator panel.
Page 152: Replacing The Transfer Kit
Release lever Chapter 7: Replacing the transfer kit Your printer monitors the life of your transfer belt. When the transfer belt in your printer is nearing the end of its life, the printer displays 84 Transfer Belt Life Warning printer display under the supplies menu. This message indicates it is time for you to replace the transfer kit.
Page 153 Green tabs Orange tabs Green tabs Pull the transfer belt from the printer. To remove the transfer belt, use the green tabs. Remove the new transfer belt from its package. Remove the orange tabs and any packing material or tape from the transfer belt.
Page 154 Align the bottom of the transfer belt with rails inside the printer. To install the transfer belt, hold it by the green tabs. Push the transfer belt into the printer until it is firmly seated. To replace the transfer roller: Squeeze the two green snap locks on each side of the transfer roller.
Page 155 Pull the transfer roller out of the front cover. A slight amount of pressure must be used to remove the transfer roller from the front cover. Make sure the springs remain in the front cover. Align the holes on the bottom of the new transfer roller with the springs on the front cover.
Page 156 Chapter 7: Replacing the transfer kit Press the transfer roller into the front cover until all of the snap locks are secure. Some minor alignment of the transfer roller and the front cover may be necessary while installing the transfer roller. Close the front cover.
Page 157 Close the multipurpose feeder. Plug the power cord into a properly grounded electrical outlet. Place the printer power switch to on (I). Chapter 7: Replacing the transfer kit...
Page 158 Chapter 7: Replacing the transfer kit...
Page 159: Solving Printer Problems
• The printer cable is securely attached to the printer and the host computer. • The power cord is plugged into the printer and a properly grounded electrical outlet. • The printer is turned on.
Page 160: Theory Of Operation
The result of these components working together is the sharp laser image you want. To get the best possible output, use the correct media thickness and type. The media recommended by Lexmark provides the best print quality.
Page 161: Understanding Printer Messages
Meaning The printer is ready to receive and process data. If the printer has an internal fax modem, the Ready/Fax icon is also displayed. For additional information regarding the fax icons, see page 15. When your printer is in power saver mode, the Ready message on the display.
Page 162 Chapter 8: Understanding printer messages Meaning The printer has received a page of data to print but is waiting for an End of Job or Form Feed command or for additional data. • To print the contents of the print buffer, press •...
Page 163 The fax interface is the active communication link. The printer is processing a request to cancel the print job. The printer is deleting any print jobs in progress and restoring all print settings to the user defaults. The printer is flushing corrupted print data and discarding the current print job. No buttons are active when this message is displayed.
Page 164: Attendance Messages
Close the printer’s front cover, fuser cover, or cartridge cover. Insert the tray indicated (tray 1, 2, or 3). The printer is requesting a different size or type media than what it detects is in the identified tray (tray 1, 2, 3, or the multipurpose feeder). The message displays either the custom media name defined using the MarkVision utility, the media size, or the media size and type it is looking for.
Page 165 Press Select. The printer is trying to feed paper from a source it detects is empty (tray 1, 2, 3, or the multipurpose feeder). The message displays either the custom media name defined using the MarkVision utility, the media size, or the media size and type it is looking for.
Page 166 35 Res Save Off Deficient Memory 37 Insufficient Collation Area Chapter 8: Understanding printer messages Action Jobs that were spooled to the optional hard disk before the printer was last turned off have not yet printed. Press to print the jobs. Press...
Page 167 Incoming data that was not stored will be lost. Stop The printer is processing the job, but the memory used to store pages is full. • Press to clear the message and continue printing. Some data may not print or may not print correctly.
Page 168 52 Flash Full 53 Unformatted Flash 54 Serial Option x Error 54 Serial x Fax Connection Lost The printer has detected the external modem that was once connected to the 54 Std Par ENA Connection Lost 54 Network x Software Error...
Page 169 • Make sure the cable connecting the ENA and the printer is securely attached. Turn the printer off and then on again to see if the printer recognizes the connection. • Press to clear the message.
Page 170 See your Setup Guide for information on installing an optional hard disk in your printer. Note: Do not attempt to remove or install the hard disk with the printer power on or the power cord connected. Reserved for messages relating to the optional print server sometimes referred to as an Internal Network Adapter (INA) installed in your printer.
Page 171 Normally the coating roll is replaced when you replace the black print cartridge. It is possible, depending on the type of print jobs you send to the printer, a coating roll may have to be replaced prior to the print cartridge becoming low on toner. If you do not have an extra coating roll, order it now.
Page 172: Service Messages
Note: If the duplex unit is not plugged in, the printer will display Check Duplex The printer has detected a paper jam in the tray specified in the message. You must remove the paper from the paper path. Then close any open trays or covers.
Page 173 Message 920-929 Service Fuser Error 930-935 Service Printhead Error 939 Service RIP-Engine Comm. Indicates the printer engine has not received the proper input during a specified 941 Service Code CRC 941 Service Font CRC 943 Service RIP Font Version 944-946 Service System Board...
Page 174 970-979 Service Network Card x 990-993 Service Engine Error Chapter 8: Understanding printer messages Action Indicates a network card in the slot specified. If Alarm Control is turned on, the alarm is sounded if this error occurs. Removing or replacing the network card normally fixes this error.
Page 175: Identifying Other Problems
The information in the following tables may help you solve other printing problems. If these suggestions still do not correct the problem, call for service. You may have a printer part that requires adjustment or replacement. Action Make sure the front cover is closed completely.
Page 176 Print quality problems (continued) Problem Light lines or streaks appear on the printed page. Light lines or voids appear from the top of the page to the bottom of the page. The page is blank or one of the colors is missing. Toner smears or rubs off the page.
Page 177 • Place envelopes in trays and deliver to the post office; do not drop envelopes into mail boxes or chutes Make sure you’re using the recommended Lexmark transparencies. See page 100 for more information. When printing transparencies, always set Paper Type to Transparency.
Page 178 If you’re printing low resolution images using PostScript 3 emulation, set Image Smoothing On. See “PostScript Menu” on page 48 for more information. Make sure all four corners of the printer are resting on a level surface. Make sure you have selected the appropriate Color Correction, Image Enhancement, and Print Resolution values for the job you’re printing.
Page 179 We recommend Lexmark part number 1329605 (10 ft) or 1427498 (20 ft) for the standard parallel port. If you’re using a Lexmark internal or external network adapter, verify it is set up properly and the network cable is securely connected. Refer to the documen- tation that came with your adapter, or the network documentation on the printer CD for more information.
Page 180 Add more printer memory. See page 89 or refer to the Setup Guide for more information. Install an optional hard disk in your printer. See page 92, or refer to the Setup Guide for more information. Check the Print Timeout setting in the Setup Menu. Increase the value.
Page 181 Fan transparencies before loading. Make sure you only load transparencies in tray 1 or the multipurpose feeder. If you just turned the printer on or the printer has been idle for a period of time, print on paper before trying to print on transparencies. For example, before printing transparencies, select Print Menus from the Utilities Menu and print the menu settings page on a sheet of paper.
Page 182: Clearing Printer Paper Jams
You must clear the paper from this area, but you must also clear all paper from the entire paper path. The illustration of the printer’s paper path may help you. For paper jams occurring in the duplex unit see “Clearing duplex unit paper jams”...
Page 183 Paper jam messages Message To locate the jam… 202 Paper Jam Open the fuser cover 201 Paper Jam Open the front cover 250 Paper Jam Open the front cover 24x Paper Jam Open the paper tray Chapter 8: Clearing printer paper jams...
Page 184: Paper Jam
Caution! The inside of the printer may be hot. Allow the printer to cool before touching any internal components. Fuser cover release button Chapter 8: Clearing printer paper jams 202 paper jam To clear a 202 paper jam (fuser and output rollers): Press the fuser cover release button.
Page 185 201 paper jam To clear a 201 paper jam (transfer belt): Open the multipurpose feeder. Pull the release lever on the printer’s front cover and open the front cover. Carefully remove any paper in front of the transfer belt.
Page 186 250 paper jam To clear a 250 paper jam (multipurpose feeder): Remove the paper from multipurpose feeder. Pull the release lever on the printer’s front cover and open the front cover. Carefully remove any paper in front of the transfer belt.
Page 187: 24X Paper Jam
24x paper jam To clear a 24x paper jam (paper trays 1, 2, or 3): Pull the paper tray completely out of the printer and set it on a flat surface. Remove any wrinkled or damaged paper from the tray.
Page 188 Release lever Multipurpose feeder Chapter 8: Clearing printer paper jams Open the multipurpose feeder. Pull the release lever on the printer’s front cover and open the front cover. Carefully remove any paper in front of the transfer belt. Close the front cover.
Page 189: Clearing Duplex Unit Paper Jams
The Jam Recovery setting in the Setup Menu determines whether the printer reprints the jammed page. See page 41 for more information. Chapter 8: Clearing duplex unit paper jams Paper Jam...
Page 190 Chapter 8: Clearing duplex unit paper jams 230 paper jam To clear a 230 paper jam (duplex unit): Raise the top duplex assembly. Carefully remove any jammed paper from the front of top duplex assembly or output rollers of the printer.
Page 191 Lower the top duplex assembly. Open the top duplex assembly access door. Chapter 8: Clearing duplex unit paper jams...
Page 192 Chapter 8: Clearing duplex unit paper jams Carefully remove any jammed paper from the top duplex assembly. Close the top duplex assembly access door.
Page 193 Open the rear duplex assembly access door. Carefully remove any jammed paper from rear the duplex assembly. Close the rear duplex assembly access door. Chapter 8: Clearing duplex unit paper jams...
Page 194 Chapter 8: Clearing duplex unit paper jams Pull the duplex tray out of the duplex unit base. Remove any wrinkled or damaged paper from the duplex tray. Hold the duplex tray with both hands and firmly slide it all the way into the duplex unit base.
Page 195: Cleaning The Print Cartridge Dust Collector
Press Menu> <Menu appears on the second line. Press to have the printer rotate the carousel Select and place the cartridge in position for replace- ment. Remove any paper in the output bin. Chapter 8: Cleaning the print cartridge dust collector...
Page 196 Cartridge cover release button Slide Chapter 8: Cleaning the print cartridge dust collector Press the cartridge cover release button. Open the cartridge cover. Lift the print cartridge from the carousel. Turn the print cartridge over. Move the green slide completely across the print cartridge and back again.
Page 197 Photoconductor shutter Place the print cartridge onto the carousel. The edge of the cartridge toward the rear of the printer must be angled downward for the cartridge to align with the drum. Close the cartridge cover. Chapter 8: Cleaning the print cartridge dust collector...
Page 198: Cleaning The Waste Toner Sensor
To replace the transfer belt: Place the printer power switch to off (O). Unplug the printer or optional device power cord from the outlet. Open the multipurpose feeder. Lift the release lever on the printer’s front cover. Open the front cover.
Page 199 Warning! Make sure you do not touch the image film inside the transfer belt housing. Pull the transfer belt from the printer. To remove the transfer belt, use the green tabs. Chapter 8: Cleaning the waste toner sensor...
Page 200 Place the transfer belt on its end as shown. Move the wiper lever from side to side to clean the detection window. Align the bottom of the transfer belt with rails inside the printer. Push the transfer belt into the printer until it is firmly seated.
Page 201 Close the front cover. Close the multipurpose feeder. Plug the power cord into a properly grounded electrical outlet. Place the printer power switch to on (I). Chapter 8: Cleaning the waste toner sensor...
Page 202: Calling For Customer Support
Calling for When you call for printer service, be prepared to describe the problem you are experiencing or the error message on customer support the printer operator panel. You’ll also need to know your printer model type and serial number. Look for the label on the rear cover for your printer model and serial number information.
Page 203: Appendix A: Markvision
MarkVision and Utilities CD that comes with your printer. MarkVision for Windows 95/98, Windows NT 4.0, Macin- tosh, and OS/2 Warp is shipped with your printer on the Drivers, MarkVision and Utilities CD. You can purchase MarkVision for UNIX networks and UNIX Intranet Serv- ers and MarkVision for Sun Systems and Sun Intranet Servers from Lexmark.
Page 204: Introducing Markvision
MarkVision. Appendix A: MarkVision MarkVision’s graphical user interface provides ongoing status for Lexmark printers connected locally or attached directly to a network. Network users and administrators can also use the following MarkVision features to increase productivity.
Page 205: Features
If a feature is helpful for a user at an individual workstation, “user” is clearly indicated in the section. Lexmark is continually updating printer utilities to pro- vide you optimum printer control. To get information about the newest versions of MarkVision, which may include new features or enhanced functions, use the Lex- mark resources listed under “Getting updated utilities and...
Page 206 Customized user accounts Job statistics Printer map Printer grouping Printer inventory Property tag support Resource management Printer and network adapter password control Job queue management Print buffer management Job buffering Can configure but cannot upgrade. Limited function. Support for this feature provided by the operating system.
Page 207 Printer configuration. MarkVision’s Quick Setup func- tion lets you configure multiple printers simultaneously. Simply use MarkVision to set up one printer, save the set- tings into a file, and send that file to all the other printers you want to update.
Page 208 When minimized on your screen, the MarkVision icon flashes to let you know there is a problem with a printer. You can maximize the window to see a graphic of the printer and detailed information about the problem.
Page 209 You can then use the opera- tor panel buttons to clear errors or step through the menus and change printer settings. Printer management The tabs in the MarkVision window that group related printer settings, as well as the remote operator panel, make it easy to view and change printer default settings.
Page 210 When you gather inventory information about the print- ers on a network, you can create a MIF file for each printer’s data. You can then import the MIF files into vari- ous network management tools to create reports that may help with asset management and other tasks.
Page 211: Markvision Online Help
(parallel, serial, network, LocalTalk, or infrared). Job buffering allows the printer to remain busy even if the host computer, network connection, or printer server is down. Jobs buffered to disk are retained even if the power supply to the printer is interrupted.
Page 212: Installing Markvision On A Network
Install window when running the Network Printer Utility. To set up the OS/2 server to support clients using Windows operating systems, select “Server and Workstation Utilities” from the Install window when running the Network Printer Utility. Server/Network operating system independent.
Page 213: Getting Updated Utilities And Drivers
Windows desktop. If you have access to an online service, you can download printer drivers and updates to MarkVision and other printer utilities from Lexmark 24 hours a day, 7 days a week. The addresses are: • Internet server: ftp.lexmark.com (driver files are located at /pub/driver) •...
Page 214 Appendix A: MarkVision...
Page 215: Appendix B: Printer Specifications
A4, B5, letter, legal, and executive 32MB (SDRAM) Note: Some printer models may ship with more memory. When a duplex unit is installed, 64MB is the recommended minimum printer memory. Base printer; Parallel (standard Centronics protocol that complies with bidirectional IEEE 1284B) Network printer;...
Page 216 • Ethernet 10BaseT and 10Base2 • Ethernet 10/100BaseTX • Token-Ring (connects the printer to a Token-Ring network via DB9 or RJ45) Provides support for the following interfaces: • Serial RS-232C/RS-422A (which can also be configured to support a class 1 fax modem) •...
Page 217: Printer Supplies
Printer configuration Dimension (HxWxD) Printer 405 mm (16.0 in.) Printer with duplex unit 550 mm (21.7 in.) Printer with optional drawer unit 628 mm (24.8 in.) Printer with optional drawer unit 770 mm (30.4 in.) and duplex unit Weight Printer configuration...
Page 218 Appendix B: Printer specifications...
Page 219: Appendix C: Fonts
Printing font To print samples of all the fonts currently available for your printer: samples From the printer operator panel, press < to enter the menus. Menu Continue to press and release UTILITIES MENU Press to display the list of menu items for...
Page 220: Resident Fonts
Resident fonts PCL scalable fonts Appendix C: Fonts The scalable and bitmapped fonts resident in your printer are listed below. You can select the resident fonts from your software application, or from the printer operator panel if you’re using PCL emulation.
Page 221 Helvetica Light Oblique Helvetica Narrow Helvetica Narrow Bold Helvetica Narrow Bold Italic Helvetica Narrow Italic ITC Avant Garde Book ITC Avant Garde Book Oblique ITC Avant Garde Demi ITC Avant Garde Demi Oblique ITC Bookman Demi ITC Bookman Demi Italic ITC Bookman Light ITC Bookman Light Italic ITC Zapf Chancery Medium Italic...
Page 222: Postscript Scalable Fonts
PostScript scalable Appendix C: Fonts The following are resident scalable fonts for PostScript 3 emulation: fonts AlbertusMT AlbertusMT-Italic AlbertusMT-Light AntiqueOlive-Bold AntiqueOlive-Compact AntiqueOlive-Italic AntiqueOlive-Roman Apple-Chancery Arial-BoldItalicMT Arial-BoldMT Arial-ItalicMT ArialMT AvantGarde-Book AvantGarde-BookOblique AvantGarde-Demi AvantGarde-DemiOblique Bodoni Bodoni-Bold Bodoni-BoldItalic Bodoni-Italic Bodoni-Poster Bodoni-PosterCompressed Bookman-Demi Bookman-DemiItalic Bookman-Light Bookman-LightItalic Candid...
Page 223 GillSans-Bold GillSans-BoldCondensed GillSans-BoldItalic GillSans-Condensed GillSans-ExtraBold GillSans-Italic GillSans-Light GillSans-LightItalic Goudy Goudy-Bold Goudy-BoldItalic Goudy-ExtraBold Goudy-Italic Helvetica Helvetica-Black Helvetica-BlackOblique Helvetica-Bold Helvetica-BoldOblique Helvetica-Condensed Helvetica-Condensed-Bold Helvetica-Condensed-BoldObl Helvetica-Condensed-Oblique Helvetica-Light Helvetica-LightOblique Helvetica-Narrow Helvetica-Narrow-Bold Helvetica-Narrow-BoldOblique Helvetica-Narrow-Oblique Helvetica-Oblique HoeflerText-Black HoeflerText-BlackItalic HoeflerText-Italic HoeflerText-Ornaments HoeflerText-Regular Intl-CG-Times Intl-CG-Times-Bold Intl-CG-Times-BoldItalic Intl-CG-Times-Italic Intl-Courier Intl-Courier-Bold Intl-Courier-BoldOblique Intl-Courier-Oblique Intl-Univers-Bold...
Page 224 LubalinGraph-Book LubalinGraph-BookOblique LubalinGraph-Demi LubalinGraph-DemiOblique Marigold Monaco MonaLisa-Recut NewCenturySchlbk-Bold NewCenturySchlbk-BoldItalic NewCenturySchlbk-Italic NewCenturySchlbk-Roman NewYork Optima Optima-Bold Optima-BoldItalic Optima-Italic Oxford Palatino-Bold Palatino-BoldItalic Palatino-Italic Palatino-Roman StempelGaramond-Bold StempelGaramond-BoldItalic StempelGaramond-Italic StempelGaramond-Roman Symbol Taffy Times-Bold Times-BoldItalic Times-Italic TimesNewRomanPS-BoldItalicMT TimesNewRomanPS-BoldMT TimesNewRomanPS-ItalicMT TimesNewRomanPSMT Times-Roman Univers Univers-Bold Univers-BoldExt Univers-BoldExtObl Univers-BoldOblique Univers-Condensed Univers-CondensedBold Univers-CondensedBoldOblique...
Page 225: Bitmapped Fonts
(or more spe- cifically, for each code point). Some applications require different characters at some code points. To support multi- ple applications and languages, your printer has 83 symbol sets for the resident PCL 6 emulation fonts. Symbol Sets for Not all font names support all of the symbol sets listed.
Page 226 ISO 15: Italian ISO 16: Portuguese ISO 17: Spanish ISO 21: German ISO 25: French ISO 57: Chinese ISO 60: Norwegian version 1 ISO 61: Norwegian version 2 ISO 69: French ISO 84: Portuguese ISO 85: Spanish ISO 8859-1 Latin 1 (ECMA-94) ISO 8859-2 Latin 2 ISO 8859-5 Latin/Cyrillic ISO 8859-7 Latin/Greek...
Page 227: Downloadable Fonts
Fonts downloaded to flash memory or disk remain in memory even after the printer language changes, the printer resets, or the printer is turned off. The MarkVision utility includes a remote management function that lets you manipulate the font files you’ve downloaded to flash memory or disk.
Page 228 Appendix C: Fonts...
Page 229: Appendix D: Safety Information
This product is designed, tested and approved to meet strict global safety stan- dards with the use of specific Lexmark components. The safety features of some parts may not always be obvious. Lexmark is not responsible for the use of other replacement parts.
Page 230 Il prodotto è stato progettato, testato e approvato in conformità a severi standard di sicurezza e per l’utilizzo con componenti Lexmark specifici. Le caratteristiche di sicurezza di alcune parti non sempre sono di immediata comprensione. Lexmark non è responsabile per l’utilizzo di parti di ricambio di altri produttori.
Page 231 Este producto se ha diseñado, verificado y aprobado para cumplir los más estrictos están- dares de seguridad global usando los componentes específicos de Lexmark. Puede que las características de seguridad de algunas piezas no sean siempre evidentes. Lexmark no se hace responsable del uso de otras piezas de recambio.
Page 232 • Dette produktet er utviklet, testet og godkjent i overensstemmelse med strenge verden- somspennende sikkerhetsstandarder for bestemte Lexmark-deler. Delenes sikkerhetsfunk- sjoner kan være skjulte. Lexmark er ikke ansvarlig for bruk av uoriginale reservedeler. • Produktet ditt bruker en laser. ADVARSEL: Bruk av styremekanismer, innstillinger eller fremgangsmåter som ikke er beskrevet her, kan resultere i farlig utstråling.
Page 233 • Aquest producte està dissenyat, comprovat i aprovat per tal d'acomplir les estrictes normes de seguretat globals amb la utililització de components específics de Lexmark. Les característiques de seguretat d'algunes peces pot ser que no sempre siguin òbvies. Lex- mark no es responsabilitza de l'us d'altres peces de recanvi.
Page 234 Este produto está projetado, testado e aprovado para satisfazer os padrões globais de seg- urança para uso de componentes específicos da Lexmark. Os recursos de segurança de alguns componentes podem não ser sempre óbvios. A Lexmark não é responsável pelo uso de outros componentes de substituição.
Page 235 Appendix D: Safety information...
Page 236 Appendix D: Safety information...
Page 237 Appendix D: Safety information...
Page 238 Appendix D: Safety information...
Page 239 Appendix D: Safety information...
Page 240 Appendix D: Safety information...
Page 241: Appendix E: Notices
Companies participating in this program introduce personal computers, printers, moni- tors, or fax machines that power down when they are not being used. This feature will cut the energy used by up to 50 percent. Lexmark is proud to be a participant in this program.
Page 242: Industry Canada Compliance Statement
Your Lexmark Optra C710 color laser printer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 243: Without A Network Card Installed
Your Lexmark Optra C710 color laser printer has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 244 A declaration of conformity with the requirements of the Directive has been signed by the Director of Manufacturing and Technical Support, Lexmark International, S.A., Boi- gny, France. This product satisfies the Class A limits of EN 55022 and safety requirements of EN 60950.
Page 245: Laser Notices
Laser notices The following laser advisory label is affixed to this printer as shown: Laser Advisory Label Advisory label Appendix E: Notices...
Page 246: Laser Notice
Avis relatif à l’utilisation de laser Appendix E: Notices The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1.
Page 247: Avvertenze Sui Prodotti Laser
longueurs d’onde comprises entre 770 et 795 nanomètres. L’imprimante et son système laser sont conçus pour impossible, dans des conditions normales d’utilisation, d’entretien par l’utilisateur ou de révision, l’exposition à des rayonnements laser supérieurs à des rayonnements de Classe I . Avvertenze sui Questa stampante è...
Page 248: Declaração Sobre Laser
Laserinformatie De printer voldoet aan de eisen die gesteld worden aan een laserprodukt van klasse I. Voor de Verenigde Staten zijn deze eisen vastgelegd in DHHS 21 CFR Subchapter J, voor andere landen in IEC 60825-1.
Page 249 mal drift, brugervedligeholdelse eller obligatoriske servi- cebetingelser. Huomautus Tämä kirjoitin on Yhdysvalloissa luokan I (1) laserlait- laserlaitteesta teiden DHHS 21 CFR Subchapter J -määrityksen mukainen ja muualla luokan I laserlaitteiden IEC 60825-1 - määrityksen mukainen. Luokan I laserlaitteiden ei katsota olevan vaarallisia käyt- täjälle.
Page 250: Avís Sobre El Làser
Laser-melding Skriveren er godkjent i USA etter kravene i DHHS 21 CFR, underkapittel J, for klasse I (1) laserprodukter, og er i andre land godkjent som et Klasse I-laserprodukt i sams- var med kravene i IEC 60825-1. Klasse I-laserprodukter er ikke å betrakte som farlige. Skriveren inneholder internt en klasse IIIb (3b)-laser, som består av en gallium-arsenlaserenhet som avgir stråling i bølgelengdeområdet 770-795 nanometer.
Page 251 Japanese Laser Notice Chinese Laser Notice Appendix E: Notices...
Page 252: Korean Laser Notice
Korean Laser Notice Appendix E: Notices...
Page 253: Statement Of Limited Warranty
This Statement of Limited Warranty applies to this product if it was originally pur- chased for your use, and not for resale, from Lexmark or a Lexmark remarketer, referred to in this statement as “Remarketer.” Lexmark warrants that this product: •...
Page 254 Lexmark be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages. This is true even if you advise Lexmark or a Remarketer of the possibility of such damages. Lexmark is not liable for any claim by you based on a third party claim.
Page 255 Glossary 600/1200 Image Quality. A print quality setting that allows the printer to vary the size of each printed pixel, thereby producing a continuous tone effect. This setting improves the print quality of graphic fills, images, and halftones. A4. Paper measuring 210 x 297 mm. Feeds long edge first.
Page 256 See bits per second. buffer. A portion of memory used to temporarily store data. Busy. A printer state in which the printer is processing data or printing pages. byte. A group of eight binary digits processed as a unit.
Page 257 Because of this, the DIMM memory chip provides wider and faster transfer of data. disk. Optional device that you can install in the printer to provide non-volatile storage for downloaded fonts, symbol sets, or macros. A disk also lets you store job statistics, collate large jobs, and spool jobs to the disk.
Page 258 DL. Envelope measuring 110 x 220 mm. download. To transfer information, such as fonts, from a diskette or other device to your computer or printer for temporary or permanent storage. dpi. Dots per inch. See resolution.
Page 259 (ENA). A LAN device—such as the Lexmark MarkNet XLe or MarkNet Pro—that attaches externally to the printer and lets you connect various printers to your network, thereby freeing dedicated PC print servers for use as LAN workstations.
Page 260 Honor INIT. A printer setting that allows the printer to be reset by an initialization signal sent from the computer. image. The output form of graphics data, a drawn representation of a graphics file.
Page 261 Feeding one sheet of media (paper, envelope, transparency) into the printer at a time. MarkNet Pro. See external network adapter. MarkNet S. Family of multi-protocol Lexmark INAs. Versions for Ethernet and Token-Ring available. MarkNet XLe. See external network adapter.
Page 262 The network card you install in your printer to connect your printer to a local area network. Not Ready. A printer state in which the printer does not accept data from the computer. This state is initiated either by operator intervention or a printer error.
Page 263 Sliding parts in the paper trays that define proper placement of paper. Failing to properly adjust the paper guides may result in paper jams. paper type. A printer setting that defines the type of media (plain paper, letterhead, or transparency, for example) loaded in a specified tray.
Page 264 See media. print server. See external network adapter. printer driver. A program that translates the language of a software application to the language of the printer so the two can communicate data. printer language. A set of defined commands (such as PCL or PostScript) to which the printer responds.
Page 265 Ready. State of the printer in which it can receive, process, and print data. Press the button to return the printer to the ready state. When the printer is in the ready state, the message or the message appears on the...
Page 266 SmartSwitch. A printer function that automatically switches the printer language to that of the job the software application is sending to the printer. software application. Any program loaded on your computer used to perform a specific task, such as word processing or data compiling.
Page 267 The material that adheres to the paper or other media to create the printed page. transfer belt. The rotating belt inside the printer that uses an electrostatic charge to carry or transfer the image from the photocondutor to the media on which it is to be printed.
Page 268 yield. The approximate number of A4 or letter size sheets you can print before a supply or service item must be replaced. For example, if a print cartridge has a yield of 15,000 pages, you can print approximately 15,000 pages before you must replace the print cartridge.
Page 269 Numerics 20x Paper Jam 157 23x Paper Jam Check Duplex 158 24x Paper Jam Check Tray x 158 25x Paper Jam MP Feeder 158 2-Color Draft setting 86 30 color toner missing 152 35 Res Save Off 152 37 Insufficient Collation Area 152 37 Insufficient Defrag Memory 153 37 Insufficient Memory 153 38 Memory Full 153...
Page 270 CompuServe 199 confidential job PIN numbers 36 Configure MP (Paper Menu) 25 conserving supplies 119 controlling your printer 80 conventions used in manual x Copies (Finishing Menu) 27 Custom Types (Paper Menu) 25 Cyan Toner (Supplies Menu) 17 Defragment Flash (Utilities Menu) 33...
Page 271 213 drawer, optional options 250-sheet paper trays 109 driver, printer See printer drivers Duplex (Finishing Menu) 27 Duplex Bind (Finishing Menu) 27 duplex unit paper jam 175 dust collector 181 electronic emissions notices 228 empty print cartridges 113, 117...
Page 272 PCL SmartSwitch 59 PS SmartSwitch 59 Transmit Delay 61 Window Size 61 Internet 48, 199 intranet servers 189, 199 inventory, printer hardware 196 Jam Recovery (Setup Menu) 41 jams See paper jams Japanese VCCI notice 230 Job Accounting (Setup Menu) 43...
Page 273 MarkVision 189 Magenta Toner (Supplies Menu) 17 managing color 78 managing memory 89 flash memory 92 hard disk 92 printer memory 89 solving problems 90 MarkNet internal print server 202 MarkVision 191 alerts 194 custom media names 195 features 191...
Page 274 Supplies 17 unlocking 14, 148 USB 65 Utilities 32 messages fax status 15 See printer messages Multipage Border (Finishing Menu) 31 Multipage Order (Finishing Menu) 30 Multipage Print (Finishing Menu) 30 Multipage View (Finishing Menu) 31 multipurpose feeder media specifications 96...
Page 275 Paper Loading (Paper Menu) 26 Paper Menu 20 Configure MP 25 Custom Types 25 Paper Loading 26 Paper Size 20 Paper Source 20 Paper Type 22 Substitute Size 25 paper path 168, 175 Paper Size (Paper Menu) 20 paper sizes supported 96, 97 Paper Source (Paper Menu) 20 paper sources 95...
Page 276 35 specifications 201 status 190 supplies 203 printer driver settings 5 printer drivers getting the latest versions 199 Printer Language (Setup Menu) 38 printer memory 89 managing 91 options 90 problems 90 printer messages Activating Menu Changes 148 attendance messages 150...
Page 277 7, 9, 194 renumbering trays 47 Replacing air filter 133 coating roll 126 fuser 131 print cartridges 117, 121 supplies 116 transfer belt 138 transfer roller 140 replacing supply items 120 Reset Printer (Job Menu) 35 Index...
Page 278 35 resident fonts 206 resource management 93, 196 Resource Save (Setup Menu) 39 Return button 9 RGB 84 RGB color 75 safety information 215 scalable fonts resident 206 screen angle 83 screen frequency 82 screening methods 80...
Page 279 ordering 113 recycling 119 replacing 116 storing 115 transparencies 100 Supplies Menu 17 Coating Roll 17 color Toner 17 Fuser 18 Transfer Belt 18 Tray x 17 supply items, replacing 120 Symbol Set (PCL Emul Menu) 45 Symbol Sets 211 Technical Reference xi timeouts print timeout 39...
Page 280 Windows MarkVision support 189 World Wide Web xii, 199 Yellow Toner (Supplies Menu) 17 Index...
Page 281 9/99 You may use this form to communicate your comments about this publication, with the understanding that Lexmark may use or distribute whatever information you supply in any way it believes appropriate without incur- ring any obligation to you. Did you find the book well organized?
Page 282 REPLY MAIL FIRST CLASS MAIL PERMIT NO. 2659 LEXINGTON KY POSTAGE WILL BE PAID BY ADDRESSEE Lexmark International, Inc. Department F95, Building 035-3 740 WEST NEW CIRCLE ROAD LEXINGTON KY 40511-9954 | | | | | | | | | |...

This manual is also suitable for:

19z0201 - x 862dte 4 b/w laser C710n - optra color laser printer

Lexmark Optra C710 User Manual

Using Your Documentation

Trademarks

1 Introducing Your Printer

2 Using Printer Drivers

3 Changing Printer Settings

4 Using Color

7 Replacing Supplies

8 Solving Printer Problems

Appendix A: Markvision

Appendix B: Printer Specifications

Appendix C: Fonts

Appendix D: Safety Information

Appendix E: Notices

Quick Links

Need help?

Questions and answers

Related Manuals for Lexmark Optra C710

Summary of Contents for Lexmark Optra C710

This manual is also suitable for:

Table of Contents
