AirLink GX Series Quick Start Guide
This guide provides instructions for quickly getting your Sierra Wireless
For more information refer to the:
• AirLink GX Series User Guide
™
• ALEOS Confi guration User Guide
Both are available for download from the Sierra Wireless web site (www.sierrawireless.com/Support/Downloads).
STEP 1 Install the SIM Card (Does Not Apply to CDMA Devices)
1 Remove the four screws attaching the black cover to the device's body.
If the GX device has a Wi-Fi, I/O, or Ethernet X-Card installed, refer to the AirLink GX Series
User Guide for instructions on installing a SIM card.
2 Slide the SIM card into the SIM card holder.
Note the location of the notched corner for correct alignment.
3 Replace the cover using all 4 screws to maintain the IP65 rating.
STEP 2 Connect the Device
NOTE: If you want to confi gure all your devices at the same time using AirVantage
register your devices before applying power.
1 Connect the RF antenna.
5 Connect the power cable to the device.
The device starts automatically, as indicated by the fl ashing LEDs.
© 2013 Sierra Wireless All Rights Reserved
2 If required, connect the GPS and/or
the diversity antenna (recommended).
4 If required by your application, connect the RS-232 port and/or the USB port.
Page 1
PN 2400281 Rev. 1
®
GX Series device confi gured and connected.
®
Management Service, follow the instructions on page 2 to
3 Connect a Windows
with an Ethernet cable.
® computer to the device
