- Page 1 Pellet stoves user manual english...
-
Page 3: Table Of Contents
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Extraflame S. p. A. enGLiSH .............................................. -
Page 4: English
Extraflame s.p.a. cannot be held responsible for the failure to comply with such precautions. After removing the packaging, ensure that the content is intact and complete. If not so, contact the dealer where the appliance was purchased. -
Page 5: Safety Devices
EngLisH safEty dEvicEs gLossary safEty dEvicEs Key: * = presenT, - = noT presenT cLosEd HEartH aPPLiancE Heat generator which opening is only allowed through the loading of the fuel during use. circuit board: intervenes directly by sending the product into alarm conditions until complete cooling, in the case BioMass of: breakage of flue gas motor, pellet feed motor breakage,... -
Page 6: Installations Allowed
EngLisH radiation arEa for expelling combustion products, the instructions below Area immediately near the hearth in which the heat caused by must be followed: combustion is diffused, where no combustion materials must Insulating be present. product rEfLuX arEa Area where leaking of the combustion products is verified, from the appliance towards the installation room. -
Page 7: Chimney Or Individual Flue
EngLisH cHiMnEy or individuaL fLuE The chimney or individual flue must respond to the following requisites: Š seal the combustion products, be waterproof and adequately insulated in line with the use conditions; Š be realised with materials which resist the normal mechanical stress, heat, action of the combustion products and any condensate;... -
Page 8: Chimney Cap
EngLisH < 3 m external pipe that is isolated 45° Inspection 45° Inspection Appliance connection to the flue and combustion products evacuation The flue must receive the discharge from only one heat generator. Direct discharge towards closed spaces is forbidden, even with clear sky. The direct discharge of the combustion products must be at roof and the smoke pipe must have the features provided in the "Chimney or individual flue"... -
Page 9: Connection To External Air Inlets
Š Ö-norm M 7135 Š DIn plus 51731 Š UnI Cen/Ts 14961 extraflame recommends the use of pellets with a 6 mm diameter for its products. open the tank lid and load the pellets using a scoop. tHE usE of EXPirEd PELLEts or any otHEr MatEriaL daMagEs tHE functions of your stovE and can... -
Page 10: Souvenir Spacers
eNGlIsH sOUveNIR spACeRs The “Souvenir” model has for spacers at the back to mark the minimum distance to be kept from any surface on the rear. The spacers must not be removed. HOT AIR DUCTING The pipe destined for ducting the hot air must have an internal diameter of 80 mm, be insulated and protected from heat loss. INsTAllATION Of THe pIpes UseD fOR DUCTING THe HOT AIR mUsT be peRfORmeD by qUAlIfIeD sTAff AND/OR THe mANUfACTUReR's TeCHNICAl AfTeR-sAles AssIsTANCe. -
Page 11: Souvenir
eNGlIsH sOUveNIR The “Souvenir” model can be ducted on the rear, on the side or on the top; for further information on installation, refer to the instruction leaflet provided. Option to decide when to use the duct, thanks to a hot air flow deviation by means of a key provided, which can be inserted in its special housing on the upper part of the stove. -
Page 12: Emma Plus And Tosca Plus
eNGlIsH emmA plUs AND TOsCA plUs The emma and Tosca Plus models also offer the option to decide where to direct the hot air flow, thanks to two gate valves controlled by 2 levers positioned inside the pellet tank, which must be activated via the fire irons supplied. (see figure below). -
Page 13: Control Board
EnGlISH Control Board BUTTON Display OF variOUs TO aCCess ON/OFF TexT messages THe meNU OperaTiNg pOWer TemperaTUre aDJUsTmeNT seTTiNg dISplay IConS indicates the receipt of the radio signal On = during radio communication indicates the status of the additional thermostat input (gND - i3) Off = no radio communication Fixed light = serial input deactivated it indicates functioning of the ducted motor... -
Page 14: General Menu
EnGlISH GEnEral mEnu Go BaCk - ExIt BroWSE paramEtErS: nExt (2); prEvIouS (3) modIFy SEttInG data: InCrEaSE (4); dECrEaSE (5) ConFIrm - aCCESS mEnu SEt CloCk SEt CHrono EnaBlE CHrono ConFIrmatIon lanGuaGE It,En,Fr,dE,ES Start prG1 HourS WItH kEy 6 uSEr dISplay Stop prG1 mInutES... -
Page 15: The Remote Control
EnGlISH tHE rEmotE Control The remote control allows adjusting all that can normally be done through the lCD display The table below shows the various functions in detail: on / oFF pressing the key for three seconds, the stove will switch-on or off... -
Page 16: Commissioning Settings
EnGlISH CommISSIonInG SEttInGS Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (i). The switch at the back of the stove powers the stove board. The stove remains off and a first screen appears on the panel with the word OFF. -
Page 17: Functioning And Logic
EnGlISH FunCtIonInG and loGIC IGnItIon Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. During the switch-on phase there are 15 minutes available; after switch-on and upon reaching the control temperature, the stove interrupts the ignition phase and passes to sTarTiNg. -
Page 18: Additional External Thermostat (Optional)
EnGlISH addItIonal ExtErnal tHErmoStat (optIonal) The appliance can control the room temperature by means of an additional external thermostat (optional). after ignition (pressing button 1 or via chrono mode), the stove will work to reach the thermostat setpoint, displaying (closed contact). The standard room probe is automatically ignored. Work When the thermostat reaches the temperature (open contact), the stove will go to minimum, displaying modulatIon. -
Page 19: V1-Fan
EnGlISH NO FUel: Š the stove can never develop a suitable flame, tending to remain very low even at high powers. Š at minimum power the stove tends to almost switch-off taking the stove into “ ” alarm condition. no pEllEtS Š... -
Page 20: Keys Locked
EnGlISH sTBy FUNCTiON seT TO OFF (FaCTOry seTTiNg) if the stby function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and displaying modulate. When the room temperature is lower than the setpoint, the stove will start working again at the power set on the display, showing work. -
Page 21: V2 -Fan
EnGlISH v2 -Fan The menu allows adjusting the speed percentage of the duct fan. CONTrOls prOCeDUre press the key 6, SEt CloCk will appear. Š Š press key 2 several times until "uSEr" is displayed press key 6. Š "dISplay" will appear Š... -
Page 22: Programming Example
EnGlISH proGrammInG ExamplE let's suppose that the weekly programmer function is to be used and 4 time periods are to be used in the following way: 1st time period: from 08:00 to 12:00 every day of the week, with room temperature at 19°C, excluding Saturday and Sunday 2nd time period: from 15:00 to 22:00 only Saturday and Sunday with room temperature at 21°C 1sT Time periOD sWiTCH-OFF... -
Page 23: Cleaning Under User's Responsibility
englisH Cleaning under user's responsibility Some images could be offset from the original model. MontHly daily Cleaning the heat exchanger:the heat exchangers burn pot: remove the burn pot from the relevant chamber must be cleaned every month as the soot compartment and free the holes using the appropriate fire deposited on the rear of the cast iron hearth wall blocks the irons supplied, remove the ash from the burn pot using... -
Page 24: Routine Maintenance
englisH routine MaintenanCe In order to guarantee proper functioning and safety of the device, the operations indicated below must be performed every season or more often when necessary. door, asH draWer and burn pot gasKets The gaskets guarantee the tightness of the stove and its consequent good functioning. These must be checked regularly: if they should be worn or damaged they must be replaced immediately. -
Page 25: Displays
englisH Displays Display Reason Stove off staRt The start phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress staRt-up The start phase is in progress WoRk The normal work phase is in progress MoDulation... -
Page 26: Alarms
englisH alaRMs Display explanation solution On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 3 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm. -
Page 27: Warranty Conditions
Š EXTRAFLAME S.p.A. is not liable for any damage that can, directly or indirectly, affect persons, objects and pets as a consequence of failure to comply with the prescriptions indicated in this manual/book. - Page 28 Š Masonry work Š The system particulars for the production of domestic hot water not supplied by EXTRAFLAME S.p.A. (water products only). Š The heat exchanger is excluded from the warranty unless an adequate anti-condensate circuit is realised, which guarantees a minimum return temperature of the appliance of at least 55°C (only water products).
- Page 30 www.lanordica-extraflame.com Extraflame reserves the right to vary the features and data shown in this booklet at any time and without prior notice, in order to improve its products. This manual cannot be considered as a contract for third parties.
