Extraflame Babyfiamma User Manual
Ventilated stoves
Hide thumbs
Also See for Babyfiamma:
- Instruction manual (60 pages) ,
- Use and maintenance manual (52 pages)
Related Manuals for Extraflame Babyfiamma
Summary of Contents for Extraflame Babyfiamma
- Page 1 Stufe a Pellet PELLET STOVES User Manual VENTILATED STOVES Read all instructions carefully before installation, use and maintenance The instruction book is an integral part of the product.
- Page 3 Congratulations! You are now the owner of an EXTRAFLAME stove! The EXTRAFLAME pellet stove is an ideal heating solution. It utilises the most advanced technology and is manufactured to the highest standards with a contemporary design, allowing you to enjoy the ambience and warmth of a natural fl ame in complete safety.
-
Page 5: Table Of Contents
Index Chapter 1 PRECAUTIONS AND SAFETY ........................7 Chapter 2 TECHNICAL FEATURES ..........................8 Chapter 3 WHAT ARE PELLETS?..........................11 PELLET STORAGE .................................. 11 PELLET LOAD ..................................11 Chapter 4 SAFETY DEVICES ............................. 12 WARM AIR BLOWER BREAKDOWN ..........................12 FUME EXHAUSTER BREAKDOWN ........................... - Page 6 BELLA – BELLA LUX – DUCHESSA – DUCHESSA STEEL – CONTESSA – CLEMENTINA – DIVINA – DIVINA STEEL – DIVINA PLUS – TOSCA PLUS CLEANING ..................... 44 PULIZIA BABYFIAMMA – PREZIOSA – KAROLINA – ISABELLA – GRAZIOSA – ROSY ......... 46 FALÒ 1XLP – FALÒ 1CP – FALÒ 2CP – ESMERALDA CLEANING ................48 BURN POT PARTITION .................................
-
Page 7: Precautions And Safety
Extraflame S.p.A. may not The air vents are critical for correct combustion. be held responsible in the event of failure to Keep the packaging materials out of the reach observe these precautions. -
Page 8: Technical Features
Chapter 2 TECHNICAL FEATURES Features U.M. Weight Height 1021 1036 1041 1043 Width Depth Diameter of fume discharge pipe Diameter of air intake pipe Max. heating volume Max. global thermal power Max. thermal power needed - air power supply - water power supply Min. - Page 9 Chapter 2 Features U.M. Weight Height 1032 1032 1068 1522 1522 1522 1150 Width 1806 1806 Depth Diameter of fume discharge pipe Diameter of air intake pipe Max. heating volume Max. global thermal power 10.0 10.0 10.0 12.0 10.0 10.0 10.0 12.0 Max.
- Page 10 Chapter 2 Features U.M. Weight Height 1011 1011 1068 1150 1150 1165 1053 Width 1249 1249 Depth Diameter of fume discharge pipe Diameter of air intake pipe Max. heating volume Max. global thermal power 10.0 10.0 12.0 12.0 12.0 12.0 12.0 12.0 Max.
-
Page 11: Chapter 3 What Are Pellets
Chapter 3 WHAT ARE PELLETS? Pellets are made by applying very high pressure to sawdust; i.e. the residue of raw timber (without paint) produced by sawmills, carpentry works and other activities involved in processing wood. This type of fuel is completely environmentally friendly, as no binders of any kind are used to keep it compact. -
Page 12: Chapter 4 Safety Devices
Chapter 4 SAFETY DEVICES WARM AIR BLOWER BREAKDOWN If the blower stops for any reason, the stove automatically shuts down to prevent overheating. FUME EXHAUSTER BREAKDOWN If the exhauster stops, the electronic unit immediately prevents pellet feeding. PELLET FEED MOTOR BREAKDOWN If the motor stops, the stove continues to operate until the minimum cooling level is reached. -
Page 13: Assembly And Installation Instructions
Chapter 5 Chapter 5 ASSEMBLY AND INSTALLATION INSTRUCTIONS The installation must comply with: UNI 10683 (2005) heat generators fed with wood and other solid fuels: installation. The chimneys must comply with: UNI 9731 (1990) chimneys: classifi cation according to thermal resistance. EN 13384-1 (2006) calculation method of the thermal and fl uid-dynamic features of the chimney. -
Page 14: Installation
Chapter 5 EXHAUST VENTING SYSTEM A system for fume exhaust venting that is independent from the appliance, composed of a pipe or channel, chimney or single fl ue, and chimney cap. FORCED DRAUGHT Air circulation by means of a fan driven by an electric motor. NATURAL DRAUGHT Draught resulting in a chimney/fl ue due to the diff erence in the volume mass existing between the (hot) fumes and the surrounding atmospheric air, without any mechanical suction aid installed inside or on top... -
Page 15: Connection To The Exhaust Venting System
Chapter 5 CONNECTION TO THE EXHAUST VENTING SYSTEM EXHAUST CHANNEL OR PIPE For the assembly of the exhaust channels it is imperative to use non-fl ammable materials that are resistant to combustion products and any condensates. It is forbidden to use fl exible metal pipes and asbestos cement for connecting the stove to the fl ue, also for pre- existing exhaust channels. -
Page 16: Chimney Or Single Flue
Chapter 5 the fl ue connection. It is forbidden to run other air feed channels or piping for utilities inside the exhaust channels, even if they are oversized. It is also forbidden to fi t manual draught adjustment devices on the forced draught appliance. - Page 17 Chapter 5 Windproof chimney cap < 3 m 3 - 5 % Flue Inspection Inspection fi gure 5.5 fi gure 5.6 < 3 m External insulated 45° duct Inspection 45° Inspection fi gure 5.7 fi gure 5.8 ASSEMBLY AND INSTALLATION INSTRUCTIONS...
-
Page 18: Connection To The Flue And Combustion Product Exhaust Venting
Chapter 5 CONNECTION TO THE FLUE AND COMBUSTION PRODUCT EXHAUST VENTING The fl ue must receive exhaust from a single heat generator. Direct discharge towards enclosed areas, even when roofl ess, is forbidden. Direct discharge of combustion products must take place on the roof and the exhaust duct must have the features set forth in the section “Chimney or single fl ue”. -
Page 19: Connection To External Air Intakes
Chapter 5 CHIMNEYS, DISTANCES AND POSITIONING Distance between the Minimum height of the chimney Roof pitch crown and the chimney (measured from the outlet) β A (m) H (m) < 1,85 0,50 m beyond the crown 15° > 1,85 1,00 m from the roof <... -
Page 20: Divina Plus Distributed Heating
Chapter 6 DIVINA PLUS DISTRIBUTED HEATING DIVINA PLUS The DIVINA PLUS model is equipped with two pipe outlets situated on the back of the stove that allow the heat produced by the stove to be distributed to other rooms. For this purpose, as you can see in the photo below, we recommend using pipes with the following characteristics: Internal diameter 80 mm Insulated pipes (thermal insulation) -
Page 21: Comfort Maxi Installation
Chapter 7 COMFORT MAXI INSTALLATION Adaptation layout The Maxi Comfort model is supplied with a metal sliding base that enables it to be installed in an existing fi replace. The base allows you to slide out the insert easily for maintenance and cleaning at the end of the year. -
Page 22: Installation With Pedestal (Optional)
Chapter 7 up to the base, connect the plug to the power socket and set the master switch on position 1: the display should come on. The bottom grill of the insert must stand at least 1 cm above the marble fi re top of the facing. -
Page 23: Extracting The Insert
Chapter 7 Adjust the height and angle of the hopper according to the fi replace to be built The bottom grill of the insert must stand at least 1 cm above the marble fi re top of the facing. EXTRACTING THE INSERT Maxi Comfort has to be extracted to carry out routine maintenance (cleaning the ash pipe at the end of the year) or special servicing (replacing mechanical parts in... -
Page 24: Recirculation Air Pipes
Chapter 7 RECIRCULATION AIR PIPES For the correct functioning, and so as to avoid any possible overheating to the apparatus, it is necessary to create a recirculation of air inside the structure which covers the insert. To guarantee this, it is suffi cient to create one or more openings, both in the lower and upper parts of the covering. - Page 25 Chapter 7 fi gure 7.12 fi gure 7.13 COMFORT MAXI INSTALLATION...
- Page 26 Chapter 7 Warm air of convection It is necessary to let the heat (accumulated inside the casing) go out. It must be done to avoid the superheating of the insert. 5 cm Forced ventilation The tangential fan blows in the room the warm air created in the insert.
- Page 27 Chapter 7 Air inlet box fi gure 7.15 Air inlet box fi gure 7.16 As far as the air inlet box is concerned, there is the possibility to connect the air inlet pipe above the sliding base (see picture above) or under it (see picture below) depending on the needs. All these operations must be carried out by a specialized technician.
-
Page 28: Falo' 1Xlp, Falo' 1Cp And Falo' 2Cp
Chapter 8 FALO’ 1XLP, FALO’ 1CP AND FALO’ 2CP As you can see in the photograph below, our FALO’ 1XLP, FALO’ 1CP and FALO’ 2CP models are provided with a convenient drawer for pellet feeding, so there is no need to disassemble any part of the stove to refi ll the pellets. -
Page 29: Product Functioning
Chapter 9 PRODUCT FUNCTIONING CONTROL PANEL REMOTE CONTROL SENSOR fi gure 9.1 REMOTE CONTROL SENSOR fi gure 9.2 ON/OFF BUTTON The stove can be turned on and off automatically by pressing button 1. AIR TEMPERATURE SETTING Buttons 2 and 3 are used to adjust the room temperature inside the house. OPERATING POWER Buttons 4 and 5 are used to adjust the heating power and warm air ventilation D1 Display for showing the various messages... -
Page 30: Current Time And Day Settings
Chapter 9 CURRENT TIME AND DAY SETTINGS Commands procedure Switch the stove off and on again using the master switch on the back of the stove. The following messages are shown: fi rst, the microchip version ( EXTRA_43 or later), then “TIME”, “LI 3”, and “OFF”. -
Page 31: Lighting
Chapter 9 LIGHTING Before proceeding, check to make sure that: the hopper is loaded the combustion chamber is clean the burn pot is clean the front door and the pellet drawer are closed the power outlet is connected the switch on the back of the stove is in position 1 Press button 1 for three seconds;... -
Page 32: Shutdown
Chapter 9 ATTENTION!!! The cover of the pellet container must always be kept closed except when loading fuel The sacks of pellets must be kept at least 1.5 metres away from the stove. The hopper should always be kept at least half full. Before refi lling, make sure that the appliance is switched off . -
Page 33: Remote Control (Optional "Rosy")
Chapter 10 Chapter 10 REMOTE CONTROL (OPTIONAL “ROSY“) The heat setting, the room temperature, and automatic start/stop of the stove can be remote controlled. S = Luminous warning light that indicates which keys have been pressed. Correspondence of display keys with remote control keys 1 = p3+p5 2 = p2... -
Page 34: Chapter 11 Room Thermostat
Chapter 11 ROOM THERMOSTAT DIGITAL THERMOSTAT (INCLUDED) The stove can control the room temperature by means of a digital thermostat whose function is to lower the heating power to the minimum when a pre-set temperature is reached. When the stove has been started and has entered normal operating mode, a number (e.g. 21°C ) appears on display D1 indicating the room temperature. -
Page 35: Mechanical Thermostat Operation For Heat Distribution Motor (Divina Plus Only)
Chapter 11 Thermostat with open contact the stove switches off or stays off , and display D1 shows “STBY”. This function can also be suspended temporarily by pressing button 1 for three seconds: If the stove is in “ STBY” phase, the stove remains off . -
Page 36: User Parameters
Chapter 12 Chapter 12 USER PARAMETERS USER PARAMETERS WEEKLY PROGRAMMER Display D1 Display D2 Function Start/Stop weekly programmer 00:00 Time of fi rst switch-on 00:00 Time of fi rst switch-off OFF 1 Consents for fi rst switch-on/switch-off for the various days Installer parameter 00:00 Time of second lighting... - Page 37 Chapter 12 Parameter Display D1 Adjustment Button to Function Display D2 buttons Indication confi rm Enable/disenable weekly programmer 2 o 3 ON/OFF Time of 1st switch-on 2 o 3 OFF or from 00:00 to 23:50 Time of 1st switch-off 2 o 3 OFF or from 00:00 to 23:50 Consents 1st switch-on/off for the various days 2 o 3...
- Page 38 Chapter 12 Press button 5 to confi rm and go to the next parameter. Press button 4 to go back to the previous one. Parameter 4 (D2 = 5, D1 =”00”) N.B. This parameter is reserved to the installer and must not be modifi ed. Parameter 5 (D2 = 5 (blinking), D1 =Ex.
-
Page 39: Day/Night Temperature Function
Chapter 12 Note: When the weekly programmer is on, the corresponding LED indicator on the control panel is on (see description of indicator lights). TO DISACTIVATE THE WEEKLY PROGRAMMER, enter the User Parameters by pressing button 3 and holding it, then pressing button 5. Display D2 shows a blinking “0”. Use button 2 or 3 to set “OFF” mode on display D1. -
Page 40: Pellet Feed Adjustment
Chapter 12 Summary table Display D1 Display D2 Function 06:00 Start day phase/end night phase 22:00 Start night phase/end day phase 25°C Day phase max. temperature 20°C Night phase max. temperature Once this function is active, it is still necessary to light the stove using button 1. When the stove switches off because the maximum temperature has been reached, the message “DOFF”... -
Page 41: Heat Distribution Motor Parameters
Chapter 12 The adjustment is made on a percentage basis, and therefore any change of this parameter leads to a proportional variation on all loading speeds of the stove. To access the percentage adjustment of pellet feeding, you have to enter the user programming by pressing button 3, and while keeping it pressed, press button 5. -
Page 42: Chapter 13 Stove Cleaning
Chapter 13 STOVE CLEANING ECOLOGICA – COMFORT MAXI Maintenance is necessary to ensure the correct operation of your stove over time. Failure to do so may make the stove unsafe. CLEANING THE BURN POT The burn pot must be cleaned every day. To do so: Remove the burn pot form its compartment and clean the holes using the poker provided (fi gure 13.1) Remove the ash from the burn pot using a vacuum... - Page 43 Chapter 13 CLEANING THE HEAT EXCHANGER (monthly) The heat exchangers chamber has to be cleaned once a month because the ash residue doesn’t let the stove work properly. To do this, it is necessary to remove the fi rewall: Remove the brazier from his frame Rotate the door latch of 180°...
-
Page 44: Bella - Bella Lux - Duchessa - Duchessa Steel - Contessa - Clementina - Divina - Divina Steel - Divina Plus - Tosca Plus Cleaning
Chapter 13 BELLA – BELLA LUX – DUCHESSA – DUCHESSA STEEL – CONTESSA – CLEMENTINA – DIVINA – DIVINA STEEL – DIVINA PLUS – TOSCA PLUS CLEANING Maintenance is necessary to ensure the correct operation of your stove over time. Failure to do so may make the stove unsafe. - Page 45 Chapter 13 CLEANING THE HEAT EXCHANGER (monthly) The heat exchangers chamber has to be cleaned once a month because the ash residue doesn’t let the stove work properly. To do this, it is necessary to remove the fi rewall: Remove the brazier from his frame Rotate the door latch of 180°...
-
Page 46: Pulizia Babyfiamma - Preziosa - Karolina - Isabella - Graziosa - Rosy
Chapter 13 PULIZIA BABYFIAMMA – PREZIOSA – KAROLINA – ISABELLA – GRAZIOSA – ROSY Maintenance is necessary to ensure the correct operation of your stove over time. Failure to do so may make the stove unsafe. BURN POT CLEANING The burn pot must be cleaned every day. To do so: Remove the burn pot form its compartment and clean the holes using the poker provided (fi gure 13.19) - Page 47 Chapter 13 CLEANING THE HEAT EXCHANGER (monthly) The heat exchangers chamber has to be cleaned once a month because the ash residue doesn’t let the stove work properly. To do this, it is necessary to remove the fi rewall: Remove the brazier from his frame Rotate the door latch of 180°...
-
Page 48: Falò 1Xlp - Falò 1Cp - Falò 2Cp - Esmeralda Cleaning
Chapter 13 FALÒ 1XLP – FALÒ 1CP – FALÒ 2CP – ESMERALDA CLEANING Maintenance is necessary to ensure the correct function of your stove over time. Failure to do so may make the device unsafe. CLEANING THE BURN POT The burn pot must be cleaned every day. To do so. Remove the burn pot form its compartment and clean the holes using the poker provided Remove the ash from the burn pot using a vacuum... - Page 49 Chapter 13 DOOR, ASH DRAWER AND BURN POT SEALS The seals ensure that the stove is hermetically sealed and consequently that it operates correctly. The seals should be checked periodically and replaced immediately if worn or damaged. These operations must be carried out by an authorized technician.
-
Page 50: Burn Pot Partition
Chapter 13 BURN POT PARTITION Some Extrafl ame products have a partition fi xed to the burn pot by a screw, which reduces the amount of carbon monoxide produced by the stove. fi gure 13.33 fi gure 13.34 Burn pot of: Bella – Bella Lux – Contessa – Duchessa – Divina – Burn pot of: Babyfi amma –... -
Page 51: Table Of Display Messages
Chapter 14 TABLE OF DISPLAY MESSAGES INDICATIONS Message Cause Solution Display When the stove has just been shut down (normal shutdown or caused by an alarm situation), you An attempt is made to switch on a stove again have to wait until it is completely cold and then ATTE when it has just been shut down (normal clean the burn pot. - Page 52 Chapter 14 ALARMS Message Cause Solution Display This indicator lights up when one of the alarms described below is in progress and is accompanied by the corresponding Indicates the presence of an alarm. indication on display D1. To reset the alarm, press button 1 and hold for three seconds when the stove is completely cold.
- Page 53 Chapter 14 INDICATOR LIGHTS LED indicator Meaning Description light It is switched on when the weekly programmer is active. Weekly Programmer function. For all settings relating to the following function, see “Weekly programmer” paragraph. This LED is on/off when the room temperature is lower/higher than the temperature set.
-
Page 54: Chapter 15 Warranty
Chapter 15 WARRANTY EXTRAFLAME S.p.A. is the owner of the rights described by Legislative Decree no. 24 of 2 February 2002, and the following warranty does not alter such rights. This warranty off ered by Extrafl ame S.p.A., based in Montecchio Precalcino (VI), Italy, in Via dell’Artigianato, 10, covers all the parts of the stoves supplied by Extrafl ame S.p.A., and includes repair or replacement, free... - Page 55 SERVICE UNDER WARRANTY The service request must be forwarded to the vendor. RESPONSIBILITY EXTRAFLAME S.p.A. shall not be liable for any direct or indirect damage caused by or depending on the product. COMPETENT COURT For any controversy, the competent court shall be the court of Vicenza, Italy.
-
Page 56: Chapter 16 Quality Control
Chapter 16 QUALITY CONTROL Document that must be kept and produced if interventions under warranty are requested Name Surname Address Postal code Town/City County Telephone Model Serial number Vendor Date of purchase IMPORTANT: I accept I do not accept Notice as per Law 196/2003 – Your personal data are treated by our company in full respect for Italian Law 196/2003 for the entire duration of the contractual relationships established and also thereafter for the fulfi lment of all legal obligations as well as to carry out eff ective management of the commercial relationships. - Page 57 Notes...
- Page 58 Notes...
- Page 59 Notes...
- Page 60 Stufe a Pellet EXTRAFLAME S.p.A. Via Dell’Artigianato, 10 36030 MONTECCHIO PRECALCINO Vicenza - ITALY Tel. 0445/865911 Fax 0445/865912 http://www.lanordica-extraflame.com E-mail: info@extraflame.com This document is available at www.extraflame.it/support 004275259 - INGLESE Manuale utente ventilate REV 017 04.03.2009...
Need help?
Do you have a question about the Babyfiamma and is the answer not in the manual?
Questions and answers
Display shows 'no pell' but hopper has plenty
The Extraflame Babyfiamma stove displays 'NO PELL' when there are no pellets being fed into the burn pot, even if the hopper is full. This could be due to a blockage in the pellet feed system, a malfunction in the auger mechanism, or an issue with the pellet sensor. Additionally, there may still be some unburned pellets in the burn pot when this alarm is triggered. Checking for obstructions and ensuring proper pellet feed operation can help resolve the issue.
This answer is automatically generated
