- Page 1 MaNuaL Lucia MADE ITALY design & production 004277341 - Rev 003...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
SafEty ..........................................5 routINE MaINtENaNcE ....................................7 INStaLLatIoN ........................................8 MINIMUM DISTANCES .............................................. 8 PREPARATIONS FOR MAINTENANCE ........................................8 DEtaILS LucIa ....................................... 10 PoSItIoNING tHE StovE ..................................... 11 NotES for corrEct oPEratIoN ................................11 FUSE ....................................................11 PELLEtS aND LoaDING ....................................12 PELLEt HoPPEr - PrESSurISED cLoSurE. - Page 4 ATENÇÃO - OBrIgATÓrIO ATTENZIONE TASSATIVO ANTES dE mOVImENTAr A SAlAmANdrA, rE- PrImA dI mOVImENTArE lA STufA TOglIErE lE TIrAr AS cErâmIcAS INdIcAdAS PArA EVITAr mAIOlIchE INdIcATE PEr EVITArE dANNI. dANOS. ATTENTION - cOmPulSOrY TÄhElEPANu! BEfOrE mOVINg ThE STOVE, kINdlY TAkE ThE ENNE Ahju lIIguTAmIST EEmAldAgE SEllElT cErAmIcS Off IN OrdEr TO NÄIdATud kErAAmIlISEd OSAd, ET VÄlTIdA...
-
Page 5: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner... - Page 6 CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY. Š THE CLEANING AND MAINTENANCE REQUIRED BY THE USER MUST NOT BE PERFORMED BY CHILDREN WITHOUT SUPERVISION.
-
Page 7: Routine Maintenance
SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE. Š THIS APPLIANCE MUST NOT BE USED TO BURN WASTE Š DO NOT USE ANY FLAMMABLE LIQUIDS FOR IGNITION Š... -
Page 8: Installation
InstallatIOn general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... - Page 9 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
-
Page 10: Details Lucia
DEtAIls lUCIA Room air output Fumes exhaust Serial input Access to combustion chamber Additional thermostat Combustion air inlet and ash drawer TA input On/Off Touch screen display Fuse Room probe Pressure closing pellet hopper Power supply 230 V ENGLISH... -
Page 11: Positioning The Stove
posItIoNING tHE stovE For the correct operation of the product, we recommend positioning it on a perfectly flat surface. Use a spirit level to check this. NotEs For CorrECt opErAtIoN Pellet hopper lid For the correct operation of the pellet stove, the following indications must be respected: Both during the functioning and when the stove is not in use, all the machine doors (pellet hopper, fire door, ash drawer) must... -
Page 12: Pellets And Loading
Pellets and loading Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignite. -
Page 13: Remote Control
Remote contRol The remote control can be used to adjust the main stove functions. Transmitter Select air mode Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch- off delay. -
Page 14: Remote Control Icons
Remote contRol Icons Air mode selected: Enable chrono Flashing COMFORT Light on = activated On AUTO Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level. -
Page 15: Touch Screen Display
TOUCH SCREEN DISPLAY The stove is equipped with a modern touch screen display with WiFi technology that allows for the individual functions of the unit to be adjusted by the user in an easy and intuitive manner. Touch the buttons (icons) on the display to activate the actions. The touch screen display reacts with the touch of you fingers. WARNINg! Š... -
Page 16: Control Panel
CONTROL PANEL DispLAy oF The vArious TexT messAges on/off stove. increase operating power / scroll through the menus. Decrease operating power / scroll through the menus. increase operating set thermostat / scroll through the menus. Decrease operating set thermostat / scroll through the menus. To access the menu / confirm key. -
Page 17: Main Menu
MAIN MENU Back - exit scroll through parameters: next (3); previous (2) change settings data: increase (4); decrease (5) confirm - access menu FRONT AIR EASY SETUP CHRONO ENABLING PRG1 PRG2 SETTINGS DATE-TIME PRG3 LANGUAGE PRG4 DISPLAY STAND-BY DELTA T FIRST LOAD DEGREES WIFI... -
Page 18: Settings For First Use
SETTINgS fOR fIRST USE After connecting the power cord at the back of the stove, turn the switch located at the back to position (I). The switch at the back of the stove is used to power the generator board. The stove will remain off and the word OFF will appear on the panel. -
Page 19: Operation And Logic
OPERATION AND LOgIC IgNITION After checking the previous points, press the 1 for three seconds to switch on the stove. For the ignition phase, 15 minutes are available during which the presence of the flame is checked. When the control temperature has been reached, the stove stops the ignition phase and goes into prepArATion. -
Page 20: Front Air
fRONT AIR This menu allows you to set the front air motor speed. range: (comfort, auto). if you select comfort mode, the front air speed is reduced To ensure combustion efficiency, the front air is excluded when the product is at the minimum power. conTroLs proceDure Š... -
Page 21: Chrono
CHRONO This function allows you to program the stove to switch on and off automatically. The factory setting for CHRONO is off. The chrono allows you to program 4 time slots within a day to be used for every day of the week. In each time slot, it is possible to set the ignition and switch-off times, the days of use of the programmed time slot, the desired temperature and the set power. - Page 22 EXAMPLE OF TIMER WITH OVERLAPPING TIME SLOTS TIME SLOT 02:00 08:00 16:30 23:00 SET POWER 02:00 08:00 16:30 23:00 SET THERMOSTAT 22° 18° 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 power 3 - seT ThermosTAT 22°c stop 23:00 start 08:00 Time slot 2 power 1 - seT ThermosTAT 18°c...
-
Page 23: Settings
SETTINgS • DATE-TIME • LANgUAgE See chapter: SettingS for firSt uSe • DEgREES DISPLAY This menu allows you to adjust the brightness of the display. The possible values go from oFF, 1 to 20. if oFF, the display backlight is at the maximum intensity and goes out after a 60 second delay. -
Page 24: Additional Thermostat
ADDITIONAL THERMOSTAT N.b. : THE INSTALLATION MUST bE PERfORMED bY AN AUTHORISED TECHNICIAN There is a possibility to thermostat a room adjacent to the room where the stove has been placed; simply connect a thermostat following the procedure described in the following section (it is advisable to place the optional mechanical thermostat at a heigh from the ground equal to 1.50 m). -
Page 25: Wi-Fi
WI-fI The display allows internet connection using Wi-Fi technology. This allows remote management and control of the stove using the dedicated App for smartphones, “TotalControl 2.0” (Apple store / play store). ATTENTION DOWNLOAD: The Wi-Fi network can be configured directly from the display using the following procedure (home network "TOTAL CONTROL 2.0"... -
Page 26: Cleaning And Maintenance
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions in Complete safety! Š Make sure that the power cord plug is disconnected as the generator may have been programmed to turn on. - Page 27 burn pot and Combustion Chamber: Š Vacuum the residues in the burn pot Š Remove the burn pot completely from its compartment; Š Vacuum the ash from the burn pot seat, glow plug tube and combustion chamber. Š Clear all the holes in the burn pot using the special tool supplied.
-
Page 28: Routine Maintenance Performed By Qualified Technicians
BURN POT HOLES TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe performed by Qualified teChniCians routine maintenance must be performed at least once a year. Using pellets as solid fuel, the generator requires annual routine maintenance, which must be performed by a qualified technician, using only original spare parts. - Page 29 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Seals, pallet hopper, inspections, ash drawer and door (replace and apply silicone where required) Combustion chamber &...
- Page 30 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Seals, pallet hopper, inspections, ash drawer and door (replace and apply silicone where required) Combustion chamber &...
-
Page 31: Displays
Displays Display Reason Generator off sTaRT The START phase is in progress pelleT loaDinG Continuous pellet loading is in progress during the ignition phase The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress MoDulaTion The generator is operating at the minimum speed final cleaninG... -
Page 32: Guarantee Terms
EXTRAFLAME S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website. -
Page 33: Disposal
AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating. - Page 34 ENGLISH...
- Page 35 ENGLISH...
- Page 36 ExtraflamE S.p.a. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
