2.5in Tool-less USB 2.0 to IDE SATA Hard
Drive Enclosure
UNI2510U2V
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 01/31/2013
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNI2510U2V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for StarTech.com UNI2510U2V

  • Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/31/2013...
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
  • Page 3: Table Of Contents

    Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................2 Hardware Installation ..........................2 Driver Installation ............................4 Using the Storage Device ..............4 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual...
  • Page 4: Introduction

    Introduction The StarTech.com hybrid 2.5” USB 2.0 to IDE/SATA Hard Drive Enclosure lets you turn almost any 2.5” laptop hard drive into a portable storage device. Compatible with both IDE or SATA (1.5/3.0Gbps) hard drives, the enclosure offers a cost-effective and convenient choice for a variety of uses including data backups, extra data storage, or simply putting an “outdated”...
  • Page 5: Installation

    Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation 1. Slide the latch on the bottom of the enclosure to release the top cover. 2.
  • Page 6 4. Place the 2.5” hard drive into the drive tray and slide it into the connector firmly. If using an IDE hard drive, the connector is located towards the front of the drive tray, while the SATA drive connectors are located towards the rear of the drive tray. 5.
  • Page 7: Driver Installation

    Driver Installation Windows 2000/XP/Vista/7, Mac OS 9.2+, and Linux No driver installation is required for these operating systems, as this enclosure is natively supported, so the drivers are already installed. Using the Storage Device Windows 2000/XP/Server 2003/Vista/7/Server 2008 If you are using a brand new hard drive that does not contain any data, then you will first need to prepare the hard drive for use.
  • Page 8 The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting up the drive. Once complete, the Disk should show up as “Healthy” with a drive letter assigned (i.e. E:). This drive letter should now appear within My Computer. If you are installing a hard drive that already has data on it, then after plugging it in, the drive should automatically show up with a drive letter assigned within My Computer.
  • Page 9: Specifications

    Specifications Bus Interface USB 2.0 Connectors 1 x USB mini-B Chipset ID JMicron JM20337 LEDs 1 x Power/Activity Maximum Data Transfer Rate USB 2.0: 480Mbps Compatible Hard Drives 2.5” EIDE or SATA 1.5/3.0Gbps, 9.5mm height Power Adapter Dimensions 133.0mm x 78.0mm x 19.0mm Weight 130g Windows 2000/XP/Server 2003/Vista/7/Server...
  • Page 10: Technical Support

    Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
