8600 Series Mobile Computer
Warning! The contents of the data memory (SRAM) will be wiped out after test.

3.3.6 ECHO TEST

After a physical connection is established properly, run a test utility on your computer
and start the test on your mobile computer. Select a desired baud rate if necessary.
To stop and exit the test, press [ESC].
Interface Description
RS-232 This echo test is to verify connectivity via the RS-232 cable
between the mobile computer and a host computer.
Fast VPort This echo test is to verify the connectivity via the Fast VPort
cable between the mobile computer and a host computer.
USB This echo test is to verify connectivity via the USB cable
between the mobile computer and a host computer.
USB VCOM Echo — The mobile computer works as a
generic USB device.
USB HID — The mobile computer works as an input
device; select keyboard type and Caps Lock status for
running a test.
USB VCOM_CDC Echo — The mobile computer works as
a generic USB device.

3.3.7 VIBRATOR

Select this item to test the vibrator.
To stop and exit the test, press [ESC].

3.3.8 RFID

Select this item to test the RFID Reader.
Press [ESC] to exit.

3.3.9 GPS

Select this item to test the GPS receiver of the device.
Received Information
Latitude
Longit.
Speed
Altitude
48
Reference Manual
Description
Displays the latitude where the device is located.
Displays the longitude where the device is located.
Displays the moving speed in kilometers per hour.
Displays the altitude in meters.
Test Utility
EchoTest.exe
EchoTest.exe
EchoTest.exe for
Virtual COM
Any text editor for
HID
EchoTest.exe for
Virtual COM
