8000 Series Mobile Computer

3.3.6 ECHO TEST

After a physical connection is established properly, run a test utility on your computer
and start the test on your mobile computer. Select a desired baud rate if necessary.
To stop and exit the test, press [ESC].
Interface Description
IR (Cradle-IR) This echo test is to verify connectivity via IR between the
mobile computer and any cradle.
Modem This echo test is to verify connectivity via the Modem
Cradle. A telephone line must be connected to the Modem
Cradle.
Note: For the Modem Cradle, any value other than 57600 bps (default) must be
configured through the DIP switch on the IR control board.
34
Reference Manual
Test Utility
EchoTest.exe
EchoTest.exe
