IS09 ECN2087
• Connection of the appliance to the water supply must also allow for reasonable service access
unless the appliance is situated in high-risk areas.

Overflow and Drainage

• The overflow from the tank is connected via a flexible tube to a vent port mounted internally
of the appliance.
• The primary function of this feature is to capture the small amounts of condensed steam
produced during normal operation of the appliance.
• In the unlikely event of an overflow occurrence the spillage tray has a limited capacity and
should not be deemed as a safeguard against overflow.
• As an option the flexible tube can be removed from the lower internal vent and redirected
through the base to a suitable drainage system.
• The drainage system to which the flexible tube is to be connected must have a continuous fall
and have a greater diameter than that of the flexible tube. Alternatively, the flexible tube can
be directed to a gully where no risk of contact with hot water by persons using the building
can be considered as a means of safe drainage.
• The flexible tube must not be connected directly to a soil system.
• The tube from the overflow must remain connected to the overflow on the tank.
• The overflow tube must never become blocked or restricted in any way.

Electricity Supply

All appliances must be earthed.
The EB3 model is supplied with a 3 pin bonded plug and lead fitted with a 13Amp fuse as
standard. The plug is to be connected to a suitable mains socket. The wiring markings are as
follows: -
LIVE wire colour BROWN with terminal marked L
NEUTRAL wire colour BLUE with terminal marked N
EARTH wire colour GREEN/YELLOW with terminal marked E or
All appliances with an electrical loading of over 3kW must be connected to the supply by a
qualified electrician in accordance with Health & Safety at Works Act, IEE regulations, BS codes
of practice, Building Standards, Local Authority and Building regulations etc. A suitable means
of disconnecting such units from the supply must be provided, having at least 3mm contact
separation at all poles.
The EB4 model should be wired to at least a 20Amp single-phase supply via an isolation switch.
The isolation switch must be so positioned for immediate access in case of emergency shut down.
The EB6 model should be wired to at least a 30Amp single phase or multi-phase supply via an
isolation switch. The isolation switch must be so positioned for immediate access in case of
emergency shut down.
• To wire the EB4 and EB6 models remove the access panel at the rear of the appliance.
• Remove the TEST WIRES from the terminal block and cable gland.
• For EB6 models to be wired from a multi-phase supply remove the LINK wire from the
terminal block.
• Introduce the new cable from the isolation switch to the appliance via the cable gland and
wire to the terminal block as follows:-
8
