Installation, Operating and Servicing
Instructions
Water boiler and chiller - EB3FX/HC
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS637 ECN 3846
Page 1 of 12
Advertisement
Table of Contents
Related Manuals for Lincat EB3FX/HC
Summary of Contents for Lincat EB3FX/HC
- Page 1 Installation, Operating and Servicing Instructions Water boiler and chiller - EB3FX/HC Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS637 ECN 3846 Page 1 of 12...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person with the installation instructions for the appliance and in accordance with national and local regulations in force in the country of installation. This appliance is intended for indoor use only and should never be installed outdoors or exposed to the elements of nature. -
Page 4: Technical Data
TECHNICAL DATA EB3FX/HC Height (mm) Width (mm) Depth (mm) Weight (kg) Power rating(kW) Current rating (A) CHECK LIST OF ENCLOSURES Warranty card Instructions manual Drip tray Drip tray insert Connection hose Silicone drain hose assembly IS637 ECN 3846 Page 4 of 12... -
Page 5: Installation And Commissioning
Ambient air temperature shall be between 16 C and 32 Electrical supply The EB3FX/HC is supplied with a 13 amp plug to BS1363. Water supply connection Connect the supplied white water inlet hose to the inlet connection point on the base of the boiler and the other end to the mains supply via an accessible isolating tap with a ¾”... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS General arrangement Drain pipe Touchscreen display Drip tray Dispense tap cold Mains power lead Dispense tap hot Water inlet point Serial plate location Side condenser air vent Water filter Pressure reducing valve Hot tank drain valve Dip stick Vent pipe Only qualified or trained personnel should use this appliance. - Page 7 Twist the base of the filter (E) 90 degrees to the left and lower the cartridge out of the appliance. It will contain a small amount of water. Only use a genuine Lincat Filter. Insert the new filter into the recess and lock in place by twisting to the right.
-
Page 8: Wiring Diagram/Spares List
F10-Chiller condenser over heat: This could be due to condenser fan not working, condenser air outlet blocked or condenser blocked. F11-Chiller- clean condenser: This is a regular periodic warning to ensure the condenser fins are not blocked that should be kept clean to ensure optimum operation of cooler water cooling system. -
Page 9: Cleaning
1mm thick the tank should be de-scaled. The de-scale routine takes about an hour to complete and the boiler cannot be used during the routine. Lincat offer a purpose designed de-scaler powder, part number DP10 that can be used should you require it. IS637 ECN 3846... -
Page 10: Maintenance And Component Replacement
Please refer to the Service Help Desk number on the final page of this manual. SPARE PARTS LIST For spare parts for your water boiler/chiller please contact the Lincat Spares department on 01522-875510. Refer to the serial plate for the model and serial number of your water boiler, as this will help us quickly identify the part you require. -
Page 11: Service Information And Guarantee
