Installation, Operating and Servicing
Instructions
Electric Auto-Fill Push Button Water Boilers
EB3F/PB and EB3F/PBM
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS425 ECN 3607
Page 1 of 13
Advertisement
Table of Contents
Related Manuals for Lincat EB3F/PB
Summary of Contents for Lincat EB3F/PB
- Page 1 Installation, Operating and Servicing Instructions Electric Auto-Fill Push Button Water Boilers EB3F/PB and EB3F/PBM Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS425 ECN 3607 Page 1 of 13...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
Disconnect this appliance before servicing, maintenance or cleaning. TECHNICAL DATA Model Height (mm) Width (mm) Depth (mm) Weight (kg) EB3F/PB 13.0 CHECK LIST OF ENCLOSURES Warranty card Instructions manual Drip tray and insert Inlet hose with ¾” BSP connection FilterFlow badge... - Page 4 5 to 30 1 to 8 100 to 800 The EB3F/PB is supplied with a 13 amp plug. Water supply and waste connection Connect the supplied white water inlet hose to the inlet connection point on the base of the boiler and the other end to the supply via an accessible isolating tap with a ¾”...
-
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Fig 1 IS425 ECN 3607 Page 5 of 13... - Page 6 First Use Only qualified or trained personnel should use this appliance. Switch on the water and electricity supplies. Leave the boiler to fill for 30 minutes. Drain off approximately 5 litres of water to remove any loose carbon particles from the filter.
- Page 7 EB3F/PBM PROGRAMMING GUIDE The PBM version of the EB3F has the option to preset upto 3 measured dispense sizes. This quick guide shows the procedure for programming the water boiler. The measured dispense can only be set when the unit is full and upto temperature. So connect the unit to the water supply and electric, allow 30 minutes for the unit to fill and heat.
- Page 8 Re-insert the filter into the recess and lock into place by twisting to the right. Refit the lower panel. For EB3F/PB, hold the Fn button for 10 seconds to reset the filter life. For EB3F/PBM hold the Fn and On/Off buttons down simultaneously for 10 seconds.
-
Page 9: Cleaning
De-scaling the boiler at the end of the working day gives the de-scaling agent several hours to work. Lincat recommend our own de-scaling agent MS19, available from our Spares department. Wear protective clothing. -
Page 10: Servicing, Maintenance And Component Replacement
Remove the drip tray, lower panel, silicone dispense hose and the inner cover. Connect a hose from the overflow pipe to a bucket and open the service valve to drain the water from the tank. Flush the tank with clean water, shut the valve and replace the covers. Replace the drip tray and tank lid, ensuring the gasket is sealing the top of the tank correctly. -
Page 11: Spare Parts List
NOT HEATING FILTER Boil dry/overheat protector Check connections tripped Call service if fault persists CAUTION Temperature sensor fault SEE MANUAL Element failed PCB fault Faulty or loose connection STANDBY CLEAR THERMISTOR FILTER Temperature sensor fault Call service CAUTION SEE MANUAL STANDBY SPARE PARTS LIST Part Number... -
Page 12: Accessories
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. IS425 ECN 3607... - Page 13 GUARANTEE This unit carries a comprehensive UK mainland twelve month/2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights. The guarantee does not cover: Accidental damage, misuse or use not in accordance with the manufacturer‟s instructions ...
