Installation, Operating and Servicing
Instructions
Waterboiler EB3FX, EB4FX, EB6FX,
EB6TFX, EB3FX/PB AND EB3FX/TT
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS590 ECN 3846
Page 1 of 12
Advertisement
Table of Contents
Related Manuals for Lincat EB3FX
Summary of Contents for Lincat EB3FX
- Page 1 Installation, Operating and Servicing Instructions Waterboiler EB3FX, EB4FX, EB6FX, EB6TFX, EB3FX/PB AND EB3FX/TT Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS590 ECN 3846 Page 1 of 12...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
Ensure that the plug/socket is accessible at all times. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. Disconnect this appliance before servicing, maintenance or cleaning. TECHNICAL DATA EB3FX EB4FX EB6FX EB6TFX EB3FX/PB... -
Page 4: Installation And Commissioning
Inlet water pressure should be between 2 and 6 bar. (0.2MPa to 0.6MPa) Ambient air temperature shall be between 5 and 30 deg C Electrical supply The EB3FX series are supplied with a 13 amp plug to BS1363. The EB4FX is supplied with a bulkhead cable connector. Connect a 2.5mm 3 core cable. -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS General arrangement Tank Cap Touchscreen display Dispense tap Serial plate location Water filter Lower drain valve (below slide down cover) Drip tray Only qualified or trained personnel should use this appliance. First Use Switch on the water and electricity supplies. Leave the boiler to fill for 30 minutes. New filters have a small amount of loose, harmless, carbon particles. - Page 6 Touchscreen display configuration Pressing allows Power button On, off, Timed and ECO modes Timed operation Access to timer settings ECO operation Access to ECO options Clock Access to clock settings Ready, Wait Clock, descale, PIN lock and temperature Element on Filter life icon Reset filter life after replacement Water in...
- Page 7 A master PIN code is available from Lincat Service should you forget the user set PIN. Filter Replacement The filter display shows the estimated life remaining in the filter cartridge.
-
Page 8: Cleaning
The de-scale routine takes about an hour to complete and the boiler cannot be used during the routine. Lincat offer a purpose designed de-scaler powder, part number DP10 that should be used. If there is a fault with the unit it will not be possible to de-scale the unit using the in- built programme. -
Page 9: Maintenance And Component Replacement
Please refer to the Service Help Desk number on the final page of this manual. SPARE PARTS LIST For spare parts for your waterboiler please contact the Lincat Spares department on 01522-875510. Refer to the serial plate for the model and serial number of your waterboiler, as this will help us quickly identify the part you require. -
Page 10: Service Information And Guarantee
Type number • Serial number • Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. - Page 11 Service calls to equipment under warranty will be carried out in accordance with the conditions of sale. Unless otherwise specified, a maximum of 15 minutes of administrative time, not spent directly carrying out servicing work, is provided for within the warranty. Any requirement for staff attending the call to spend greater time than 15 minutes due to administrative requirements, such as on health and safety risk assessments, will be chargeable at the prevailing rate.
- Page 12 This page intentionally blank IS590 ECN 3846 Page 12 of 12...
