Installation, Operating and Servicing
Instructions
Wall Mounted Water Boiler
M3F, M5F AND M7F
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 713 ECN 4386
Page 1 of 11
Advertisement
Table of Contents
Related Manuals for Lincat M7F
Summary of Contents for Lincat M7F
- Page 1 Installation, Operating and Servicing Instructions Wall Mounted Water Boiler M3F, M5F AND M7F Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 713 ECN 4386 Page 1 of 11...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This appliance must be earthed. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. -
Page 5: Operating Instructions
Hang the unit onto the bracket and mark the position of the lower fixing screw on the underside of the unit. Remove the boiler and drill the hole and insert suitable wall plug. The water boiler is now ready to mount and connect services. Please allow 200mm clear space above the unit to allow removal of the cover and 300mm below the unit to allow for filter removal. - Page 6 New filters have a small amount of loose, harmless, carbon particles. Drain off approximately 3 litres of water when first setting up or replacing filter. Regular operation The appliance starts automatically shortly after the electrical supply is turned on, filling with water and heating. The unit will display ‘Wait’...
- Page 7 The backlight adjustment screen is displayed next. Press the power button to cycle through the values 1 to 25. Press the Set button to select the required value. The contrast adjustment screen is displayed next. Press the power button to cycle through the values 35 to 60.
-
Page 8: Cleaning
De-scaling the boiler at the end of the working day gives the de-scaling agent several hours to work. Lincat recommend our own de-scaling agent DP10, available from our Spares department. Wear protective clothing. -
Page 9: Servicing, Maintenance And Component Replacement
FAULT Water pressure too high or Clear fault code SEE MANUAL pressing Set button Drain valve open Filter blocked or not fitted Call Lincat if fault STANDBY CLEAR persists Boil dry/overheat protector Try overflow temp reset FILTER NOT HEATING... -
Page 10: Spare Parts List
TH123 90 Deg cutout TH88 120 Deg cutout TH98 Thermistor WL02 Sensor loom ACCESSORIES Part Number Description DR94 M3F Drip tray DR95 M5F & M7F Drip tray FC04 Filter cartridge DP10 De-scaler IS 713 ECN 4386 Page 10 of 11... -
Page 11: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
