9
Mounting plate
Wire connectors
Switch
housing
Fig. 18
11. INSTALLING THE SWITCH HOUSING
Step 1. While holding the switch housing under
your ceiling fan, push the square wire
connectors together. One from the fan and one
from the switch housing.
NOTE: These connectors are color coded and
will ONLY engage when the colored strips are
matched (aligned).
Step 2. Carefully push all the wires into the
switch housing.
Attach the switch housing to the mounting
plate with the screws provided. Make sure
Screws
each screw is tight. (Fig. 18)
