Adjusting Transformer Seat Height

NOTE: For this procedure, refer to FIGURE 6.3 on page 60

Adjusting Front Seat Height

1. Note the order of the mounting screw, coved washers, spacer, half clamps and
mounting screw/threaded sleeve and their position on the wheelchair frame and
footrest tubing (Detail ʺAʺ, FIGURE 6.3).
2. Remove the mounting screw, coved washers, spacer, half clamps and mounting
screw/threaded sleeve on both sides of the wheelchair.
NOTE: The footrest tubing will slide once the hardware is removed.
3. Raise/lower the front of the seat to the desired position.
4. Adjust the footrest height if desired. Refer to Adjusting the X‐terminator and
Transformer Footrests on page 64.
5. Align the footrest tubing adjustment holes with the desired wheelchair frame
adjustment holes.
6. Install the hardware removed in STEP 2 through the adjustment holes aligned in STEP 5.
7. Securely tighten all hardware.

Adjusting Rear Seat Height

1. Loosen the two mounting screws on both sides of the front of the wheelchair
(Detail ʺAʺ).
2. Loosen the four adjustment screws on both sides of the rear of the wheelchair
(Detail ʺBʺ).
3. Adjust seat higher or lower to desired position. Use a tape measure or ruler to ensure
that both sides are the same height.
4. Securely tighten the four adjustment screws at the rear of the wheelchair and the two
mounting screws at the front of the wheelchair.
