5. Stand behind the wheelchair and perform the following:
A. Slide anchor loop section of adjustable tension back upholstery up onto the left
back post with the upper grommet hole facing the rear of the wheelchair.
B. Slide adjuster strap section of adjustable tension back upholstery up onto the right
back post with the upper grommet hole facing the rear of the wheelchair.
6. Align the mounting hole in each back post with the desired mounting hole in each
back upright.
NOTE: Both back posts should be adjusted to the same height.
7. Install the two back height adjustment screws through the back upright mounting
holes determined in STEP 6 and the back post mounting holes.
8. Slip adjuster straps through corresponding anchor loops and adjust the back
upholstery. Secure with the fastening straps.
After the adjustable tension back upholstery has been positioned to the end-users
individual needs, the fastening straps MUST be securely fastened BEFORE applying
the back upholstery cover. The adjustable back should be checked whenever enter-
ing the wheelchair to ensure that the fastening straps are securely fastened.
9. Secure the back upholstery cover (fastening strap) to the back of the adjustable back
upholstery (fastening strap).
10. Flip the back upholstery cover over the adjustable back upholstery and secure the
fastening straps to the front of the adjustable back upholstery.
11. Lay the front portion of the back upholstery cover on the seat pan.
12. Adjust the slack in the back upholstery cover and then secure to the seat pan fastening
straps.

Back Height Adjustment (Adjustable Backs Only)

NOTE: For this procedure, refer to FIGURE 4.5 on page 34
NOTE: Observe the tautness of the back upholstery for reinstallation.
1. Unlatch the two fastening flaps that secure the top of the back upholstery to the back
posts and remove from the back posts.
Push pin MUST be protruding through hole in back post.
Ensure that both back post inserts are at the same height BEFORE reassembling
the wheelchair.
2. Press the push pin on the back post insert tube in and adjust the back height to one of
four heights depending on original back height:
Part No 1122172
WARNING
WARNING
33
Everyday and Sport Series Wheelchairs
SECTION 4—BACK
