Casio QT-2100 Service Manual page 49

[ 13 ] Printer test
This test will check the print test for printer.
Operation : x1 x2 x3
X1 : Display test pattern
0 = A pattern 1 = B pattern
X2 : Port selection
1 = COM1
5 = COM5
X3 : Baud rate selection
1 = 4800 bps 2 = 9600 bps 3 = 19.2 kbps
n : 0 = One time check
Not 0 = Continuous check (To stop the test, press "Esc" key)
d : Printer type selection
1 = RJ
SLIP SP-1300
RJ UP250/350
SA3015
TM-U300
IDP-3541
CBM-231
[ LCD ]
(When the RJ printer is selected)
PRT xxxn03d
END xxxn03d
Note : Printing pattern is the following 2types.
1234567890123456789012345678901234567890
BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
A Pattern
Note : SLIP = 35 character
RJ = 40 character
n 0 3 d SUBTOTAL
2 = COM2 3 = COM3
6 = COM6
2 = SLIP
[ PRINTER SPEC ]
19.2 kbps 9600 bps
NG
OK
NG
NG
NG
OK
Note : The following error the printer without being con-
NON PRINTER ERR
[ PRINT ]
— 47 —
4 = COM4
4800 bps
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
nected.
1234567890123456789012345678901234567890
BBBBBBBBBBBBBBBBBBBBB
B Pattern
*8,888.88
