510-Series Camera
Speed Dome

User Manual

CM-510
XM5000
model no.
model no.
Please carefully read these instructions before using this product.
28583AA
Save this manual for future use.

Advertisement

Table of Contents
loading

Summary of Contents for OpenEye CM-510

  • Page 1: User Manual

    510-Series Camera Speed Dome User Manual CM-510 XM5000 model no. model no. Please carefully read these instructions before using this product. 28583AA Save this manual for future use.
  • Page 2 28583AA...
  • Page 3 THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL OPENEYE BE LIABLE FOR ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE, OR OTHER DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION,...
  • Page 4: Important Safeguards

    Important Safeguards Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.
  • Page 5 REGULATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.
  • Page 6: Explanation Of Graphical Symbols

    WARNING DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 7: Standard Warranty

    Standard Warranty Openeye warrants all products to be free from defects in workmanship and material under normal use for a period of one year after the date of purchase. Any defective product that falls under this warranty will, at OpenEye's discretion, be repaired or replaced at no additional charge.
  • Page 8 NOTES: viii 28583AA...
  • Page 9: Table Of Contents

    Table of Contents INTRODUCTION ....................1 OVERVIEW ........................... 1 Product Features ........................1 GENERAL OPERATION REQUIREMENTS ................. 2 System Configuration ........................ 2 GETTING STARTED ..................... 5 CAMERA CONTENTS ........................5 CAMERA SETTINGS ........................6 Switch Definition ........................6 Communication Switch Setting ....................6 Dome ID Setting ........................
  • Page 10 Running a Preset ........................ 21 Exit the Preset Menu ......................21 Tour ............................21 Autoscan ..........................22 Pattern ............................ 23 Home Setting .......................... 24 IR Function (removeable IR Cut) .................... 25 Alarm Setting .......................... 25 WDR Function ........................26 Privacy Mask .......................... 27 Time Setting ..........................
  • Page 11 28583AA...
  • Page 12 28583AA...
  • Page 13: Introduction

    INTRODUCTION OVERVIEW With a weather resistant feature, the Integrated High Speed Dome Camera is applicable to outdoor installations. The dome camera supports all-in-one cabling for easy installation and can be integrated with CCTV products, such as DVRs, Control Keyboards, and CCTV accessories for a total surveillance solution.
  • Page 14: General Operation Requirements

    SYSTEM CONFIGURATION NOTE: To extend the network distance up to 1.2 km (4000 feet) and to protect the connected devices, OpenEye recommends placing a repeater at the mid-point. However, a repeater may be needed with network distances less than 1.2 km if the cables used are not CAT 5, 24-gauge cables.
  • Page 15 NOTES: 28583AA...
  • Page 16 NOTES: 28583AA...
  • Page 17: Getting Started

    13 pin Alarm Cable Waterproof Gasket 510-Series Camera Speed Dome Installation Manual XM5000 CM-510 model no. model no. Please carefully read these instructions before using this product. Save this manual for future use. Quick Start Guide Installation and User Manuals...
  • Page 18: Camera Settings

    CAMERA SETTINGS SWITCH DEFINITION The dome ID and communication switch settings must be set before connecting the dome camera to other CCTV devices. These switches are located on the bottom of the dome camera. Dome Control Protocol Switch Communication Switch ISP Connector (for firmware upgrade) Reserved...
  • Page 19: Dome Id Setting

    DOME ID SETTING Use the switch to change your speed dome ID by turning the arrow to the desired number. For instance, if the dome ID is 123, the ID switch should be set as below. Centesimal Digit Decimal Digit Single Digit NOTE: No two domes should have the same ID or communication conflict may occur NOTE: The number 0 should be at the top, as shown, when setting the camera ID.
  • Page 20: All-In-One Data Cable

    Connector 2-wire NOTE: Be careful not to pull the cables improperly during installation. OpenEye suggests that you fasten the cables after installation is complete. NOTE: When wiring the power cable, make sure the G/Y wire (Ground) is inserted into the mid-pin of the terminal block.
  • Page 21: 22-Pin Connector Definition

    The dome camera uses the RS-485 interface to communicate with a connected control device. Connect a control keyboard to the speed dome using the terminal block. OpenEye recommends using CAT 5 cables for RS-485 communication with a maximum length of 4000 feet (1219 meters) for 24-gauge wire. If the total cable length exceeds 4000 feet, use a repeater to maintain the signals.
  • Page 22 NOTES: 28583AA...
  • Page 23: Operation And Configuration

    OPERATION AND CONFIGURATION OSD DISPLAY FORMAT The information displayed on the screen is described in terms of OSD display, position and function description in the table below. Position Function OSD Display Description Auto Focus Mode Focus Modes Manual Focus Mode Backlight Compensation OFF Backlight Backlight Compensation ON...
  • Page 24: Osd Menu Tree

    OSD MENU TREE The OSD setup menu structure of the 510 dome camera is listed below. The star symbol indicates the factory default. For detailed function descriptions, see Configuration Menu. Item Layer 1 Layer 2 Layer 3 Default <ENGLISH>, <FRENCH>, <GERMAN>, <ITALIAN>, <JAPANESE>, <POLISH>, LANGUAGE ENGLISH <PORTUGUESE>, <RUSSIAN>, <SPANISH>...
  • Page 25 Item Layer 1 Layer 2 Layer 3 Default TOUR LINE <1> ~ <8> TOUR POINT <01> ~ <32> PRESET POSITION <001> ~ <255>, <END> TOUR SPEED <01> ~ <15> DWELL TIME <000> ~ <127> SEC. RUN TOUR ENTER EXIT AUTOSCAN LINE <1>...
  • Page 26 Item Layer 1 Layer 2 Layer 3 Default RATIO LEVEL <000> ~ <128> SHUTTER SPEED <000> ~ <ON> <128> IRIS OFFSET <000> ~ <128> EXIT <YES> WDR FUNCTION <AUTO> ☆ <OFF> PRIVACY SWITCH <ON>, <OFF> MASK SHADE <GRAY>, <WHITE>, <BLACK> BLACK H CENTER <000>...
  • Page 27: Configuration Menu

    CONFIGURATION MENU The detailed functions and parameter settings of your high speed dome can be set through the OSD (On Screen Display) menu with a control device, such as a control keyboard. The items in the OSD menu are described in the following sections. For further detailed setup procedures, please refer to the user manual of your installed control devices.
  • Page 28: Default Camera Settings

    DEFAULT CAMERA SETTINGS The LOAD DEFAULTS is used to restore some camera settings to the default settings, including Backlight, Focus, AE, WBC, Aperture, Zoom Speed and Digital Zoom. Once any one of the items is modified, the setting will become <OFF> automatically. Select <ON>...
  • Page 29: Wbc (White Balance Control) Mode

    WBC (WHITE BALANCE CONTROL) MODE The unit for measuring the color temperature ratio is in degrees Kelvin (K). You can select one of the White Balance Control modes according to the condition. The following table shows the color temperature of some light sources. Light Sources Color Temperature in K Cloudy Sky...
  • Page 30: Image Inverse

    Image Inverse Users can select <ON> to make the displayed image inversed vertically and horizontally. Occasions to employ the function include conferences, demonstration, testing, etc. When this function is enabled, the preset masks will be set off automatically (see Privacy Mask).
  • Page 31: Flip

    Flip Users can track an object continuously when it passes through under the dome camera with setting Flip to IMAGE (digital flip) or M.E. (mechanical flip). Image IMAGE represents digital IMAGE FLIP, which enables users to keep tracking objects seamlessly; under the mode, almost no delay occurs in comparing with that under the M.E.
  • Page 32: Id Display

    ID DISPLAY MAIN PAGE 2 ID DISPLAY TITLE DISPLAY TITLE SETTING PRESET ENTER SEQUENCE ENTER AUTOSCAN ENTER CRUISE ENTER HOME SETTING ENTER Press the direction key down to change the MAIN MENU page from 1 to 2, and then the menu item <ID DISPLAY> will be shown on the top.
  • Page 33: Preset

    TITLE SETTING: 01 EXIT SAVE LEFT RIGHT DELETE TITLE: Choose a character with direction keys and then press the <CAMERA MENU> key (ENTER) to input. For example: <A> <CAMERA MENU>, <B> <CAMERA MENU>, <C> <CAMERA MENU> TITLE: ABC To delete input characters, move the cursor to <LEFT> or <RIGHT> and press <CAMERA MENU> to select a character in the entry field.
  • Page 34: Autoscan

    Tour Line There are eight sets of Tour lines built in the dome camera. Use the LEFT/RIGHT direction keys to select a line first and then set its Tour points. Tour Point Up to 32 points can be specified for each Tour line. The Tour points represent order of the preset points that the dome will automatically run.
  • Page 35: Pattern

    End Point Users are able to set the end point after the start point is defined. Pan the dome to another position and press <ENTER> to save the position as the end point. Direction The item is for setting the AUTOSCAN direction of the dome camera. The dome will start to pan clockwise from the start point to the end point if your selection is <RIGHT>, and then return to the start point.
  • Page 36: Home Setting

    Run Pattern After Pattern setting is completed, select this item to execute the Pattern function. Exit Exit the PATTERN setup menu; go back to the MAIN PAGE 2 to carry on setup of home setting. NOTE: You can execute the Pattern function using the keyboard controller. Refer to the keyboard user manual for more information. HOME SETTING Users are able to set an operation mode to ensure constant monitoring.
  • Page 37: Ir Function (Removeable Ir Cut)

    IR cut filter will be removed to catch infrared light, and the displayed images will become black and white. Moreover, in the CM-510, users are able to view color images when the IR function is activated..
  • Page 38: Wdr Function

    Alarm Switch The item is used to enable or disable the selected alarm pin function. Use the left/right direction keys on the control keyboard to change the setting. Alarm Type There are two kinds of alarm types: Normal Open and Normal Close, which are illustrated as below. Select an alarm type that corresponds with the alarm application.
  • Page 39: Privacy Mask

    Under the item, users can define three parameters’ value: RATIO LEVEL (000 ~ 128), SHUTTER SPEED (000 ~ 128) and IRIS OFFSET (000 ~ 128), as shown below. WDR MODE RATIO LEVEL SHUTTER SPEED IRIS OFFSET EXIT Exit the WDR FUNCTION menu and go back to the MAIN PAGE 3 to carry on setup of privacy mask. PRIVACY MASK The Privacy Mask function aims to avoid any intrusive PRIVACY...
  • Page 40: Time Setting

    Clear Mask Users can delete a preset mask zone: Select the mask zone that will be erased (e.g. 01). Press <ENTER> to confirm the selection. Consequently, the screen will display the instructions to reset after the mask is cleared. Select <RESET> under the CLEAR MASK item and press <ENTER> to proceed with resetting. Mask Display This item is used to set the time to display a privacy mask.
  • Page 41: Schedule

    SCHEDULE The schedule function enables users to program a preset point or function (Tour/Auto-scan/Pattern) automatically to perform in a specific period of time. SCHEDULE SWITCH POINT HOUR MINUTE MODE PRESET PRESET POINT SCHEDULE RESET Switch Select <ON> to enable or <OFF> to disable the schedule function. Point Users are allowed to arrange 32 sets of schedule points, i.e.
  • Page 42 NOTES: 28583AA...
  • Page 43: Specifications

    SPECIFICATIONS TECHNICAL SPECIFICATIONS Model CM-510 Outdoor Speed Dome CAMERA CCD Sensor 1/4” CCD Progressive Scan Optical Zoom Digital Zoom 1x ~ 12x variable Effective Pixels 380k Horizontal Resolution 480 TVL Scanning System NTSC Synchronization Internal / Line Lock Video Output 1.0 Vp-p / 75 Ώ, BNC...
  • Page 44: Operation

    OPERATION Built-in Protocol OPTIX 3, Pelco D&P, VCL, Philips, AD-422, JVC, Kalatel Multi-Language OSD English, French, German, Italian, Japanese, Polish, Portuguese, Russian, Spanish Pan Travel 360° endless Tilt Travel -10° ~ 190° Manual Speed 1° ~ 90°/s Presets 0.225° Preset Accuracy Tilt 0.225°...
  • Page 45: Osd Menu Notes

    OSD MENU NOTES The following OSD menu tables are provided for you to record the dome settings. Item Layer 1 Layer 2 Layer 3 NOTES <ENGLISH>, <FRENCH>, <GERMAN>, <ITALIAN>, <JAPANESE>, <POLISH>, LANGUAGE <PORTUGUESE>, <RUSSIAN>, <SPANISH> LOAD DEFAULTS <ON>, <OFF> <ON> BLC LEVEL <00>...
  • Page 46 Item Layer 1 Layer 2 Layer 3 NOTES TOUR LINE <1> ~ <8> TOUR POINT <01> ~ <32> PRESET POSITION <001> ~ <255>, <END> TOUR SPEED <01> ~ <15> DWELL TIME <000> ~ <127> SEC. RUN TOUR ENTER EXIT AUTOSCAN LINE <1>...
  • Page 47 Item Layer 1 Layer 2 Layer 3 NOTES RATIO LEVEL <000> ~ <128> SHUTTER SPEED <000> ~ <ON> <128> IRIS OFFSET <000> ~ <128> EXIT <YES> WDR FUNCTION <AUTO> <OFF> PRIVACY SWITCH <ON>, <OFF> MASK SHADE <GRAY>, <WHITE>, <BLACK> H CENTER <000> ~ <255>...
  • Page 48 NOTES: 28583AA...
  • Page 49 28583AA...
  • Page 51 © 2008 OpenEye Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from OpenEye Inc. The information in this publication is believed to be accurate in all respects. However, OpenEye cannot assume responsibility for any consequences resulting from the use thereof.
