OpenEye Optix CM-525P User Manual

Pro-pack dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Eye
pen
®
Optix
Pro-Pack Dome Camera

User Manual

CM-525P
model no.
Please carefully read these instructions before using this product.
Save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optix CM-525P and is the answer not in the manual?

Questions and answers

Related Manuals for OpenEye Optix CM-525P

Summary of Contents for OpenEye Optix CM-525P

  • Page 1: User Manual

    ® Optix Pro-Pack Dome Camera User Manual CM-525P model no. Please carefully read these instructions before using this product. Save this manual for future use.
  • Page 3 User Guide No part of this documentation may be reproduced in any means, electronic or mechanical, for any purpose. OPENEYE shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.

  • Page 4: Warnings & Cautions

    WARNINGS & CAUTIONS WARNINGS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK. - DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. - DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTIONS CAUTIONS RISK OF ELECTRIC SHOCK...

  • Page 5: Compliance Statement

    COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.

  • Page 6: Important Safegurds

    IMPORTANT SAFEGUARDS 1. Do not expose the camera to rain or moisture - 7. Before operating, please check proper The OPTIX camera itself is designed for enclosed temperature, humidity and power source ratings - use or for use in a location where it is protected from -Use the camera under conditions where temperature rain and moisture.
  • Page 7 27104AF...

  • Page 8: Table Of Contents

    TABLE OF CONTENTS WARNINGS & CAUTIONS COMPLIANCE STATEMENT CE COMPLIANCE STATEMENT IMPORTANT SAFEGURDS INTRODUCTION INSTALLATION & CONFIGURATION PROGRAM & OPERATION PTZ SETUP MENU TECHNICAL SPECIFICATIONS DIMENSIONS APPENDIX A-TROUBLE SHOOTING APPENDIX B-OPTIONAL ITEMS 27104AF...
  • Page 9 27104AF...

  • Page 10: Introduction

    1. INTRODUCTION Features This OpenEye OPTIX Pro-Pack Dome Camera is the building block for any surveillance/security system. By using multiple Pre-Packaged dome cameras, no place is too large for monitoring. Extensive and flexible architecture facilitates remote control functions for a variety of external switching devices such as multiplexers and DVRs.
  • Page 11 27104AF...

  • Page 12: Installation & Configuration

    2. INSTALLATION / CONFIGURATION 2.1 Basic Installation A. PACKAGE CONTENTS OPTIX Pre-Pack Dome (Dome Camera Unit) Ceiling Mount Bracket Joint Pipe Plastic Anchor Screws for Plastic Anchor L-Wrench (M4) L-Wrench (M5) Block Protector Cap Cable (Alarm In/Out) Instruction Manual Silicon Rubber Sealant Teflon Tape B.
  • Page 13 2. INSTALLATION / CONFIGURATION C. BASIC CONFIGURATION CH 1 in CH 2 in CH 3 in CH 4 in CH 5 in CH 6 in CH 7 in CH 8 in CH 9 in CH 10 in CH 11 in CH 12 in CH 13 in CH 14 in...
  • Page 14 2. INSTALLATION / CONFIGURATION The Pro-Pack dome camera must be installed by qualified service personnel in accordance with all local and federaI electrical and building codes. The system should be installed according to Figures 3 through 9. The Pro-Pack OPTIX dome camera is for use in surface mounting applications. The mounting surface should be capable of supporting loads up to 10lb(4.5Kg).
  • Page 15 2. INSTALLATION / CONFIGURATION The Pro-Pack dome camera must be installed by qualified service personnel in accordance with all local and federaI electrical and building codes. The system should be installed according to Figures 3 through 9. Figure 5 - Layout of Switches D.
  • Page 16 2. INSTALLATION / CONFIGURATION The dome camera must be installed by qualified service personnel in accordance with all local and federaI electrical and building codes. The system should be installed according to Figures 3 through 9. Figure 7 - Example Termination Diagram E.

  • Page 17: Baud Rate

    F. SETTING UP THE DIP SWITCH If a dome camera is to be installed with an OPTIX dome keyboard controller, select the OpenEye OPTIX Protocol. Consult OpenEye technical support if a dome camera is installed with a device other than a keyboard.

  • Page 18: Connecting Wiring

    2. INSTALLATION / CONFIGURATION 2.2 Connecting Wiring A. CONNECTING RS-485/422 The dome camera can be controlled remotely by an externaI device or control system, such as control keyboard, using RS-485 half duplex, RS-422 duplex or simplex serial communications signaIs. Connect marked RX+, RX- to TX+ and TX- of the RS-485 control system.

  • Page 19: Getting Started

    2. INSTALLATION / CONFIGURATION 2.3 Getting Started Once installed, apply power to the dome camera. Once power is turned on, the dome camera will start a configuration sequence. When configuration is done, the following information is displayed. OPTIX DOME 1 LOADING DOME ADDRESS (001) CAMERA TYPE: 25XDN CHECKING EEP ROM...
  • Page 20 27104AF...

  • Page 21: Program & Operation

    3. PROGRAM & OPERATION 3.1 Getting Started Before you program or operate OpenEye OPTIX Dome Camera, you must select the dome camera by pressing the dome camera NO + CAM on the OpenEye Keyboard Controller. Pressing 1, 0 and CAM key sequentally will select the dome camera 10. The selected dome camera ID Example: will be displayed on the LCD monitor of the OpenEye Keyboard Controller.
  • Page 22 3. PROGRAM & OPERATION A. OPTIX HIGHSPEED DOME MENU MENU SYS INFO AREA TITLE PRIVACY ZONE OSD DISPLAY DISPLAY VIEW ANGLE POSITION COOLER/HEATER HOME/PRESET AUTO SCAN DOME SETUP TOUR PATTERN FOCUS ALARMS WB CONTROL AE CONTROL LINE LOCK CAMERAS SCREEN SETUP DIGITAL EFFECT DAY/NIGHT INIT DATA...
  • Page 23 27104AF...

  • Page 24: Ptz Setup Menu

    The HOME function can be set so that the camera automatically goes to Preset, Tour, Pattern, or Auto Scan after the OpenEye Keyboard Controller has been idle for an amount of time. For example, if a joystick controller is idle for 10 seconds (FUNCTION TIME), the camera goes to the previous mode.

  • Page 25: System Information

    4. PTZ SETUP MENU 4.2 SYS INFO The OpenEye OPTIX Camera’s set up menu provides essentiaI information about the dome camera if service is required. When you view this screen, you can determine the camera type and ROM version. The information on this screen can't be modified.
  • Page 26 If this option is enabled, the nearest area title will be displayed when the camera is moving either by manual operation, AutoScan, or Pattern. The DOME camera’s [OSD DISPLAY/AREA TITLE] will override this function (Dome Camera’s[OSD DISPLAY/AREA TITLE] must be turned ON). AREA TITLE SET UP --- OpenEye OPTIX PRE-PACK --- NO.001 : ============== HOME START(PTZ): 000.00...
  • Page 27 4. PTZ SETUP MENU B. PRIVACY ZONE The Privacy Zone allows users to hide up to 8 unwanted views in a camera. Select No. PRIVACY ZONE SETUP --- OpenEye OPTIX PRE-PACK --- NO.001 HOME MODE : DISABLE SYS INFO AREA TITLE...
  • Page 28 4. PTZ SETUP MENU AREA D. TIME :005 OPERATION Z050 ID :0001 T :+34.0C (259.38, 047.42) Area/P-Zone Title: You can see the area title, the privacy zone title has priority over the area title. Time Display: D. Time/T.Time/A.Time (Dwell/Task/Alarm Time) Operation Title: Preset, AutoScan and Pattern Title Dome Mode: T1(Tour1) 001(Preset001) (Privacy/Flip on)
  • Page 29 REVERSE: Left - right reversal and Upside down. E. POSITION If the OpenEye OPTIX OSD is obsured on other equipment, like a DVR, you can move the OSD horizontally and/or vertically. The factory position is 33/05 (Horizontal/Vertical). Variable 23~43 for horizontal, 02~15 for vertical.
  • Page 30 F. COOLER/HEATER This function will allow users to keep the inside temperature of the OpenEye OPTIX Pre-Pack at a stable operating condition. If the temperature in the dome is to high, the cameras Auto Mode will regulate the temperature by turning on the Cooler.

  • Page 31: Dome Setup

    “home” position for the dome camera. As many as 320 presets (HOME included), whose positions are saved in the dome’s firmware, may be programmed. There are four pages of the preset menu, each page can hold 80 presets. Select No. HOME/PRESET SETUP --- OpenEye OPTIX PRE-PACK --- : HOME NO. 000 HOME : AUTO P: 000.00...
  • Page 32 NO. + HOME button on your OpenEye keyboard controller WRITING O.K. Z001ID: 0010 Z001ID: 0010 (145.95, 038.60) (145.95, 038.60) Note: If you press NO. + CTRL + HOME on your OpenEye keyboard controller, the new preset will be programmed automatically without reminding 27104AF...
  • Page 33 LANGUAGE 00 = = = = = = = = EXIT SAVE EXIT Note: Press the SCAN button on your OpenEye Keyboard Controller to go directly to the Auto Scan menu without going through the main menu. Title AUTOSCAN SETUP...
  • Page 34 4. PTZ SETUP MENU Mode AUTOSCAN SETUP AUTOSCAN SETUP NO. 001 NO. 001 : ENDLESS (LEFT) : COMING & GOING MODE MODE SPEED(PTZ) SPEED(PTZ) START(PTZ) : (000.0, 000.00, 001) START(PTZ) : (000.0, 000.00, 001) : (000.0, 000.00, 00) (PTZ) (PTZ) DWELL(SEC) : 005 DWELL(SEC)
  • Page 35 === === === === === === === LANGUAGE === === === === === === === EXIT SAVE EXIT Note: Press the TOUR button on your OpenEye keyboard controller to go directly to the TOUR menu without going through the main menu. Title AUTOSCAN SETUP TOUR SETUP NO.
  • Page 36 4. PTZ SETUP MENU Mode & No. Select between 4 different modes and No. (Preset, Auto Scan, Tour and Pattern) TOUR SETUP TOUR SETUP NO. 001 NO. 001 : FAST : FAST SPEED SPEED : OFF : OFF FREEZE FREEZE SC2 === === === === === === === === === === === === === === === === === === === ===...
  • Page 37 The pattern feature records a users control of the selected dome camera for up to 240 seconds. Up to four patterns can be stored and played back by pressing No. + PTRN keys subsequently on your Open- Eye Keyboard controller. Select No. PATTERN SETUP --- OpenEye OPTIX PRE-PACK --- TIME NO. TITLE HOME SYS INFO...
  • Page 38 4. PTZ SETUP MENU 4.6 ALARMS NO. Alarm Input ALARM SETUP --- OpenEye OPTIX PRE-PACK --- MODE TIME HOME SYS INFO DISPLAY DOME SETUP ALARMS CAMERA CONFIG LANGUAGE EXIT SAVE EXIT PRI (Priority) Mode Stored Preset, Tour, Auto Scan and Pattern...
  • Page 39 4. PTZ SETUP MENU 4.7 CAMERAS Note: This menu feature will depend on the camera module installed in your dome camera. A. FOCUS FOCUS SETUP --- OpenEye OPTIX PRE-PACK --- MODE AUTO HOME SYS INFO SAVE EXIT FOCUS DISPLAY WB CONTROL...
  • Page 40 4. PTZ SETUP MENU C. AE CONTROL --- OpenEye OPTIX PRE-PACK --- WHITE BALANCE SETUP HOME MODE : FULL AUTO SYS INFO IRIS FOCUS DISPLAY GAIN (AGC) WB CONTROL DOME SETUP SHUTTER SPEED AE CONTROL ALARMS LINE LOCK SLOW SHUTTER...
  • Page 41 4. PTZ SETUP MENU E. SCREEN SETUP --- OpenEye OPTIX PRE-PACK --- SCREEN SETUP HOME BRIGHTNESS : 08 SYS INFO SHARPNESS : 08 FOCUS DISPLAY BACK LIGHT : AUTO WB CONTROL DOME SETUP BMB MODE : OFF AE CONTROL ALARMS...
  • Page 42 4. PTZ SETUP MENU G. DAY & NIGHT --- OpenEye OPTIX PRE-PACK --- DAY & NIGHT SETUP HOME MODE : AUTO SYS INFO FOCUS DISPLAY WB CONTROL DOME SETUP SAVE EXIT AE CONTROL ALARMS LINE LOCK CAMERA SCREEN SETUP CONFIG...
  • Page 43 4. PTZ SETUP MENU 4.8 CONFIG A. INIT DATA ON/OFF INIT DATA SETUP --- OpenEye OPTIX PRE-PACK --- INIT. ALL(FACTORY) : OFF HOME INIT. CAMERA : OFF SYS INFO INIT. AREA TITLE : OFF DISPLAY INIT. PRIVACY ZONE : OFF DOME SETUP INIT.
  • Page 44 4. PTZ SETUP MENU B. DOME RESET --- OpenEye OPTIX PRE-PACK --- HOME SYS INFO DISPLAY DOME SETUP ALARMS INIT DATA CAMERA DOME RESET RESET: (HOME)OR(ENT) KEY CONFIG GENERAL LANGUAGE CANCEL: (CLR/ESC) KEY EXIT This feature is used to reset the micro processor of the dome camera. The main power will be turned OFF and then ON again during this process.
  • Page 45 4. PTZ SETUP MENU 4.9 EXIT 1. To exit the main menu, select the CLR / ESC key or select the MENU / LOCK button. 2. Exit the main menu by selecting EXIT mode --- OpenEye OPTIX PRE-PACK --- HOME SYS INFO DISPLAY...
  • Page 46 27104AF...

  • Page 47: Technical Specifications

    5. TECHNICAL SPECIFICATIONS Camera: CM-525P 1.0 lx (30IRE); Day & Night Off (Color) Minimum Illumination 0.1 lx (30IRE); Day & Night On (B&W) 0.01 lx; Slow Shutter X 128 On 0.001 lx (30IRE); Day&Night On (B&W)+ DSS 25X Optical Zoom with Auto Focus Lens (10X Digital Zoom (F = 1.6~3.7, 50IRE, 3.8mm~95mm) 50 dB...

  • Page 48: Dimensions

    6. DIMENSIONS 7.2” [182] 4.5” [114.5] 6.7” [170] 10.8” [273.8] OpenEye OPTIX Pro-Pack Dome Camera 4.9” [124] 1-1/4” PT-Thread 4.9” [124] .71” [18] 4- o 4.3”[11] 7.9” [200] .71” [18] 1-1/4” NPT PIPE Thread 5.9” [150] 1-1/4” PT-Thread 1.14” [29] 1.8”...

  • Page 49: Appendix A-Trouble Shooting

    APPENDIX A - TROUBLESHOOTING If problems occur, verify the installation of the camera with the instructions in the manual and with other operating equipment. Isolate the problem to specifi c pieces of equipment in the system and refer to the equipment manual for further information.

  • Page 50: Appendix B-Optional Items

    APPENDIX B - OPTIONAL ITEMS A. PARAPET WALL (SWING ARM) & MOUNT BRACKET 21.99” [558] 4.47” [120] 39.4” [1000] 2-m10Xp1.5-BOLT .59” [15] 2.76” [70] 2.76” [70] 14.2” [360] 2.76” [70] 4-M10Xp1.5-NUT 2.76” [70] 1.58” [40] 8.67” [220] 1.18” [30] 11.03” [280] 3.31”...
  • Page 51 APPENDIX B - OPTIONAL ITEMS D. CORNER MOUNT ADAPTOR 7.88” [200] 3.94” [100] 6.3” [160] 160.0 o.433” [11] 4-M8X1.25 NUT 4.5” [114.3] 4.33” [110] 114.3 o1.58” [40] 5.01” [150] E. ROOF MOUNT ADAPTOR 6.3” [160] 4.5” [114.3] 12.61” [320] 12.61” [320] 6.51”...
  • Page 52 APPENDIX B - OPTIONAL ITEMS G. FLUSH MOUNT ADAPTOR 7.8” [200] 4.73” [120] 3.15” [80] 8.67” [220] H: WALL MOUNT ADAPTOR 11.74” [298] 4.5” [8] 1.58” [40] 8” [203] 4.5” [114.3] 3.15” [80] 8” [203] 6.51” [165.1] .37” [9.5] .8” [20] 6”...
  • Page 53 27104AF...
  • Page 54 27104AF...
  • Page 55 27104AF...
  • Page 56 All rights reserved. No part of this publication may be reproduced by any means without written permission from Openeye Inc. The information in this publication is believed to be accurate in all respects. However, Openeye cannot assume responsibility for any consequences resulting from the use thereof.
