Nstalling The - 3Com VCX V7122 Installation Manual

2
I

NSTALLING THE

G
ATEWAYS
This section provides information on the hardware installation procedure
for the V7122 Digital Gateways.
WARNING: Electrical Shock
The equipment must be installed or serviced only by qualified service
personnel.
The figure below shows the front panel of the V7122 media gateway. For
information on the V7122 LEDs, see
Figure 1 V7122 Front View
Table 2 V7122 Front View Component Descriptions
Item Label
1 FAULT
2 --
3 --
4 --
5 --
6 T1/E1 STATUS E1/T1 Trunk Status LED indicators
V7122 M
Monitoring the V7122 Chassis
Component Description
Dual AC Power LED
cPCI board locking screws
cPCI latches
TP 1610 cPCI board, 16-trunk configuration
Status LED indicators
EDIA
LEDs.
