3. Press Up/Down button to select effect, color and speed for that program.
Note: 1. Effects [1-12] and Colors [1-50] are from factory default settings or customized.
2. Speed 1 ~ 99 goes from fastest to slowest.
► NON editable program 13-18
Program Number [13]: 50-color step changing
Program Number [14]: Color flowing in Red, Green, Blue, White and Amber
Program Number [15]: 50-color crossfade
Program Number [16]: Falling star effect in white color
Program Number [17]: RRGGWBBAA flashing
Program Number [18]: Pulse close effect
TEST MODE
Test Mode is designed to test LEDs and fans if they are all working.
1. Press MENU button till [Test Mode] shows up, press Fun button to enter Test Mode.
2. Use Up/Down button to select [Test LED] or [Test Fan], then press Fun button to go to Test LED or Test Fan.
3. Press Up/Down to test Red, Green, Blue, White and Amber LEDs or test fan ON/OFF.
NOTE! During operating Fans will be turned off when internal temperature is below 40°C and
will be turned on automatically over that level.

4. MOUNTING AND INSTALLATION

This fixture is designed for floor stand and truss mounting.
IMPORTANT!!! Safety cables must always be used. The safety cable must be capable of holding 10
times the weight of the fixture.
