SOUND ACTIVE MODE
1. Press MENU button till System Mode [xxx] displayed, then use Up/Down button to select System Mode [Sound] and
press Fun button to enter. LCD shows:
Sound Program
[xx]
2. Press Up/Down button to select Sound Program [1-16]. [1-12] program is editable and [13-16] program is fixed.
3. When Sound Program [1-12] is selected, press Fun button to enter and use Up/Down to select effects [1-12] (same as
updating), colors [1-50] (same as updating) and set sound sensitivity from [1-99], HIGHEST to LOWEST level.
4. When Sound Program [13-16] is selected, press Fun button to enter and use Up/Down to set sound sensitivity [1-99].
MASTER/SLAVE MODE
In this mode, one can run the whole system in synchronized effect. Maximum 31pcs can be linked in a daisy chain as
Master/Slave operating system.
1. One unit is to be set as Master and this Master unit needs to work under PROGRAM or Auto or Sound mode. Also, you
need to set Slave Number for total number of Slave units. i.e., there are 5 Slave units (not including Master unit) in the
daisy chain, then Slave Number is 5.
2. Other units are to be set in Slave mode and Slave ID is to be set for each Slave unit.
3. Operate the Master unit in PROGRAM, Auto and Sound mode to run the whole system.
In Master/Slave operating mode, all Slave units are to be set to Slave Mode and Slave ID is required for each Slave unit.
1. Press MENU button go to System Mode, then use Up/Down button to select System Mode [Slave] and press Fun
button to enter.
2. Use Up/Down button to set up a Slave ID number for that unit. The first Slave connected with the Master unit is Slave
ID [1], the next Slave units are Slave ID [2], Slave ID [3], and so on.
In Master/Slave mode, in order to run color flow effect sequentially through the daisy chain, on the Master unit you need to
set up a total number for Slave units.
1. Press MENU button till [System Setup] shows up, then use Up/Down button to select System Setup [Slave Number]
and press Fun button to enter.
2. Use Up/Down button to set up the number of total Slave units.
PROGRAM MODE
In this mode, you can edit and run Program Number [1] to [12] combining effect, color, speed to make desired programs.
Program from [13] to [18] are non-editable while you can select appropriate speed to run the program.
1. Press MENU button go to System Mode, then use Up/Down button to select System Mode [Program] and press Fun
button to enter.
2. Use Up/Down button to select program number, then press Fun button to select Program Effect [x], Program Speed [x],
Program Color [x].
