Danfoss C17 Installer's Manual page 63

Choose your favorite display
(schedule II)
Choose the display - A, B, or C - for daily
operations.
Display A
Line
A
Circuit
System information - display B
Line
B
Circuit
Supply
temp. (S1)
Today's schedule - display C
Line
C
Circuit
The controller automatically reverts to display C if the card has
been reinserted or the power supply has been interrupted.
If the temperature value is displayed as "- -", the sensor in
question is not connected. "- - -" means that the sensor is short-
circuited.
State of controlled units
1 1 2
ON ON
80
Time
1 8 3 5
0 3 6 9 12
Today's schedule
3
ON
33
Return
temp. (S4)
15 18 21 24
1b
The yellow
side of the
ECL Card
