SportsArt Fitness P756 Owner's Manual

Sportsart horizontal leg press machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P756 OWNER'S MANUAL CONTENTS
1. INTRODUCTION..................................................................................................
2. IMPORTANT SAFETY PRECAUTIONS...............................................................
3. LIST OF PARTS...................................................................................................
STEP 1 Seat Frame and the Connector Installation..........................................
STEP 2 Weight Stack Installation.......................................................................
STEP 3 Cable Installation..................................................................................
STEP 4 Cable Adjustment..................................................................................
STEP 5 Cable Slack Adjustment........................................................................
STEP 6 Foot Press Plate Installation.................................................................
STEP 7 Handle Installation.................................................................................
STEP 8 Seat Bottom Installation........................................................................
STEP 9 Seat Back Installation...........................................................................
STEP 10 Apply the Weight Stack Sticker............................................................
STEP 11 Cover Support Plate Installation...........................................................
STEP 12 Front Cover and Rear Cover Installation..............................................
STEP 13 Top Covers Installation..........................................................................
5. OPERATION INSTRUCTION................................................................................
6. MAINTENANCE.....................................................................................................
MAINTENANCE Schedule....................................................................................
MAINTENANCE Task List......................................................................................
MAINTENANCE One-Year Maintenance Log.......................................................
7. CONSIGNES DE SECURITE IMPORTANTES.....................................................
..........................................................................
'
'
........................................................................
1
2
5
8
11
15
17
18
19
21
22
24
25
26
28
29
30
31
32
33
34
35
36
37

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P756 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SportsArt Fitness P756

Summary of Contents for SportsArt Fitness P756

  • Page 1: Table Of Contents

    P756 OWNER’S MANUAL CONTENTS 1. INTRODUCTION....................2. IMPORTANT SAFETY PRECAUTIONS............... 3. LIST OF PARTS....................4. ASSEMBLING THE PRODUCT STEP 1 Seat Frame and the Connector Installation.......... STEP 2 Weight Stack Installation............... STEP 3 Cable Installation.................. STEP 4 Cable Adjustment.................. STEP 5 Cable Slack Adjustment................

  • Page 2: Introduction

    1. INTRODUCTION Congratulations on the purchase of a high quality SportsArt product, the P756 Horizontal Leg Press machine. Constructed of high quality materials and designed for years of reliable performance, this product was made for full commercial use. Before this product is assembled or operated, we recommend that you familiarize yourself with this manual.

  • Page 3: Important Safety Precautions

    2. IMPORTANT SAFETY PRECAUTIONS This product was designed and built for optimum safety. However certain precautions apply during the use of this product. Please note the following safety precautions: ．Please read the entire manual before assembly and operation. Make sure the product is installed and operated as instructed in this manual.

  • Page 4: List Of Parts

    3. LIST OF PARTS Box A...
  • Page 5 Box B Box C...
  • Page 6 Box A - Main Frame Components Name Qty No. Description Weight stack top right cover Weight stack rod Weight stack top left cover Cover bracket Main frame Cover support plate A Cover support plate B-2 Rear cover Cover support plate B-1 Front cover Storage tray Bracket...
  • Page 7 Components in the Hardware Kit Name Specification Notes (13*17) Open end wrench (27*29) Open end wrench Phillips-head screw driver Components on the Product Specification Notes Name Hex head screw M10*P1.5*L130 Spring washer Washer D16*d10.2*t1.0 Nylon hex lock nut Mushroom top inner hex screw M10*P1.5*L25 Washer D44*d10.5*t3.0...
  • Page 8 Components on the Product Specification Notes Name Flat washer D20*d6.3*t1.5 Axle D15*L26 Nylon hex lock nut M6*P1.0*6 Flat washer D20*d6.3*t1.5 Axle D8*L54.5 Bushing D12*d8*L7 Soft cap Round head inner hex screw M8*P1.25*L25 Spring washer M8*t2.0 Flat washer D17*d8*t1.5 Nylon hex lock nut M8*P1.25 Round head inner hex screw M8*P1.25*L20...

  • Page 9: Assembling The Product

    4. ASSEMBLE THE PRODUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product.
  • Page 10 *Loosen and remove the screws (30) (31) (32) (33) and the connecting plates from the components (A3) (A24) (A27) (A28) (A29) as shown. Carefully set each piece aside.
  • Page 11 (a). Use the screws (30) (31) (32) (33) to secure the connectors (A27) (A28) (A29) to the main frame (A3) and the seat frame (A24) as shown.

  • Page 12: Step 2 Weight Stack Installation

    STEP 2 Weight Stack Installation...
  • Page 13 (a). Remove the screws (35) from the guide rod (36). Set the guide rod (36) downward into place as shown. (b).Remove the pin (37) and the rubber washer from the guide rod (36).
  • Page 14 (c). Loosen and remove the screws (38) (39) from the stack fork (A7). (d). Insert the weight stack rod (A8) into the central mounting position of the upper stack carriage set (A20). Use the screws (38) (39) to secure the stack fork (A7) and the cable bracket into place of the upper stack carriage set (A20) as shown.
  • Page 15 (e). Insert and lower the (5 kg/11lb) weight plates (A30) into place on the guide rods (36) one at a time. Once complete, slide down the upper stack carriage set (A20) on top of the weight stack. (Note: The convex side of weight plate should face up and the stack fork (A7) points toward the front.) * If there is an optional (7.5kg/16.5lb) weight plate installed, insert the optional weight plates first before the (5 kg/11lb) weight plates (A30).

  • Page 16: Step 3 Cable Installation

    STEP 3 Cable Installation (a) Lossen and remove the screws (40) from area A and B as shown.
  • Page 17 (b). First, cut the zip tie on the cable. Disconnect the feeder cord from area B and wrap this feeder cord around the cable nut. Tread the cable onto the pulley at area B as indicated, and then secure the pulley with the screws (40). Pull the feeder cord at area A to thread the cable through the pulley at area A as indicated.

  • Page 18: Step 4 Cable Adjustment

    STEP 4 Cable Adjustment Please follow the following instructions to adjust the cable. * Insert the stack fork into the gap under the lowest weight plate, and then adjust the large nut at area C. Adjust until the upper stack carriage set moves slightly. * To adjust the cable, first insert the (Z) rod and loosen the (Y) nut, and then adjust the (X)nut.

  • Page 19: Step 5 Cable Slack Adjustment

    STEP 5 Cable Slack Adjustment * If area C can no longer be adjusted, set distance at area C to 30mm. Remove the * screws (41) from hole E of area D and the soft cap (42) from area F, and then insert the cable nut into hole F and secure with the screws (41).

  • Page 20: Step 6 Foot Press Plate Installation

    STEP 6 Foot Press Plate Installation...
  • Page 21 (a). Loosen and remove the screws (43)(44) from the foot press plate (A21) and the stopper (A22). (b). Use the screws (33) to secure the stopper (A22) to the front of the foot press plate (A21), and then set foot press plate (A21) in place of the seat frame (A24) on its mounts, then insert the axles and secure them with the screws (44).

  • Page 22: Step 7 Handle Installation

    STEP 7 Handle Installation (a). Loosen and remove the screws (45) from the handle (A26). (b). Rest the handle (A26) beneath the seat frame (A24) as shown, and then secure the screws (45) as shown.

  • Page 23: Step 8 Seat Bottom Installation

    STEP 8 Seat Bottom Installation...
  • Page 24 (a). First, remove the screws (46) from the seat bottom (A25). (b). Use the screws (46) to secure the seat bottom (A25) to the seat frame (A24).

  • Page 25: Step 9 Seat Back Installation

    STEP 9 Seat Back Installation (a). First, remove the screws (47) (48) from the seat back (A23) and the seat frame (A24). (b). Use the screws (48) to secure the seat back plate to the seat frame (A24). ( ). Secure the seat back (A23) to the seat back plate with the screws (47).

  • Page 26: Step 10 Apply The Weight Stack Sticker

    STEP 10 Apply the Weight Stack Sticker Note: Before applying weight plate stickers, please wipe the area clean, and clean your hands before proceeding to the next step. (a). Align and tape the cardboard to the upper left corner of the weight plate (A30). (b).

  • Page 27: Step 11 Cover Support Plate Installation

    STEP 11 Cover Support Plate Installation (a). Insert the screw sockets (13) into place in the main frame (A3) as shown, and then use the screws (15) to secure the bracket (A16) in place. (Note: The bracket (A16) must be secured to the top of main frame as shown.)
  • Page 28 (b). Use the screws (16) to secure the cover support plates (A10) to the straight frame of the main frame (A3) and then secure the cover support plates (A4) (A5) to the both side of the curved frame as shown. (Note: The cover support plates must be secured outside of the bracket (A16).)

  • Page 29: Step 12 Front Cover And Rear Cover Installation

    STEP 12 Front Cover and Rear Cover Installation (a). Use the screws (10) to secure the cover bracket (A9) in place on the main frame (A3) as shown. (b). Slide the front cover (A14) (A15) from the top down into the cover support plates' grooves.

  • Page 30: Step 13 Top Covers Installation

    STEP 13 Top Covers Installation *Secure the weight stack top right cover (A1) and the top left cover (A2) with the screws (11). (Note: During assembling, place the bracket of the top covers inside of the cover support plates as shown.)

  • Page 31: Step 14 Storage Tray Installation

    STEP 14 Storage Tray Installation (a). Loosen and remove the screws (49) (50) from the storage tray (A6) and the main frame (A3). (b). Hold the storage tray (A6) in place and secure it with the bracket and the screws (50) (49) as shown.

  • Page 32: Step 15 Stack Fork Inspections

    STEP 15 Stack Fork Inspections *Insert the stack fork to make sure that every weight plate can be engaged easily.

  • Page 33: Operation Instruction

    5. OPERATION INSTRUCTION To move the seat back position toward yourself, simply pull it. To move the seat back away from yourself, pull the knob of area A and press the seat back.

  • Page 34: Maintenance

    6. MAINTENANCE This section covers maintenance topics and includes a maintenance schedule, task list, and log. 1.Apply lubricant to the guide rods every week. Procedure: (a). Put some lubricant on a clean, lint-free cloth. Rub the lubricated cloth on the guide rods.

  • Page 35: Maintenance Schedule

    Maintenance Schedule (P756) Maintenance Schedule Area Week Month Quarter Year Clean Exterior Inspect for looseness and Screws secure if necessary. Check for proper equipment Test operation. Seat/Back Use damped cloth to clean. Cushion Check for damage or wear. Cable Replace it if necessary.

  • Page 36: Maintenance Task List

    ‧ Do NOT use cleaners with alcohol, ammonia, or other damaging chemicals. The use of such chemicals can damage the product and void the warranty. Never spray or pour any liquid directly onto the product. Doing so can damage electronic components and void the warranty. P756...

  • Page 37: Maintenance One-Year Maintenance Log

    Maintenance One-Year Maintenance Log Facility : Supervisor: Product Model Number : Serial Number: Start Date: End Date: Daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28 Completed Daily Tasks Weeks 29-35 Weeks 36-42 Weeks 43-49 Weeks 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21...

  • Page 38: Consignes De Securite Importantes

    ‘ ‘ 7. CONSIGNES DE SECURITE IMPORTANTES Le produit SportsArt a été conçu et fabriqué afin d'assurer une sécurité optimale. Cependant certaines précautions s'appliquent chaque fois que vous utilisez votre produit. ．Lisez entièrement le manuel avant l'assemblage et l'utilisation. Veuillez aussi noter les consignes de sécurité...
  • Page 39 ATTENTION Si vous ressentez une douleur ou si vous avez une sensation anormale, ARRÊTEZ VOTRE ENTRAÎNEMENT et consultez immédiatement votre médecin. Entraînez- vous à votre niveau d'exercice recommandé. NE PAS s'entraîner jusqu'à l'épuisement. Avant de commencer un programme d'exercice, vous devriez consulter votre médecin.
