SportsArt Fitness S972 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S972 OWNER'S MANUAL CONTENTS
1. INTRODUCTION ................................................................................ 2
2. SAFETY PRECAUTIONS ..................................................................
3. LIST OF PARTS .................................................................................
4. ASSEMBLE THE PRODUCT .............................................................
STEP 1 Install the Top Support Frame ...................................................
STEP 4 Install the Pulleys .................................................................... 10
STEP 5 Counterweight Assemblies ...................................................... 11
STEP 6 Apply the Weight Stack Sticker ................................................ 13
STEP 7 Install Front Cover Bottom Bracket .......................................... 14
STEP 8 Install Cover Support Plate....................................................... 15
STEP 9 Install the Cable ........................................................................ 16
STEP 10 Install the Cover .................................................................... 17
STEP 11 Install the Tower Covers ........................................................ 19
STEP 12 Install the Hooks ................................................................... 20
STEP 13 Install the Level the Unit ........................................................ 21
5. OPERATE THE PRODUCT ............................................................... 25
OPERATION Operate the Product ........................................................ 25
OPERATION Exercising Instructions .................................................... 26
6. MAINTENANCE ................................................................................ 29
MAINTENANCE Schedule .................................................................... 29
MAINTENANCE Task List ..................................................................... 30
MAINTENANCE One-Year Maintenance Log ....................................... 31
7. CONSIGNES DE SÉCURITÉ IMPORTANTES ................................. 32
3
4
7
7
8
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S972 and is the answer not in the manual?

Questions and answers

Related Manuals for SportsArt Fitness S972

Summary of Contents for SportsArt Fitness S972

  • Page 1: Table Of Contents

    S972 OWNER’S MANUAL CONTENTS 1. INTRODUCTION ................2 2. SAFETY PRECAUTIONS ..............3. LIST OF PARTS ................. 4. ASSEMBLE THE PRODUCT ............. STEP 1 Install the Top Support Frame ........... STEP 2 Install the Support Tube and the Connector ......

  • Page 2: Introduction

    1. INTRODUCTION Congratulations on the purchase of a high quality SportsArt product, the S972 Functional Trainer. Constructed of high quality materials and designed for years of reliable performance, this product was made for full commercial use. Before this product is assembled or operated, we recommend that you familiarize yourself with this manual.

  • Page 3: Safety Precautions

    2. SAFETY PRECAUTIONS This product was designed and built for optimum safety. However certain precau- tions apply during the use of this product. Please note the following safety precautions: • Please read the entire manual before assembly and operation. Make sure the product is installed and operated as instructed in this manual.

  • Page 4: List Of Parts

    3. LIST OF PARTS Assembly Parts No. Name Qty. No. Name Qty. A1 Main frame A8 Front cover support plate 2 A2 Top support frame A9 Pulley A3 Height adjusting tube A10 Pulley support plate A4 Front cover top bracket A11 Cable alignment plate A5 Back cover Left adjustment pulley...
  • Page 5 Right adjustment pulley A20 Hook assembly A14 Left connector assembly A21 Weight stack A15 Right connector assembly 1 A22 Weight stack label A16 Front cover bottom bracket 1 A23 Back cover Front cover center A24 Front cover support plate A18 Left rear support leg A25 Tool kit A19 Right rear support leg Components in the Hardware Kit...
  • Page 6 Hex head screw M8*P1.25*L65 Flat washer D17*d8.3*t2 PU tube ØD12*d8*L45 Nyloc hex lock nut Mushroom head inner hex screw M8*P1.25*L15 Flat washer D20*d8*t1.0 Mushroom head inner hex screw M6*P1.0*L15 Washer D16*d10.2*t1.0 Beveled head inner hex screw M6*P1.0*L30 Nyloc Hex Lock Nut M6*P1.0*6 Cable balls set Ball washer...

  • Page 7: Assemble The Product

    4. ASSEMBLE THE PRODUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product.

  • Page 8: Step 2 Install The Support Tube And The Connector

    STEP 2 Install the Support Tube and the Connector Support Tube and Connector Installation (a). Remove the screws (31)(40) from the the main frame (A1). (b). Attach both connector assembly (A14) (A15) and the rear support legs (A19) (A20) to the main frame (A1). Use screws (31)(40) to secure the whole assembly.

  • Page 9: Step 3 Install The Adjustment Pulley And The Adjustment Tube

    STEP 3 Install the Adjustment Pulley and Adjustment Tube (a). First, remove screws (32) from the adjustment tube (A3), then slide both adjustment pulley assembly (A12) (A13) onto each height adjustment tube (A3). (b). Attach each height adjustment tube (A3) onto the top support frame (A2) and both connector assembly (A14)(A15) at the bottom.

  • Page 10: Step 4 Install The Pulleys

    STEP 4 Install the Pulleys (a). Remove the screws (33) from the Main Frame (A1). (b). Assemble the pulley assembly with pulley (A9), pulley plate (A10), and cable alignment roller (A11). Use screws (34) to secure the assembly to the main frame (A1).

  • Page 11: Step 5 Counterweight Assemblies

    STEP 5 Counterweight Assembly...
  • Page 12 STEP 5 Counterweight Assembly (a.) Hold the upper stack plate and then cut the zip tie. Gently lower the up- per stack plate into place. (b) Remove the screws (34) that secure the guide rods to the top of the weight stack frame, and then set the guide rod downward into place.
  • Page 13 STEP 5 Counterweight Assembly (d). Insert weight plates into place on the guide rods one at a time. Once complete, slide down the upper stack carriage on top of the weight stack. (NOTE: The convex side faces up.) (e). Tilt the guide rods back into place and then lift them up to their mounting position.

  • Page 14: Step 6 Apply The Weight Stack Sticker

    STEP 6 Apply the Weight Stack Sticker (a). Align and tape the cardboard to the upper left corner of the weight stack. (b). Peel off the top half of the weight sticker (A22) backing. Note: leave the clear outside margin in place on the sticker. Don’t peel off the margin. *If there is additional optional counterweight, use the optional counterweight labels.

  • Page 15: Step 7 Install Front Cover Bottom Bracket

    STEP 7 Install Front Cover Bottom Bracket (a). Remove the screws (35) from the bottom front area of the main frame assembly (A1). (b). Secure the front cover bottom bracket (A16) with screws (35).

  • Page 16: Step 8 Install Cover Support Plate

    STEP 8 Install Cover Support Plate (a). Remove screws (36) from the main frame assembly (A1). (b). Place the front cover support plates (A8) and rear cover support plate (A7) outside of the side tabs. Align the holes with the front cover center sup- port plate (A17) and use screws (36) secure the assembly.

  • Page 17: Step 9 Install The Cable

    STEP 9 Install the Cable (a). Remove the screws (37) from the cable ball on the connector assembly pulleys (A12) (A13). (b). Start from the bottom end of the connector assembly pulleys (A12) (A13) follow the direction of the arrows to install the cable. (Note: Make sure the cable goes through the pulleys).

  • Page 18: Step 10 Install The Cover

    STEP 10 Install the Cover (a). Secure the rear cover support plate with screws (36).
  • Page 19 STEP 10 Install the Cover (Continued) (a). Set the front cover into the front cover support plate’s groove (A8), then align holes and secure the assembly with screws (12).

  • Page 20: Step 11 Install The Tower Covers

    STEP 11 Install the Tower Covers (a). Use screws (13) to secure the Front Cover (A6) to the Main Frame (A1) (b). Then press the square screw inserts (14) into the support plate. (c). Use screws (13) to secure the Back Cover (A5) to the Main Frame (A1)

  • Page 21: Step 12 Install The Hooks

    STEP 12 Install the Hooks (a). Remove the screws (39) from the main frame (A1). (b). Use screws (39) to secure the hooks (A20) onto the main frame (A1).
  • Page 22 STEP 13 Level the Product If the machine is not stable on the ground, please follow step (a, b) to adjust the leveler. (Note: adjust the rear leveler nut of the machine first, then the front) (a) Loosen the leveler nut, rotate the leveler downward so it firmly touches the floor.

  • Page 23: Step 14 Additional Weight Stack Installation Instruction

    STEP 14 Additional Weight Stack Installation Instruction (a) First, remove the front and back covers from the main frame. (b) Remove the screws that secure the guide rods to the top of the main frame, and then set the guide rod downward into place. Tilt the guide rod backward, and then lift the upper stack plate off the guide rods as shown.
  • Page 24 STEP 15 Additional Weight Stack Installation Instruction (c). Carefully slide down the additional weight plates one by one. Once com- plete, slide down the upper stack carriage on top of the weight stack. (Note: convex side face up) (d). Tilt the guide rods back into place and then lift them up to their mounting position.
  • Page 25 STEP 15 Additional Weight Stack Installation Instruction (e). Reattach the front and back tower covers to the main frame. (f). Remove the screws from the adjustment pulley assembly, please make sure the adjustment pulley is lifted to the highest position, and then secure the assembly with the screws.

  • Page 26: Operate The Product

    5. OPERATE THE PRODUCT OPERATION Operate the Product (a) Test both pulley handles to confirm they operate correctly. (b) Insert the stack fork (selector pin) to make sure that every weight plate can be engaged easily. *NOTE: Regarding the decaled resistance on the unit weight stack, the actual weight being lifted is configured at a (per handle) ratio of 4:1.
  • Page 27 OPERATION Operate the Product (c) If the cable is too loose or too tight (shown below). First insert the (Z) rod and loosen the (Y) nut. Then, adjust the (X) nut. Note: if the cable is too long or too short still, fine tune the cable to appropri- ate length and tighten up the (Y) nut after adjustment.

  • Page 28: Operation Exercising Instructions

    OPERATION Exercising Instructions...

  • Page 29: Maintenance

    6. MAINTENANCE This section covers maintenance topics and includes a maintenance sched- ule, task list, and log. MAINTENANCE Schedule Area Week Month Quarter Year Notes Exterior Clean. Screws Inspect for looseness and tighten if necessary. Cable Inspect for wear. Guide rods Clean and lubricate.

  • Page 30: Maintenance Task List

    MAINTENANCE Task List Like cars, fitness products require maintenance. Regular maintenance ex- tends product life, and failure to maintain products can void the manufac- turer’s warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. Daily tasks 1.

  • Page 31: Maintenance One-Year Maintenance Log

    MAINTENANCE One-Year Maintenance Log Facility:_______________________ Supervisor:____________________ Product model number:__________ Serial number:_________________ Start date: ____________________ End date:_____________________ Daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Week 22-28 Completed Daily Tasks Week 29-35 Week 36-42 Week 43-49 Week 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28...

  • Page 32: Consignes De Sécurité Importantes

    7. CONSIGNES DE SÉCURITÉ IMPORTANTES Le produit SportsArt a été conçu et fabriqué afin d’assurer une sécurité optimale. Cepen- dant certaines précautions s’appliquent chaque fois que vous utilisez votre produit. • Lisez entièrement le manuel avant l’assemblage et l’utilisation. Veuillez aussi noter les consignes de sécurité...
