Summary of Contents for Atlona AT-UHD-SW-51
-
Page 1: User Manual
4K/UHD 5 Input HDMI Switcher AT-UHD-SW-51 User Manual Please check http://www.atlona. com/AT-UHD-SW-51 for the most recent firmware update or manual Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 1: User Manual
4K/UHD 5 Input HDMI Switcher AT-UHD-SW-51 User Manual Please check http://www.atlona.com/UHD-SW-51.html for the most recent firmware update or manual. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 2: Table Of Contents
7. Captive Screw ....................5 8. WebGUI ....................6-11 9. RS-232 ....................12-14 10. Installation Diagram ....................15 11. Specifications ....................16 12. Safety Information ....................17 13. Warranty ....................18-19 14. Registration ....................19 Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 2: Table Of Contents
7. Captive Screw ....................5 8. WebGUI ....................6-11 9. RS-232 ....................12-14 10. Installation Diagram ....................15 11. Specifications ....................16 12. Safety Information ....................17 13. Warranty ....................18-19 14. Registration ....................19 Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
• Digital audio de-embedding through the S/PDIF output for up to DTS 5.1™ and Dolby Digital ® • Two channel PCM and LPCM de-embedding through analog output • EDID management • Easy to use webGUI through TCP/IP connection • Half-rack size with rack mount ears Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
• Digital audio de-embedding through the S/PDIF output for up to DTS 5.1™ and Dolby Digital ® • Two channel PCM and LPCM de-embedding through analog output • EDID management • Easy to use webGUI through TCP/IP connection • Half-rack size with optional rack mount ears Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 4: Panel Descriptions
POWER INPUT HDMI 2 HDMI 3 HDMI 4 HDMI 5 AT-UHD-SW-51 AUDIO RS-232 1. HDMI LEDs - Illuminates to indicate the selected source S/PDIF OUT RX TX 2. Power Button - Turns switcher on or places it in standby mode... -
Page 4: Panel Descriptions
Video 2 3. Input selection: Selects source Note: On/off video 2, audio, and setup buttons are not functional for the Input Audio Vol + UHD-SW-51 switcher Vol - Mute Setup Menu Enter Return SW-R1 Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 5: Arc
Bidirectional HDMI w/ARC signal Audio loop-out HDMI 1 POWER INPUT HDMI 2 HDMI 3 HDMI 4 HDMI 5 S/PDIF audio loop-out AT-UHD-SW-51 AUDIO RS-232 HDMI S/PDIF OUT RX TX Game Console HDMI IN HDMI OUT DC 5V Bidirectional HDMI ARC signal Captive Screw Captive screw connectors are an added feature on the UHD-SW. -
Page 5: Arc
RS-232 pin out will be determined by the RS-232 cable and will connect as Rx (receiver), Tx (transmitter), (ground). (See picture 4) RS-232 Power Pin out color Black: - White: + will differ per RS-232 cable. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... - Page 6 IP address set using RS-232 commands or the webGUI. TCP/IP WebGUI Atlona has created an easy to use WebGUI for initial setup and later changes to the configuration of the UHD-SW. To begin, plug a LAN cable into the LAN port of the UHD-SW and your network, then type the IP...
- Page 6 IP address set using RS-232 commands or the webGUI. TCP/IP WebGUI Atlona has created an easy to use WebGUI for initial setup and later changes to the configuration of the UHD-SW. To begin, plug a LAN cable into the LAN port of the UHD-SW and your network, then type the IP...
-
Page 7: Webgui
If your control system supports password protection, you can turn login mode on. The GUI always requires a password. Note: The username and password used in IP Login Mode will be the same login information as the WebGUI. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 7: Webgui
If your control system supports password protection, you can turn login mode on. The GUI always requires a password. Note: The username and password used in IP Login Mode will be the same login information as the WebGUI. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... - Page 8 Source - Select one of the five inputs to be routed to the output. Audio Settings Output 1 - Turns HDMI audio output on or off. ARC Settings Output 1 - Turns ARC on or off. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 8 Source - Select one of the five inputs to be routed to the output. Audio Settings Output 1 - Turns HDMI audio output on or off. ARC Settings Output 1 - Turns ARC on or off. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 9 Note: User information will display for the admin only. Up to 3 users other than admin can be added. Note: Only the admin password can be changed. The username will always remain “root”. If the admin password is lost the system must be returned to factory settings and setup repeated. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 9 Note: User information will display for the admin only. Up to 3 users other than admin can be added. Note: Only the admin password can be changed. The username will always remain “root”. If the admin password is lost the system must be returned to factory settings and setup repeated. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 10 Note: Internal EDIDs include audio EDIDs as well. 2Ch is two channel audio, MCh is multi-channel audio (including up to Dolby TrueHD or DTS-HD Master Audio), DD is Dolby Digital, and DVI does not include audio. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 10 Note: Internal EDIDs include audio EDIDs as well. 2Ch is two channel audio, MCh is multi-channel audio (including up to Dolby TrueHD or DTS-HD Master Audio), DD is Dolby Digital, and DVI does not include audio. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
- Page 11 Download the latest firmware from http://www.atlona.com then update the unit using this function. Click the browse button and select the firmware to be loaded. Once selected, press the upload button. The progress bar will display the progress of the firmware update.
- Page 11 Download the latest firmware from http://www.atlona.com then update the unit using this function. Click the browse button and select the firmware to be loaded. Once selected, press the upload button. The progress bar will display the progress of the firmware update.
-
Page 12: Rs-232
RS-232 is connected through a 9-pin female D connector. The pins will have functions associated with them, some will be unassigned. Function ---- Not used Transmit Receive ---- Not used Ground ---- Not used ---- Not used ---- Not used ---- Not used Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 12: Rs-232
RS-232 is connected through a 9-pin female D connector. The pins will have functions associated with them, some will be unassigned. Function ---- Not used Transmit Receive ---- Not used Ground ---- Not used ---- Not used ---- Not used ---- Not used Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... - Page 13 Displays the software versions: ex. VersionMCU Ex. Version OSD Ex. Version x.x.xx firmware [MCU] OSD menu [OSD] DSP [DSP] FPGA [FPGA] Type AT-UHD-SW-51 Displays the model information Mreset Mreset Reset device to manufacture default Lock Lock Locks the front panel buttons...
- Page 13 Displays the software versions: ex. VersionMCU Ex. Version OSD Ex. Version x.x.xx firmware [MCU] OSD menu [OSD] DSP [DSP] FPGA [FPGA] Type AT-UHD-SW-51 Displays the model information Mreset Mreset Reset device to manufacture default Lock Lock Locks the front panel buttons...
- Page 14 IPQuit Logs out of TCP/IP Connection IPAddUser X Y TCP/IP user was added Adds a user for TCP/IP control Ex. IPAddUser Atlona 1234 X= user and Y= Password IPAddUser username password Displays a list of users and passwords username password...
- Page 14 IPQuit Logs out of TCP/IP Connection IPAddUser X Y TCP/IP user was added Adds a user for TCP/IP control Ex. IPAddUser Atlona 1234 X= user and Y= Password IPAddUser username password Displays a list of users and passwords username password...
-
Page 15: Installation Diagram
Connections and Installation Video Audio Control HDMI 1 POWER INPUT HDMI 2 HDMI 3 Game Console HDMI 4 HDMI 5 A/V Receiver 5.1Ch AT-UHD-SW-51 AUDIO RS-232 S/PDIF OUT RX TX HDMI IN HDMI OUT DC 5V ZIGBEE 12V DC FACTORY HDMI COMPONENT... -
Page 15: Installation Diagram
DC 5V ZIGBEE 12V DC FACTORY HDMI COMPONENT WIFI 1 DIGITAL eSATA RESTORE COAX OUT RELAYS WIFI 2 SERIAL 1 AUDIO IN CONTACTS IR OUT VIDEO OUT AUDIO OUT ETHERNET SERIAL 2 Control System Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 16: Specifications
1.73 x 8.75 x 10.28 (inch) Rack size 1/2 rack, 1RU Weight Device 3.10 kg 1.40 lbs Certification Power Supply CE, FCC, cULus, RCM Product CE, FCC *4096x2160@50/60Hz & 3840x2160@50/60Hz supported @ chroma subsampling 4:2:0 8-bit only Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 16: Specifications
H x W x D 44 x 222.25 x 261 (mm) 1.73 x 8.75 x 10.28 (inch) Rack size 1/2 rack, 1RU Weight Device 3.10 kg 1.40 lbs Certification Power Supply CE, FCC, cULus, RCM Product CE, FCC Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 17: Safety Information
Attempting to do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your product. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 17: Safety Information
It may also cause damage to your product. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 18: Warranty
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976 (US toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at www.atlona.com. -
Page 18: Warranty
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976 (US toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at www.atlona.com. -
Page 19: Registration
Atlona’s products may be used in conjunction with. Atlona, at its sole discretion, reserves the right not to extend its warranty offering in instances arising outside its normal course of business including, but not limited to, damage inflicted to its products from acts of god. -
Page 19: Registration
Atlona’s authorized distributors, dealers and resellers can be found at www.atlona.com. Atlona Product Registration Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
