Foodservice Filtration Systems
Foodservice Filtration Systems
DO NOT DISCARD - GIVE THIS MANUAL TO THE OWNER AFTER INSTALLATION
● Installation must conform to all local plumbing codes and regulations.
● Do NOT use with water that is microbiologically unsafe or of unknown quality without adequate disinfection
before or after the system.
● Connect system to cold water supply only! Water temperature must not exceed 100°F/38°C.
● Do NOT solder plumbing connections attached to the fi lter housing or inlet valve. High temperature will
damage these components.
● Do NOT over-tighten fi tting connections into inlet valve or housing outlet. Always back-up valves and
fi ttings with a wrench to avoid turning the valve.
● Allow a minimum of 3" under the housing to allow for sump removal and fi lter replacement.
● Do NOT mount the system near a heat source or above the electrical wiring or any device or area that
would be adversely affected by water.
● Do NOT mount the system behind equipment. The unit must be easily accessible for fi lter replacement.
● Failure to change cartridges per recommended intervals with OptiPure replacement cartridges may lead to
system failure and property damage.
Introduction
Your new OptiPure QT-Series FoodService Filtration System will cleanse and condition the tap water providing
optimum water characteristics for their specifi ed applications. The result is reduced equipment maintenance require-
ments, longer equipment life and improved quality & consistency of your products. The OptiPure System is built with
the fi nest, most advanced materials and each system is quality inspected and pressure tested prior to shipment.
Proper system installation and routine fi lter changes will ensure years of trouble-free operation and performance.
Please refer to this manual when performing routine fi lter changes. The instructions make periodic mainte-
nance quick and easy, and ensure you will receive maximum benefi t from your system.
System/Operating Specifi cations &Dimensions
System/Operating Specifi cations &Dimensions
Maximum Pressure: 125 psi/8.6 bar
Inlet/Outlet Connections: 3/8" fnpt
Capacity: Change filters at gallon rating or at least every 6 months, or when pressure gauge needle enters the red
zone on the outlet gauge while water is flowing through the filter system under normal operating conditions.
Model QT10-1
Model QT10-1
Capacity: 15,000 gals./56,700 L
Service Flow Rate: 1.5 gpm/5.67 lpm
Installation, Operation & Maintenance Manual
Reduce Particulate, Chlorine, Taste & Odor
For QT Series Models: QT10-1, QT10-2, QT-1, QT-1+, QT-2, QT-2+, QT-3
Maximum Temperature: 100°F/38°C, Min.: 35°F/2°C
Model QT10-2
Model QT10-2
Capacity: 30,000 gals./113,400 L
Service Flow Rate: 3.0 gpm/11.34 lpm
QTiom908
