Foodservice Filtration Systems
NOTICE TO INSTALLER:
DO NOT DISCARD THIS MANUAL AFTER INSTALLATION.
OPERATION, MAINTENANCE AND PRECAUTIONARY INFORMATION. PLEASE PRESENT THIS MANUAL
TO USER/OPERATOR/OWNER AFTER INSTALLATION.
IT IS STRONGLY ENCOURAGED THAT YOU READ THIS MANUAL BEFORE INSTALLING SYSTEM TO
ENSURE THE BEST POSSIBLE INSTALLATION.
INSTALLATION MUST CONFORM TO ALL LOCAL AND STATE PLUMBING CODES AND REGULATIONS.
CONNECT SYSTEM TO COLD WATER SUPPLY ONLY. WATER TEMP. CAN NOT EXCEED 100°F/28°C.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY
WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
NOTICE TO USER/OPERATOR/OWNER:
PLEASE COMPLETE THE PRODUCT REGISTRATION CARD
TURER. PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE FOR PARTS, MAINTENANCE OR
TROUBLE-SHOOTING.
IT IS RECOMMENDED THAT ALL PERSONNEL RESPONSIBLE FOR OPERATION AND MAINTENANCE
OF THIS PRODUCT READ THE PRECAUTIONS, OPERATION AND MAINTENANCE SECTIONS OF THIS
MANUAL.
Introduction
Your new OptiPure FX-Series FoodService Filtration System will cleanse and condition the tap water providing
optimum water characteristics for their specified applications. The result is reduced equipment maintenance require-
ments, longer equipment life and improved quality & consistency of your products. Proper system installation and
routine filter changes will ensure years of trouble-free operation and performance.
The OptiPure System is built with the finest and most advanced materials and each system is quality inspected and
pressure tested prior to shipment. With proper installation and routine maintenance, you will have years of trouble-
free operation.
Please refer to this manual when performing routine filter changes. The instructions make periodic maintenance quick
and easy, and ensure you will receive maximum benefit from your system.
System Specifications
Maximum Pressure: 125 psi/8.6 bar
Inlet/Outlet Connections: 1/2" fnpt
Gallon Rating: FX-21: 30,000 gals./113,400 ltrs. FXC-21: 18,000 gals./68,130 ltrs.
FXS-21: 15,000 gals./56,775 ltrs. FXCS-21: 18,000 gals./68,130 ltrs.
Capacity: Change filters at gallon rating or at least every 6 months or when pressure gauge needle enters the red zone on the
outlet gauge while water is flowing through the filter system under normal operating conditions.
Installation, Operation & Maintenance Manual
Maximum Temperature: 100°F/38°C, Min.: 35°F/2°C
Service Flow Rate: 1.5 gpm /5.7 lpm
1
for OptiPure FX Series Systems
Models: FX-21, FXC-21, FXS-21, FXCS-21
THIS MANUAL CONTAINS IMPORTANT
AND MAIL OR FAX TO MANUFAC-
FX21iom104
Advertisement
Related Manuals for OptiPure FX-21
Summary of Contents for OptiPure FX-21
-
Page 1: System Specifications
The OptiPure System is built with the finest and most advanced materials and each system is quality inspected and pressure tested prior to shipment. With proper installation and routine maintenance, you will have years of trouble- free operation. -
Page 2: Installation Precautions
Run a suitable line from the 1/2” full-flow ball valve at the tap water source to the inlet ball valve on the le� side of the OptiPure system. Use 2-3 wraps of teflon tape and brace the inlet ball valve on the system with a wrench when connecting the feed water line. - Page 3 11. If no leaks turn on equipment and check for normal operation. 12. A�ach the Service Log to the Installed OptiPure System and fill in install date. 13. Register your warranty using the enclosed warranty card or go to www.filterxpress.com Installation Drawings &...
-
Page 4: Operation
Pressure Gauge Monitoring Periodically monitor the pressure gauge on the OptiPure unit. If the needle on the gauge ever enters the red zone it may be an indication that the filters have become clogged with sediment. Ideally the pressure should never drop into the red zone. -
Page 5: Replacement Filter Cartridges
Replacement Filter Cartridges OptiPure Filter Systems are designed, tested, and certified with FilterXpress filter cartridges with proven perfor- mance, size and operating capacities. Use of replacement cartridges other than those specified will void warranties, certifications and may compromise equipment protection, water quality and cartridge life.
