OptiPure ScaleX2 SX2-21 Installation, Operation & Maintenance Manual

DO NOT DISCARD - GIVE THIS MANUAL TO THE OWNER AFTER INSTALLATION
DO NOT DISCARD THIS MANUAL AFTER INSTALLATION. THIS MANUAL CONTAINS IMPORTANT OP-
ERATION, MAINTENANCE AND PRECAUTIONARY INFORMATION. PLEASE PRESENT THIS MANUAL TO
USER/OPERATOR/OWNER AFTER INSTALLATION.
IT IS STRONGLY ENCOURAGED THAT YOU READ THIS MANUAL BEFORE INSTALLING SYSTEM TO
ENSURE THE BEST POSSIBLE INSTALLATION.
INSTALLATION MUST CONFORM TO ALL LOCAL AND STATE PLUMBING CODES AND REGULATIONS.
CONNECT SYSTEM TO COLD WATER SUPPLY ONLY. WATER TEMP. CAN NOT EXCEED 100°F/38°C.
SYSTEM MUST BE INSTALLED IN A VERTICAL AND UPRIGHT POSITION.
SCALEX2 SYSTEMS MUST NOT BE USED IN CONJUNCTION WITH POLYPHOSPHATE OR ANY OTHER
®
SCALE INHIBITOR.
DO NOT INSTALL FILTERS DOWNLINE FROM THE SCALEX2
FILTER SYSTEM BEFORE THE EQUIPMENT.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY WITH-
OUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
FAILURE TO CHANGE CARTRIDGES PER RECOMMENDED INTERVALS WITH OPTIPURE REPLACE-
MENT CARTRIDGES MAY LEAD TO SYSTEM FAILURE AND PROPERTY DAMAGE.
Introduction
Your new OptiPure ScaleX2
mum water characteristics for specified applications. Results include reduced equipment-maintenance requirements,
longer equipment life and improved quality and consistency of your products. Proper system installation and routine
filter changes ensure years of trouble-free operation and performance.
The OptiPure System is built with the finest and most advanced materials. Each system is quality inspected and
pressure-tested prior to shipment. With proper installation and routine maintenance, you should have years of
trouble-free operation.
Please refer to this manual when performing routine filter changes. The instructions make periodic maintenance quick
and easy, and ensure that you should receive maximum benefit from your system.
System Specifications
Maximum Pressure: 125 psi/8.6 bar
Capacity: Change the CTO (pre-filter) cartridge at gallon rating, or at least every 6 months or when pressure gauge
needle enters the red zone on the outlet gauge while water is flowing through the filter system under normal operating
conditions. The SCLX2 cartridge does not have a grain removal capacity; however, naturally occurring organics pres-
ent in the water will gradually degrade the effectiveness of this cartridge. Change the SCLX2 cartridge at least once
a year.
Installation Precautions
• Do NOT install system on line pressure above 125 psi.
• Do NOT install the system backwards with the feed water line connected to the outlet.
• Do NOT use liquid pipe compounds for fitting connections. USE two to three wraps of teflon tape.
• Do NOT solder plumbing connections attached to filter housing or inlet valve. Inlet valve and filter housing will
be damaged by high temperature.
• Do NOT allow system to freeze. Turn off water supply to housing and drain housing if temperature falls below 32°F.
• Do NOT install system in direct sunlight or where system is exposed to harsh chemicals, or where it may be
subjected to being struck by moving equipment, carts, mops or any other item that may cause damage.
• ALLOW a minimum of 3" under the housing to allow for filter replacement.
Installation, Operation & Maintenance Manual
FoodService Filtration System will cleanse and condition the tap water, providing opti-
®
Maximum Temperature: 100°F/38°C, Min.: 35°F/2°C
Reduce Particulate, Chlorine, Taste, Odor & Scale
For ScaleX2
SYSTEM. SCALEX2
®
Models: SX2-21, SX2-22
®
MUST BE THE LAST
®
