DO NOT DISCARD - GIVE THIS MANUAL TO THE OWNER AFTER INSTALLATION.
DO NOT DISCARD THIS MANUAL AFTER INSTALLATION. THIS MANUAL CONTAINS IMPORTANT
OPERATION, MAINTENANCE AND PRECAUTIONARY INFORMATION. PLEASE PRESENT THIS MANUAL
TO USER/OPERATOR/OWNER AFTER INSTALLATION.
IT IS STRONGLY ENCOURAGED THAT YOU READ THIS MANUAL BEFORE INSTALLING SYSTEM TO
ENSURE THE BEST POSSIBLE INSTALLATION.
INSTALLATION MUST CONFORM TO ALL LOCAL AND STATE PLUMBING CODES AND REGULATIONS.
CONNECT SYSTEM TO COLD WATER SUPPLY ONLY. WATER TEMP. CAN NOT EXCEED 100°F/38°C.
SYSTEM MUST BE INSTALLED IN A VERTICAL AND UPRIGHT POSITION.
SCALEX2
SYSTEMS MUST NOT BE USED IN CONJUNCTION WITH POLYPHOSPHATE OR ANY OTHER
®
SCALE INHIBITOR.
DO NOT INSTALL FILTERS DOWNLINE FROM THE SCALEX2
FILTER SYSTEM BEFORE THE EQUIPMENT.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY
WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
FAILURE TO CHANGE CARTRIDGES PER RECOMMENDED INTERVALS WITH OPTIPURE REPLACE-
MENT CARTRIDGES MAY LEAD TO SYSTEM FAILURE AND PROPERTY DAMAGE.
Introduction
Your new OptiPure ScaleX2
characteristics for specified applications. Results include reduced equipment-maintenance requirements, longer
equipment life and improved quality and consistency of your products. Proper system installation and routine filter
changes ensure years of trouble-free operation and performance.
The OptiPure System is built with the finest and most advanced materials. Each system is quality inspected and
pressure-tested prior to shipment. With proper installation and routine maintenance, you should have years of
trouble-free operation.
Please refer to this manual when performing routine filter changes. The instructions make periodic maintenance quick
and easy, and ensure that you should receive maximum benefit from your system.
Operating Specifications
Maximum Pressure:
Installation Precautions
• Do NOT install system on line pressure above 125 psi.
• Do NOT install the system backwards with the feed water line connected to the outlet.
• Do NOT use liquid pipe compounds for fitting connections. USE two to three wraps of teflon tape.
•
Do NOT solder plumbing connections attached to filter housing or inlet valve. Inlet valve and filter housing will
be damaged by high temperature.
• Do NOT allow system to freeze. Turn off water supply to housing and drain housing if temperature falls below 32°F.
• Do NOT install system in direct sunlight or where system is exposed to harsh chemicals, or where it may be
subjected to being struck by moving equipment, carts, mops or any other item that may cause damage.
• ALLOW a minimum of 3" under the housing to allow for filter replacement.
• IF water hammer is evident, install water hammer arrestors before OptiPure unit.
• Do NOT overtighten fitting connections into inlet valve our housing outlet.
• Always back-up valves and fittings with a wrench when installing a fitting to avoid turning the valve.
• Do NOT install the unit behind equipment where it may be difficult to access the system for filter replacement.
Installation, Operation & Maintenance Manual
FoodService Filtration System will condition the tap water, providing optimum water
®
125 psi/8.6 bar
For ScaleX2
Models: SX2-11, SX2-12, SX2-12B
®
SYSTEM. SCALEX2
®
Maximum Temperature: 100°F/38°C
Minimum Temperature: 35°F/2°C
Reduce Scale
MUST BE THE LAST
®
Advertisement
Related Manuals for OptiPure ScaleX2 SX2-11
Summary of Contents for OptiPure ScaleX2 SX2-11
- Page 1 The OptiPure System is built with the finest and most advanced materials. Each system is quality inspected and pressure-tested prior to shipment. With proper installation and routine maintenance, you should have years of trouble-free operation.
- Page 2 1/2” FNPT Position the OptiPure unit in a suitable location. The direction of flow through the OptiPure unit is always left to right; keep this in mind when determining installation location. Do NOT mount the OptiPure system near any source of heat.
- Page 3 Operation With adequate pressure, normal operation of the ScaleX2 System is completely automatic. Dependable operation ® involves only periodic filter changes and service documentation. Maintenance The only routine maintenance your ScaleX2 System should ever require is ® periodic filter cartridge changes or replacement sump O-rings. Filter changes are necessary for optimum performance of your foodservice equipment.
- Page 4 Replacement Filter Cartridges OptiPure Filter Systems are designed, tested, and certified with FilterXpress filter cartridges with proven performance, size and operating capacities. Use of replacement cartridges other than those specified will void warranties and certifications, and may compromise equipment protection, water quality and cartridge life.
