ABM/AFM/AFS/ATM CONTENTS ELECTRONIC WEIGHING INDICATOR 1. INSTALLATION OPERATION MANUAL 2. SPECIFICATIONS 3. KEYBOARD LAYOUT AND DESCRIPTION PLEASE READ THIS MANUAL VERY CAREFULLY BEFORE 4. INITIAL SETUP ATTEMPT TO OPERATE THIS INDICATOR 5. INSTRUCTION FOR USE 6. TROUBLE SHOOTING 7. DAILY CARE AND MAINTENANCE... -
Page 2: Installation
1. INSTALLATION 2. SPECIFICATIONS Because of metrological legislation, installation/some Model No. ABM/AFM/AFS/ATM INDICATOR metrological parameter settings are limited to be done Max. USER DEFINED by authorized personnel only. Do not attempt to change 3000 (NOTE 1) Tare Range 1/3 Max. ¡ e (NOTE 2) any of the built-in parameters. -
Page 3: Keyboard Layout And Description
3. KEYBOARD LAYOUT AND DESCRIPTION NOTE 2: When under OIML mode, for Multi range or interval, change e to e . When under non-OIML mode, the default setting is full tare range. NOTE 3: For Multi range or interval, change e to e (MODEL SHOWN: ATM) 1. - Page 4 4. MR KEY 11. AVERAGE INDICATOR Press this key to recall the total accumulated weight This indicator flashes to indicate the digital motion from memory. filtering function is being employed. 5. TARE KEY Press this key to tare off the weight of a container. 12.
-
Page 5: Initial Setup
4. INITIAL SETUP Scale is off 4.1 PLACING THE SCALE Press and hold TARE, then press ON/OFF In order to obtain an accurate weighing result, the Scale displays F.1 complete weighing instrument (hereinafter referred as Press TARE three times to F.4 the scale) must be placed on a strong and level surface. -
Page 6: For Manual Sending, Press Tare When Display Shows
When the preferred transmission protocol shows on when display shows Filt.0 display, press TARE to confirm and proceed to the f. After TARE is pressed, indicator display F.7 next selection or ZERO to restart the scale g. Press MODE to enter next set up or ZERO to restart the scale NOTE: The default data output format of the scale is... - Page 7 4.2.6. Select Printer Output Mode Press and hold TARE, then press ON/OFF There are two selectable printout formats to choose Scale displays F.1 according to end user preference. FORMAT 1 will print Press TARE eight times in table form when press M+ and FORMAT 2 will only print Scale displays F.9 the stabled weight detects when press M+.
-
Page 8: Instruction For Use
5. INSTRUCTION FOR USE NOTE: 5.1 BEFORE WEIGHING To comply with the law of certain countries and certain Make sure that: approval requirements, the avoirdupois weight units may Connect the load cell signal and power to the be disabled. Contact your dealer for more information. indicator properly Place the scale on a level and strong surface 5.4 TURN BACKLIGHT (OPTIONAL) ON/OFF... - Page 9 Refer to SPECIFICATIONS for maximum zero range. to SPECIFICATIONS for maximum tare range. NOTE: NOTE: -When scale is set at OIML and application is legal for - When scale is set at OIML and application is legal trade. User only needs to press ZERO once when setting for trade.
- Page 10 transaction to memory When the total accumulated weight is being displayed, c. Indicator displays ¡P. X¡¨ andM+ INDICATOR appears MR INDICATOR appears to indicator that the value being to indicate that memory contains of stored data displayed is the total accumulated weight. Indicator NOTE: ¡P.
-
Page 11: Trouble Shooting
----- 6. TROUBLE SHOOTING Syndrome Indicator displays Check Is the load cell signal cables connected to the indicator properly? Syndrome Indicator cannot be turned on Check: Is the indicator powered properly? Action Recheck signal cable connections. Action: Check power supply to indicator. Check Is load cell working properly? Action... -
Page 12: Daily Care And Maintenance
7. DAILY CARE AND MAINTENANCE APPENDIX: APPEARANCE Clean the indicator with a soft and damp cloth. MODEL SHOWN: ABM/AFM If necessary, apply a mild detergent. Do not use any harsh, abrasive material, acetone, volatile solvent, thinner or alcohol for cleaning. - Page 13 Manufacturer: Enterprise Fabricant Co., Ltd. Typ/Modell: Type/Model: ABM/AFM/AFS/ATM Type/modele: Nr. der EG-Bauartzulassung (gegebenen falls): T6126 No of the EC type-approval certificate (where applicable): No du certificat d'approbation CE de type (le cas echeant): entspricht dem in der Bescheinigung uber die Bauartzulassung beschriebenen...
