VFS-300LED range Installation and user
manual
Installation and user instructions for:
VFS-300LED Range of flat screen monitors

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFS-300LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vista VFS-300LED

Summary of Contents for Vista VFS-300LED

  • Page 1 VFS-300LED range Installation and user manual Installation and user instructions for: VFS-300LED Range of flat screen monitors...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS  CE information ------------------------------------------------------------------------ 4  Safety Precautions ------------------------------------------------------------------- 4 Scope -------------------------------------------------------------------------------------- 6 Functional specification ------------------------------------------------------------- 6 Controls and indicators -------------------------------------------------------------- 9 OSD Menu ------------------------------------------------------------------------------- 10 Regulatory Agency ------------------------------------------------------------------- 22 Reliability ------------------------------------------------------------------------------ 22 Mechanical ------------------------------------------------------------------------------ 23...

  • Page 4: Ce Information

    CE INFORMATION The product must be installed according to the currently valid installation regulations for EMC to guarantee the designed use and to prevent EMC problems. The device supplied with this manual is according to the EC, EMC Directive, 2004/108/EC, LVD 2006/95/EC and RoHS 2011/65/EU SAFETY PRECAUTIONS 1.
  • Page 5 When replacement parts are required, be sure that the service technician uses components specified by the manufacturer which have the same characteristics as the original parts. UNAUTHORIZED SUBSTITUTIONS MAY RESULT IN FIRE, ELECTRICAL SHOCK OR OTHER HAZARDS. Upon completion of any service or repairs, ask the technician to perform safety checks to determine that the equipment is in safe operating condition.

  • Page 6: Scope

    1. Scope This specification is used to define the performance of VFS series color TFT LCD (LED Backlit) monitor. This system supports both video input and PC input. In video input mode, the system can automatically detect PAL or NTSC signals. In PC mode, this system can support up to 1280 x 1024 VESA standard.
  • Page 7 2.4 HDMI Input HDMI 1.3 Compatible Interface HDMI Timing Modes 480i / 480p 576i / 576p 720p 1280 x 1024 2.5 Audio Input Signal Level: 1.0 Vrms 2.6 Environmental  Temperature Operating: 0 C to +40 Storage: -20 C to +60 ...
  • Page 8 2.8 Connectors VIDEO AUDIO: Stereo Phone Jack x2, OUT x1, IN x1 CVBS 1: BNC x2, OUT x1, IN x1 CVBS 2: BNC x2, OUT x1, IN x1 S-VIDEO (Y/C): Mini-DIN 4 pins, input only VGA: D-SUB 15 pins connector HDMI: HDMI connector DC JACK: DC12V in, 5.5 / 2.5...

  • Page 9: Controls And Indicators

    3. Controls and indicators A. “i” Channel button  Press the button to select input signal. B. “-“ / “+” buttons  Press the buttons to scrolling the cursor to desired function.  Press the buttons to adjust the value of selected function in sub OSD menu. C.

  • Page 10: Osd Menu

    4. OSD Menu Hot key - / + VOLUME：Press button to enter the function and press buttons to adjust the volume value, then press MENU button to exit OSD menu. FREEZE：Press button to enter the function and press any button to release the function.
  • Page 11 PC mode MAIN ADJUST, COLOR ADJUST, IMAGE ADJUST (VGA only), INFORMATION, PIP/PAP SETTING, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enable MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 12 MAIN ADJUST - / + 1. Press buttons to select an item, then press MENU button to Enter adjust item or function. - / + 2. Press buttons to adjust the value, then press MENU button to Exit adjusts. VIVID MODE Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS Adjust the brightness value CONTRAST Adjust the contrast value...
  • Page 13 COLOR ADJUST Press MENU button to enter the sub-menu Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item, - / + 3.
  • Page 14 IMAGE ADJUST (VGA only) Press MENU button to enter the sub-menu - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return AUTO ADJUST Press...
  • Page 15 INFORMATION Press MENU button to get the VGA timing information PIP/PAP SETTING Press MENU button to enter the sub-menu - / + 1. Press buttons to select an icon 2. Press MENU button to select adjust item - / + 3.
  • Page 16 EXIT Press MENU button to return to the main menu LANGUAGE Press MENU button to enter the sub-menu - / + 1. Press buttons to select language 2. Press MENU button to enter SETUP MENU Press MENU button to enter the sub-menu - / + 1.
  • Page 17 OSD TIMEOUT Setting the OSD timeout (5~120 sec) STATUS LINE Enable / Disable the STATUS LINE display. (Display the CVBS1, CVBS2 and S-VIDEO signal status) The status line auto close: when the PIP is enable; the OSD is open or Auto Shift is working.
  • Page 18 RECALL Recall the Brightness, Contrast, Sharpness, Saturation, Tint, Volume value of the mode data and DLC = ENABLE, Vivid Mode = USER, OSD Timeout = 15, Green Mode = OFF, Auto Shift = OFF, PIP/PAP = OFF, SOURCE = CVBS1, LOCATION = 0, RATIO = 2, then press MENU button to return to the main menu...
  • Page 19 Video/HDMI mode MAIN ADJUST, COLOR ADJUST, SCAN SETTING, INFORMATION, PIP/PAP SETTING, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enable MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 20 MAIN ADJUST - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item, - / + 3. Press buttons to adjust the value 4. Press MENU button to return VIVID MODE Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS Adjust the brightness value CONTRAST Adjust the contrast value...
  • Page 21 TINT Adjust the tint value BACKLIGHT Adjust the backlight value 3D COMB FILTER (Video only) 3D COMB FILTER - - DISABLE / ENABLE NR Noise reduction - - LOW / MID / HIGH MPEG NR MPEG Noise reduction - - LOW / MID / HIGH DLC Dynamic Luminance Control - - DISABLE / ENABLE VOLUME Adjust the volume value EXIT Press...
  • Page 22  HDMI mode - / + 1. Press buttons to select an icon 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return OVERSCAN Select scan mode is Over scan, Under scan VFS-317 LED or 4:3(for future use) NORMAL Select scan mode is NORMAL or 4:3...

  • Page 23: Regulatory Agency

    5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN 60950-1:2006+A11:2009+A1:2010+A12:2011 5.2 EMI/EMS Emission Approvals This series design shall meet following EMI/EMS specifications: CE COMPLIANCE: EN55022:2010+AC:2011 class B, EN55024:2010, EN50130-4:2011 6.

  • Page 24: Mechanical

    7. Mechanical 7.1 Cabinet Material: Plastic Finish: Black 7.2 Dimensions Model VFS-317LED VFS-319LED...
  • Page 25 NORBAIN SD LTD 210 Wharfedale Road Winnersh Triangle Wokingham Berkshire RG41 5TP Subject to change without notice United Kingdom 3121-1213G02...
