- Page 1 VFS100LEDe series Installation and User manual VFS100 Range Installation and User manual Installation and user instructions for: VFS117/19/21WLEDe Range of Flat Screen Monitors (Including VFS-117LEDNAe – non audio versions)
-
Page 3: Table Of Contents
TABLE OF CONTENTS CE information ------------------------------------------------------------------------ 1 Safety precautions -------------------------------------------------------------------- 1 Before you begin ------------------------------------------------------------------- 3 Scope -------------------------------------------------------------------------------------- 5 Functional specification ------------------------------------------------------------- 5 Controls and indicators -------------------------------------------------------------- 7 OSD Menu --------------------------------------------------------------------------------10 Channel Selection ------------------------------------------------------------------- 22 Mechanical -------------------------------------------------------------------23... -
Page 4: Ce Information
CE INFORMATION The product must be installed according to the currently valid installation regulations for EMC to guarantee the designed use and to prevent EMC problems. The device supplied with this manual is according to the EC, EMC Directive, 2004/108/EC & LVD 2006/95/EC SAFETY PRECAUTIONS 1. - Page 5 When replacement parts are required, be sure that the service technician uses components specified by the manufacturer which have the same characteristics as the original parts. UNAUTHORIZED SUBSTITUTIONS MAY RESULT IN FIRE, ELECTRICAL SHOCK OR OTHER HAZARDS. Upon completion of any service or repairs, ask the technician to perform safety checks to determine that the equipment is in safe operating condition.
-
Page 6: Before You Begin
For assistance in installing, operating, maintaining and troubleshooting this product refer to this document and any other documentation provided. If you still have questions, please contact Norbain Technical Support and Sales: Vista, 210 Wharfedale Road, IQ Winnersh, Wokingham, Berkshire RG41 5TP, England. UK +44 (0) 118 912 5000 Note: You should be at the equipment and ready with details before calling Technical Support. - Page 7 This apparatus is manufactured to comply with the radio interference. A Declaration of Conformity in accordance with the following EU standards has been made. The manufacturer declares that the product supplied with this document is compliant the provisions of the EMC Directive 2004/108/EC, the CE Marking Directive 93/68 EEC and all associated amendments.
-
Page 8: Scope
1. Scope This specification is used to define the performance of VFS117LEDe / VFS117LEDNAe, VFS119LEDe, VFS121WLEDe & VFS124WLEDe series colour TFT LCD monitor. These monitors support both video and PC inputs. In video input mode, the system can automatically detect the NTSC signal and PAL signal. In PC mode, this system can support up to 1920 x 1080 VESA standard. - Page 9 2.5 Environmental Temperature Operating: 0 C to +40 Storage: -20 C to +60 Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.6 EDID This series of displays support EDID, but does not support DDC2B function. 2.7 Connectors D C B A.
-
Page 10: Controls And Indicators
3. Controls and indicators VFS117LEDe / VFS117LEDNAe / VFS119LEDe MONITOR A. “ ”Source button Press the button to show source menu. Select HDMI, S-Video, VGA and VIDEO input signal B. “ ”Down buttons Press the buttons to scrolling the cursor to desired function. Press the buttons to decrease the value of selected function in sub OSD menu. - Page 11 E. “ ” Power button Press the button to turn ON or turn OFF the monitor F. POWER LED Indication Green - Power on LED light off - Power off Flash Green - Sleep mode (PC mode only) VFS121WLEDe/VFS124WLEDe MONITOR A.
- Page 12 D. “ ”Volume+ buttons Press the buttons to increase volume Press the buttons to increase the value of selected function in sub OSD menu. E. “ ”Volume- button Press the buttons to decrease volume Press the buttons to decrease the value of selected function in sub OSD menu. F.
-
Page 13: Osd Menu
4. OSD Menu Hot key ： ： ： ： Quick adjust keys from front panel hot keys： ： ： ： VOLUME： VFS117LEDe & VFS119LEDe: Press button to select the function and press buttons to adjust the volume , the press MENU button to exit OSD menu. - Page 14 VGA & HDMI mode ： ： ： ： OSD Menu structure： ： ： ： Use the Source button to select the VGA, HDMI, CVBS, or S-VIDEO, the menu structure within each varies, refer to sections below on how to set-up each option. VGA / HDMI mode：...
- Page 15 MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon. 2. Press MENU button to select item, 3. VFS117LEDe / VFS117LEDNAe & VFS119LEDe: Press Down / UP buttons to adjust the value VFS121WLEDe & VFS124WLEDe: Press buttons to adjust the value 4.
- Page 16 COLOR ADJUST： ： ： ： Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item, 3.
- Page 17 IMAGE ADJUST (VGA ONLY)： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item 3. VFS117LEDe / VFS117LEDNAe & VFS119LEDe: Press Down / UP buttons to adjust the value VFS121WLEDe &...
- Page 18 LANGUAGE： ： ： ： Press MENU button to enter the sub-menu 1. Press Down / UP buttons to select language 2. Press MENU button to enter SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon 2.
- Page 19 OSD TIMEOUT：Adjust the OSD Show time (5 ~120 sec) GREEN MODE：Off or On (5 min~10 min) OFF – No function ON – Screen will reduce back light to 80% within (5 min to 10 min) Screen will back to normal when any button is being touched. AUTO SHIFT：Adjust AUTO SHIFT ON/OFF OFF –...
- Page 20 MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select item 3. VFS117LEDe / VFS117LEDNAe & VFS119LEDe: Press Down / UP buttons to adjust the value 4. VFS121WLEDe & VFS124WLEDe: Press buttons to adjust the value 5.
- Page 21 SHARPNESS：Adjust Image sharp. SATURATION：Adjust Image saturation. TINT：adjust Image tint. (NTSC only). BACKLIGHT：Adjust the backlight value VOLUME：Adjust the volume (VFS117LEDNAe without) . EXIT：Press MENU button to return to the main menu.
- Page 22 COLOR ADJUST： ： ： ： Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item, 3.
- Page 23 SCAN SETTING： ： ： ： 1. Press MENU button to select the sub-menu 2. VFS117LEDe / VFS117LEDNAe & VFS119LEDe: Press Down / UP buttons to select Scan Setting state. VFS121WLEDe & VFS124WLEDe: Press buttons to select Scan Setting state. 3. Press MENU button to return INFORMATION：...
- Page 24 SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item 3. VFS117LEDe / VFS117LEDNAe & VFS119LEDe: Press Down / UP buttons to adjust the value VFS121WLEDe & VFS124WLEDe: Press buttons to adjust the value 4.
-
Page 25: Channel Selection
AUTO SHIFT scan line EXIT：Press MENU button to return to the main menu. RECALL： ： ： ： Brightness, Contrast, Sharpness, Saturation, Tint, Volume, Vivid Mode, OSD Timeout, Green Mode, Auto Shift return to default Value. 5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD... -
Page 26: Mechanical
6. Mechanical 6.1 Cabinet Material: Plastic Finish: Black 6.2 Dimensions VFS117LEDe / VFS117LEDNAe & VFS119LEDe Monitor VFS121WLEDe & VFS124WLEDe Monitor... - Page 27 Model VFS117LEDe / VFS117LEDNAe VFS119LEDe VFS121WLEDe VFS124WLEDe Unit: mm 6.3 Dimension ( Packing ) WxHxD mm VFS117LEDe / VFS117LEDNAe: 450x467x138mm VFS119LEDe: 464x585x121mm VFS121WLEDe: 565x420x114mm VFS124WLEDe: 626x453x116mm...
- Page 28 Norbain House 210 Warfedale Road Winnersh Triangle Wokingham Berkshire RG415T 01189 125 000...
