- Page 1 USER’S MANUAL VISTA 15”/17"/19” TFT LCD MONITOR MODEL: VLFSM15D/17D/19Dh Series...
-
Page 3: Table Of Contents
Table of Contents ● FCC Information ● CE Information ● Safety Precautions 1. General Features 2. Setting Up 3. Controls and Indicators 4. On Screen Display... -
Page 4: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS 1. Do not modify the three-prong grounding type monitor power plug in any way. 2. Operate this unit only from the type of power source indicated on the label. 3. Do not block or cover ventilation openings on the back or bottom of the monitor cabinet. 4. -
Page 6: General Features
1. GENERAL FEATURES This is a high performance TFT LCD monitor up to 1280X1024 SXGA resolution. The LCD monitor has been designed for use with both PC and Video, comply with the power management regulations of VESA DPMS, supported by Plug & Play, complying with DDC1/2B. -
Page 7: Setting Up
2. SETTING UP Read this chapter for important safety information and how to set up and connect the display to your computer or camera. ․Check the attachment of monitor. There is power cord, power adapter user's manual and PC signal cable. ․Make sure the surface for placing the LCD monitor is stable and level. -
Page 8: Controls And Indicators
3. CONTROLS AND INDICATORS 3.1 FRONT PANEL A. SELECT INPUT/ AUTO-ADJ/EXIT BUTTON ․Press the button to display the input signal which are selected on the screen. ․Press the button for 2 sec. to go into auto adj. function. ․Press the button to exit OSD menu. B. - Page 9 F. KEY-LOCK FUNCTION ․Key lock- Push A+C+E button for10sec .Then the OSD Show “Key Locked” ․Key unlocked- Push A+C+E button for 10sec .Then the OSD Show “Key Unlocked” 3.2 I/O CONNECTORS VLFSM15/17D_h A. DC 12V input B. DVI-I(PC) input C. CVBS input D.
-
Page 10: On Screen Display
4. ON SCREEN DISPLAY (OSD) Press Up(+), Down(-) buttons to select an icon, Press MENU button to change the values in the sub menu, then press AUTO button to exit OSD menu. Luminance：Adjust the contrast & brightness value. Image Setup：Omit at video mode. (Focus, Clock) Image Position：Omit at video mode. - Page 11 OSD Setup：Adjust the OSD window position and display time. Language：Select the language to be used in OSD. [ ENGLISH / FRENCH / ITALIAN / GERMAN / SPANISH ] Information：Monitor information. Reset：Factory Recall and Line-Lock. Note: When Link-Lock ON, the screen will change according to input signal.
- Page 12 MODEL VLFSM15D_h VLFSM17D_h DESCRIPTION Panel type 15” TFT color LCD panel 17” TFT color LCD panel Screen size 381mm diagonal 431mm diagonal Viewable size 304.1mm (H) x 228.1mm (V) 337.9mm (H) x 270.3mm (V) Dot pitch 0.297mm x 0.297mm 0.264mm x 0.264mm...
- Page 13 MODEL VLFSM19D_h DESCRIPTION Panel type 19” TFT color LCD panel Screen size 480mm diagonal Viewable size 376.32mm (H) x 301.06mm (V) Dot pitch 0.294mm x 0.294mm Viewing angle (L/R/T/B) 70/70/75/60 Contrast ration 550:1 Brightness 270 cd/m² Resolution 1280x1024 Display color 16.2M colors Response time Power input...
- Page 16 Vista Norbain House Eskdale Road Winnersh Triangle WOKINGHAM 3121-0795G02 Bekshire RG41 5TS Phone: +44(0) 118 944 0123 Printed in Taiwan England Fax: +44(0) 118 944 0999 www.vista-cctv.com...
