VFS- 200LED range Installation and user
manual
Installation and user instructions for:
VFS-200LED Range of flat screen monitors

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFS-200LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vista VFS-200LED

Summary of Contents for Vista VFS-200LED

  • Page 1 VFS- 200LED range Installation and user manual Installation and user instructions for: VFS-200LED Range of flat screen monitors...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS  CE information ------------------------------------------------------------------------ 4  Safety Precautions ------------------------------------------------------------------- 4 Scope -------------------------------------------------------------------------------------- 6 Functional specification ------------------------------------------------------------- 6 Controls and indicators -------------------------------------------------------------- 8 OSD Menu ------------------------------------------------------------------------------- 9 Regulatory Agency ------------------------------------------------------------------- 20 Reliability ------------------------------------------------------------------------------ 20 Mechanical ------------------------------------------------------------------------------ 21...

  • Page 4: Ce Information

    CE INFORMATION The product must be installed according to the currently valid installation regulations for EMC to guarantee the designed use and to prevent EMC problems. The device supplied with this manual is according to the EC, EMC Directive, 2004/108/EC , LVD 2006/95/EC and RoHS 201165/EU. SAFETY PRECAUTIONS 1.
  • Page 5 When replacement parts are required, be sure that the service technician uses components specified by the manufacturer which have the same characteristics as the original parts. UNAUTHORIZED SUBSTITUTIONS MAY RESULT IN FIRE, ELECTRICAL SHOCK OR OTHER HAZARDS. Upon completion of any service or repairs, ask the technician to perform safety checks to determine that the equipment is in safe operating condition.

  • Page 6: Scope

    1. Scope This specification is used to define the performance of VFS series color TFT LCD (LED Backlit) monitors. This system supports both video input and PC inputs. In video input mode, the system can automatically detect PAL or NTSC signals. In PC mode, this system can support up to 1920 x 1080 (VFS-221W) VESA standard.
  • Page 7 720p 1080i / 1080p (VFS-221W) 2.5 Audio Input Signal Level: 1.0 Vrms 2.6 Environmental  Temperature Operating: 0 C to +40 Storage: -20 C to +60  Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.7 EDID This series of displays support EDID, but does not support DDC2B function.

  • Page 8: Controls And Indicators

    3. Controls and indicators A. “i” Channel button  Press the button to select input signal. B. “-“ / “+” buttons  Press the buttons to scrolling the cursor to desired function.  Press the buttons to adjust the value of selected function in sub OSD menu. C.

  • Page 9: Osd Menu

    4. OSD Menu Hot keys - / + VOLUME：Press button to enter the function and press buttons to adjust the volume value, the press MENU button to exit OSD menu.. FREEZE：Press button to enter the function and press any button to release the function.
  • Page 10 PC mode MAIN ADJUST, COLOR ADJUST, IMAGE ADJUST (VGA only), INFORMATION, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enter the MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 11 MAIN ADJUST - / + 1. Press buttons to select an item, then press MENU button to Enter adjust item or function. - / + 2. Press buttons to adjust the value, then press MENU button to Exit adjusts. VIVID MODE Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS Adjust the brightness value CONTRAST Adjust the contrast value...
  • Page 12 COLOR ADJUST Press MENU button to enter the sub-menu Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item, - / + 3.
  • Page 13 IMAGE ADJUST (VGA only) Press MENU button to enter the sub-menu - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return AUTO ADJUST Press...
  • Page 14 INFORMATION Press MENU button to get the VGA timing information LANGUAGE Press MENU button to enter the sub-menu - / + 1. Press buttons to select language 2. Press MENU button to enter SETUP MENU Press MENU button to enter the sub-menu - / + 1.
  • Page 15 - / + 3. Press buttons to adjust the value 4. Press MENU button to return OSD TIMEOUT Setting the OSD timeout (5~120 sec) GREEN MODE Off or On (5 min ~ 10 min) OFF – No function ON – Screen will reduce back light to 80% within (5 min ~ 10 min) Screen will back to normal when any buttons being touched.
  • Page 16 AUDIO CONTROL Press MENU button to enter the sub-menu - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value(ON or OFF) 4. Press MENU button to return CVBS1 Setting the audio input source in CVBS1 channel...
  • Page 17 Video/HDMI mode MAIN ADJUST, COLOR ADJUST, SCAN SETTING, INFORMATION, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enable MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 18 MAIN ADJUST - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item, - / + 3. Press buttons to adjust the value 4. Press MENU button to return VIVID MODE Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS Adjust the brightness value CONTRAST Adjust the contrast value...
  • Page 19 TINT Adjust the tint value BACKLIGHT Adjust the backlight value 3D COMB FILTER (Video only) 3D COMB FILTER - - DISABLE / ENABLE NR Noise reduction - - LOW / MID / HIGH MPEG NR MPEG Noise reduction - - LOW / MID / HIGH DLC Dynamic Luminance Control - - DISABLE / ENABLE VOLUME Adjust the volume value EXIT Press...
  • Page 20  HDMI mode (VFS-221W only) - / + 1. Press buttons to select an icon 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return OVERSCAN Select scan mode is Over scan, Under scan or 4:3 (VFS-221W only) NORMAL Select scan mode is NORMAL or 4:3 INFORMATION Press...

  • Page 21: Regulatory Agency

    5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN 60950-1:2006+A11:2009+A1:2010+A12:2011 5.2 EMI/EMS Emission Approvals This series design shall meet following EMI/EMS specifications: CE COMPLIANCE: EN55022:2010+AC:2011 class B, EN55024:2010, EN50130-4:2011 6.

  • Page 22: Mechanical

    7. Mechanical 7.1 Cabinet Material: Plastic Finish: Black 7.2 Dimensions Model VFS-217LED VFS-219LED VFS-221W...
  • Page 23 NORBAIN SD LTD 210 Wharfedale Road Winnersh Triangle Wokingham Berkshire RG41 5TP Subject to change without notice United Kingdom 3121-1224G03...
