OpenEye CM-150 Quick Installation Manual

Tamper Resistant
Indoor Mini Dome
Quick Installation Manual
Please carefully read these instructions before using this product.
Save this manual for future use.

Hardware Kit Contents

• 1/2" Rubber Grommet
• 3/4" Rubber Grommet
• Screw Pack
• Torx Driver
• Quick Install Adaptor
• Wire-Ended Power Adaptor Lead

Regulatory Compliance

Emissions FCC part 15 Class B
CE: EN55011
ICES-003
EN55022
CISPR 11
CISPR22
ANSI C63.4
Immunity
CE: EN50130-4
FCC COMPLIANCE:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in as residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try \to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced Radio/TV technician for help.
CISPR 22 WARNING:
This is a Class B product. In a domestic environment this product
may cause radio interference in which case the user may be required
to take adequate measures.
POWER SUPPLY REQUIREMENTS:
For use with listed Audio/Video product and only connected to 15W
or less power supply.
*Power supply should be a NEC Class 2 / LPS Supply.
EQUIPMENT MODIFICATION CAUTION:
Equipment changes or modifications not expressly approved by
seller, the party responsible for FCC compliance, could void the
user's authority to operate the equipment and could create a
hazardous condition.
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.

General Specifications

Model No.
Lens Focal Length
Type / Format
Scanning Element
CM-150
model no
Effective Picture Element
CM-159
Image Picture Element
Imaging DSP
Resolution (TV lines)
Minimum Illumination
S/N Ratio
Back Light Compensation
Exposure Control
Sync System
Gamma Compensation
Video Output
White Balance
Auto White Balance Range
Power Range
Power Consumption
Operating Temperature
Storage Temperature

Camera Adjustments

28395AC
Function Control Dip Switches
Template
Surface Mount (Wall or Ceiling)
Using the Quick Install Adaptor:
Create a 1.5" (38mm) hole in the mounting surface as
indicated by T2. The hole can also be used for cable access.
RoHS
Cable access:
To thread the cables through the mounting surface, cut a 3/4"
(19mm) hole as indicated by the Cable Access markings
inside T2.
CM-150
4mm~9mm 9mm~22mm
NTSC
2:1 Interlace
H15.734KHz / V :59.9Hz
768(H) x 494(V)
1/3" Sony SuperHAD CCD (Interline)
Sony SS-11X
500
1.2 Lux @ F1.6 (50 IRE)
48dB
Central Area for DC IRIS Lens
DC Type Auto IRIS Control
INT
0.45
1.0Vpp, 75Ω Unbalanced
Automatic White Balance
2500K – 9700K
DC 12V ±10%
1.8W (Max)
-10°C ~ +50°C
-20°C ~ +60°C
Back Light Compensation
Switch 1
OFF ON
Auto Gain Control
Switch 2
OFF ON
(Normal Mode) (Turbo Mode)
A1
A2
Side Knock-out
T1
Side Knock-out

Lens Specifications

Focal Length
CM-159
F-No.
Iris Range
Minimum Object Distance
Diagonal
Field Of View Horizontal
Vertical
BLC
AGC-UP
Low Light Chroma
Suppression
A1 : Focus Adjuster
A3
A2 : Field of View
Adjustment
A3 : Function Control
Dip Switches
A4 : AI Level
Adjustment*
* AI Level Adjustment is factory set;
it should not require adjustment.
Using screws:
Drill four holes at template positions T1 and use the screws
and anchors provided with the camera if they are appropriate
for the mounting surface.
When mounting the camera on a surface with the provided
screws, use one of the side knock-outs, as indicated on the
template, for cable entry.
T1
T2
Cable Access
T1
T1
4mm~9mm 9mm~22mm
F1.6 F1.8
F1.6~F2.4 F1.8~F360
50cm 15cm(6")
92.8º~39.4º 39.0º~17.6º
71.0º~31.6º 30.7º~14.1º
51.6º~23.6º 22.7º~10.6º
ON/OFF
ON/OFF
AUTO
A4
Side Knock-out
Side Knock-out
