- Page 1 AtlonA HD/SD-SDI TO HDMI/DVI/YPbPr/RBGHV CONVERTER AT-HDSDI-A User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ………………………………………… 1 2. Features ………………………………………… 1 3. Package Contents ………………………………………… 2 4. Technical Specifications ……………………………… 2 5. Format Specifications ……………………………… 3 6. Panel Descriptions ………………………………………… 5 ... -
Page 3: Introduction
INTRODUCTION The AT-HDSDI-AV provides high quality 12 bit conversion between SDI digital video input and HDMI / DVI digital video output or YPbPr / Composite (CVBS) / RGBHV analog video output. Plus, with an extra DVI output through HDMI type A connector, users can have a pure digital video transmission path without analog conversion distortion. -
Page 4: Package Contents
PACKAGE CONTENTS ∙ 1x AT-HDSDI-AV ∙ 1x 5V 4A power adapter ∙ 1x User Manual ∙ 1x VGA to YPbPr adapter ∙ 1XHDMI to DVI adapter TECHNICAL SPECIFICATIONS ∙ Video Bandwidth：270Mbps 1.485/1.001Gbps ∙ Input signal：HD/SD-SDI (SMPTE 259M / SMPTE 292M / SMPTE 296M) ∙... -
Page 5: Format Specifications
FORMAT SPECIFICATIONS HD INPUT YPbPr OUT 525p @ 59.94Hz SMPTE 293M, ITU-BT.1358 625p @ 50Hz ITU-BT.1358 720p @ 50Hz SMPTE 296M -3 720p @ 60 / 59.94Hz SMPTE 296M -1, -2 1080i @ 25Hz SMPTE 274M -6 1080i @ 30 / 29.97Hz SMPTE 274M -4, -5 1080p @ 24 / 23.98Hz SMPTE 274M -10, -11... - Page 6 HD INPUT VGA OUT 525p @ 59.94Hz SMPTE 293M, ITU-BT.1358 625p @ 50Hz ITU-BT.1358 720p @ 50Hz SMPTE 296M -3 720p @ 60 / 59.94Hz SMPTE 296M -1, -2 1080i @ 25Hz SMPTE 274M -6 1080i @ 30 / 29.97Hz SMPTE 274M -4, -5 1080p @ 24 / 23.98Hz SMPTE 274M -10, -11...
-
Page 7: Panel Descriptions
PANEL DESCRIPTIONS FRONT PANEL 1. HD/SD-SDI Input 4. Power Indicator 2. HD/SD Bi-Color LED 5. HD/SD-SDI Output 2 Green：HD 6. IR Receiver (reserved) Orange：SD 7. 5V Power 3. HD/SD-SDI Output 1 REAR PANEL 1. HDMI Output 2. YPbPr / RGB Output... -
Page 8: Bottom
BOTTOM An 8-pin DIP switch is used for user interface, and users can access this switch from the bottom of the unit. Output formats, video patterns, SD Pedestal, SD Wide, PAL mode, YPbPr / RGB, SD component or SD composite, YC on/off etc. ... -
Page 9: Pin Definition
PIN DEFINITION Pin 1 Pr / Red Pin 9 +5 V Y / Green / 5 4 3 2 1 Pin 2 Pin 10 Ground Composite Pin 3 Pb / Blue Pin 11 Ground 10 6 Pin 4 Ground Pin 12 Reserved 7 ... -
Page 10: Notice
NOTICE The AT-HDSDI-AV HD/SD-SDI to HDMI / DVI / YPbPr / Composite / RGBHV Converter has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, AT-HDSDI-AV should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. ... -
Page 11: Safety Information
Use only accessories recommended by ATLONA to avoid fire, shock or other Do not modify the wall plug. hazards. Doing so will void the warranty and safety features. -
Page 12: Warranty
LIMITED ONE-YEAR WARRANTY ATLONA by Lenexpo Electronics warrants only to the initial purchaser of this product for a period of one year from the date of purchase from an Authorized ATLONA Reseller, the product will be free of electrical and mechanical defects that materially affect the products operation as described in this users manual.
