Installing a New Blade
Unscrew the
Set Brass Ring
cap from the
on Blade
Blade
Carriage to the
carriage.
fully down
position
*This distance will vary depending on what material you are cutting. Your blade depth should be adjusted
to approximately;
The height of your cuttable material + ½ of the height of the backing material.
This will allow the blade to fully cut the material without fully penetrating the backing. 1/64
a general guide that will work well with many common vinyl products and is a good starting point for determining the
blade depth for your material, but some adjustments/fine tuning to blade depth will be necessary in most cases.
Remove the
Insert the
protective
blade into
cover from
the top of
a new
the Blade
blade.
carriage.
Screw the
Adjust the
cap back
carriage cap
onto the
until the blade
blade
is protruding
carriage.
approximately
th
1/64
of an
inch.*
Adjust the
Brass Ring
until it fits
snug against
the Cap. This
will help keep
the cap in
place during
operation.
th
of an inch is
