INSTALLATION Space requirements Flue connection and combustion air opening Flue gas extractor Pic 2 Pic 1...
Page 5
INSTALLATION Plumbing connections Relief valve installation Filling the system Instructions for filling...
Page 6
CONNECTION DIAGRAM Room temperature sensor Exp. Radiator temperature sensor Hot water A T-pipe with a min. vessel diameter of 1 ¼” Cold water Radiator improves ventilation Automatic shunt Mixer valve Radiator pump Flue thermostat Relief valve Shunt valve Electric resistor Warm water accumulator Tank...
Page 7
TEMPERATURE CONTROL VALVE Installing a temperature control valve to wood-fired boiler with a cooling spi- Installation TECHNICAL DATA Max pressure of incoming water 10 bar Opening temperature Temperature control valves are available from Ariterm Product Number 5012921...
OPERATION Starting the fire: Adjust primary air vent to 4. Adjust sekundary air vent to 5.
Page 11
OPERATION Adding firewood Pellet use Oil use Electric use...
Page 12
SERVICE AND MAINTENANCE Before each heating season Once a week and as required in the heating season Check that the holes of the grate are unblocked and that there is no combustion residue left Always clean the convector after the flue gas from previous use.
Page 13
SERVICE AND MAINTENANCE Remove all turbulators. Clean the boiler convector by brushing the convector pipes clean. Make sure that the fire door damper Make sure that the fire door damper closes when you close the feeding opens and closes as you use the hatch.
Page 14
SERVICE AND MAINTENANCE Other maintenance procedures Adjustment of the hatches Check that the hatch sits tightly. A leaky fee- ding hatch will cause wood to combust in the wrong place. Tighten the hatches by adjusting the lock handle and hinge pieces. From time to time, you should check that the gap between the deflectors and the storage chamber is unblocked.
SERVICE AND MAINTENANCE Adjusting the hinge: • Unscrew both mounting screws of the hinge piece enough to move the hinge. • Move the hinge piece slightly in the direc- tion of the boiler. • Tighten the mounting screws slightly and test whether the hatch now sits more tightly on the hinge side.
Page 16
MEASUREMENTS AND CONNECTIONS Part Name Unit Feeding hatch Stoking hatch Primary air vent Secondary air vent Convector door Top door Bottom door Outlet to accumulator DN 32 Expansion vessel outlet DN 25 Cooling spiral Cu 15 Return from accumulator DN 32 Draining outlet DN 15 Water thermometer / pressure gauge...
TECHNICAL DATA TECHNICAL DATA With wood 30 kW Capacity With pellets 30 kW With oil 30 kW Width 570 mm Depth 1016 mm Height 1345 mm Dimensions Weight (empty) 415 kg Water capacity 125 L Flue connection diameter 140 mm (external) Boiler pressure 0,5-1,5 bar Permitted boiler temperature...
Page 18
FLUE GAS FAN CONTROL UNIT General Electric installation...
