  • Page 1 0158434en 1107 Rammer BS 60-2 BS 70-2 OPERATOR’S MANUAL...

  • Page 3: Table Of Contents

    BS 60/BS 70-2 Table of Contents Foreword Emission Control System Information Safety Information Operating Safety ................14 Operator Safety while using Internal Combustion Engines ....15 Service Safety ..................16 Label Locations .................. 17 Safety and Operating Labels .............. 18 Operation Application ..................
  • Page 4 Table of Contents BS 60/BS 70-2 Technical Data Rammer ....................35 Sound Measurements .................36 Vibration Measurements ..............36 Dimensions ..................36 wc_bo0158434en_006TOC.fm...

  • Page 5: Foreword

    Foreword CALIFORNIA Proposition 65 Warning: Engine exhaust, some of its constituents, and certain vehicle components, contain or emit chemicals known to the State of WARNING California to cause cancer and birth defects or other reproductive harm. Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.

  • Page 6: Emission Control System Information

    Emission Control System Information Emission Control System Information Source of Emissions The combustion process produces carbon monoxide, oxides of nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of nitrogen is very important because, under certain conditions, they react to form photochemical smog when subjected to sunlight. Carbon monoxide does not react in the same way, but it is toxic.
  • Page 7 Emission Control System Information Replacement Parts The emission control systems on your Wacker engine were designed, built, and certified to conform with EPA and California emissions regulations. We recommend the use of genuine Wacker parts whenever you have maintenance done. These original-design replacement parts are manufactured to the same standards as the original parts, so you can be confident of their performance.
  • Page 8 Emission Control System Information METHANOL - (methyl or wood alcohol) 5% by volume. You may use gasoline containing up to 5% methanol by volume, as long as it contains cosolvents and corrosion inhibitors to protect the fuel system. Gasoline containing more than 5% methanol by volume may cause starting and/or performance problems.
  • Page 9 Emission Control System Information OWNER’S WARRANTY RESPONSIBILITY: As the engine owner, you are responsible for the performance of the required maintenance listed in your owner’s manual. Wacker recommends that you retain all receipts covering maintenance on your engine, but Wacker cannot deny warranty coverage solely for the lack of receipts or for your failure to ensure the performance of all scheduled maintenance.
  • Page 10 Emission Control System Information TO OBTAIN WARRANTY SERVICE: You must take your Wacker product along with proof of original purchase date, at your expense, to any Wacker authorized dealer during their normal business hours. Claims for repair or adjustment found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used.
  • Page 11 Emission Control System Information SYSTEMS COVERED PARTS BY THIS WARRANTY DESCRIPTIONS FUEL METERING CARBURETOR ASSEMBLY EXHAUST SYSTEM MUFFLER AIR INDUCTION AIR FILTER HOUSING AIR FILTER ELEMENT* IGNITION FLYWHEEL MAGNETO IGNITION MODULE SPARK PLUG CAP SPARK PLUG* MISCELLANEOUS TUBING, FITTINGS, SEALS, GASKETS PARTS AND CLAMPS ASSOCIATED WITH THESE LISTED ITEMS...
  • Page 12 Emission Control System Information wc_tx000030gb.fm...

  • Page 13: Safety Information

    Safety Information BS 60/BS 70-2 Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 14: Operating Safety

    BS 60/BS 70-2 Safety Information Operating Safety Familiarity and proper training are required for the safe operation of the machine. Machines operated improperly or by untrained personnel can be dangerous. Read the operating instructions contained in both WARNING this manual and the Engine Manual and familiarize yourself with the location and proper use of all controls.

  • Page 15: Operator Safety While Using Internal Combustion Engines

    Safety Information BS 60/BS 70-2 3.1.18 ALWAYS guide the rammer in such a way that the operator is not squeezed between the rammer and solid objects. Special care is required when working on uneven ground or when compacting coarse material. Make sure to stand firmly when operating the machine under such conditions.

  • Page 16: Service Safety

    BS 60/BS 70-2 Safety Information Service Safety A poorly maintained machine can become a safety hazard! In order for the machine to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. WARNING 3.3.1 DO NOT attempt to clean or service the machine while it is running.

  • Page 17: Label Locations

    Safety Information BS 60/BS 70-2 Label Locations wc_si000120gb.fm...

  • Page 18: Safety And Operating Labels

    BS 60/BS 70-2 Safety Information Safety and Operating Labels Wacker machines use international pictorial labels where needed. These labels are described below: Ref. Label Meaning This molded-in label contains important safety and operating information. If it becomes illegible, the cover must be replaced. Refer to the Parts Book for ordering information.
  • Page 19 Safety Information BS 60/BS 70-2 Ref. Label Meaning Pull the rewind starter. Open the choke. Place the throttle control lever in the “stop” position. Throttle control lever: 0 = Stop Turtle = Start or Idle Rabbit = Full or Fast DANGER! Engines emit carbon monoxide;...
  • Page 20 BS 60/BS 70-2 Safety Information Ref. Label Meaning DANGER! No sparks, flames or burning objects near machine. Shut off the engine before refueling. CAUTION! Use only clean, filtered gasoline fuel. WARNING! To prevent hearing loss, wear hearing protection when operating the machine. WARNING! Hot surface! Replace guard! WARNING!
  • Page 21 Safety Information BS 60/BS 70-2 Ref. Label Meaning CAUTION! ALWAYS follow instructions when disconnecting fuel lines. Failure to do so may result in fuel squirting from fuel system. Read and understand the supplied operator's manuals before operating this machine. For optimal control, performance, and minimal hand/arm vibration, grasp handle as shown.
  • Page 22 BS 60/BS 70-2 Safety Information Ref. Label Meaning Choke: 0 = Open l = Closed This engine is certified to operate on regular unleaded gasoline mixed with two cycle oil at 50:1-100:1 ratio. This rammer engine requires a two-cycle gasoline/oil mixture (50:1) This machine may be covered by one or more patents.

  • Page 23: Operation

    Operation BS 60/BS 70-2 Operation Application Rammers are designed to compact loose soils and gravel to prevent settling and to provide a firm, solid base for the placement of footings, concrete slabs, foundations, and other structures. Recommended Fuel This rammer engine requires a two-cycle gasoline/oil mixture. Mix regular unleaded gasoline and two-cycle/outboard motor oil in separate container before filling tank.

  • Page 24: To Start

    BS 60/BS 70-2 Operation To Start See Graphic: wc_gr001461 4.4.1 Open throttle to full position (c4). This will automatically turn on the flow of fuel. 4.4.2 If machine is equipped, pump the purge bulb (e) 6 to 10 times or until you see fuel in bulb.

  • Page 25: To Stop

    Operation BS 60/BS 70-2 To Stop See Graphic: wc_gr001461 4.5.1 Place throttle in the idle position (c2). 4.5.2 Shut off the engine by moving the throttle through the detent to the off position (c1). The engine will stop and the fuel valve will close. Note: If the throttle control wire should break, shut off the rammer manually by using the engine STOP button (d).

  • Page 26: Proper Compaction

    BS 60/BS 70-2 Operation Proper Compaction See Graphic: wc_gr000045 4.7.1 Run rammer at the full throttle position (a4) for maximum performance. 4.7.2 Guide rammer with its handle. Allow machine to pull itself forward. DO NOT try to over-power the machine. 4.7.3 For best compaction, the shoe must hit the ground flat (b), not on its toe or heel.

  • Page 27: Maintenance

    Maintenance BS 60/BS 70-2 Maintenance Periodic Maintenance Schedule After Every Every Every Daily first week month 3 months Every before or 25 or 100 or 300 Year starting hours hours hours hours Check fuel level. Check air filter indicator. Replace as needed.

  • Page 28: Air Cleaner

    BS 60/BS 70-2 Maintenance Air Cleaner See Graphic: wc_gr001168 NEVER use gasoline or other types of low flash point solvents for cleaning the air filter. A fire or explosion could result. WARNING NOTICE: NEVER run engine without main paper filter element (b). Severe engine damage will occur.

  • Page 29: Lubrication

    Maintenance BS 60/BS 70-2 Lubrication See Graphic: wc_gr001464 Ramming system Check oil level: 5.3.1 Tilt the machine backwards approximately 15° until the engine is level by placing a wedge under the shoe. 5.3.2 Check the oil level through oil sightglass (d). Proper ramming system lubrication is indicated when approximately 1/2–3/4 of the sightglass is full.
  • Page 30 BS 60/BS 70-2 Maintenance...

  • Page 31: Fuel Lines

    Maintenance BS 60/BS 70-2 Fuel Lines See Graphic: wc_gr0001493 ALWAYS follow the instructions when disconnecting the fuel lines. Failure to do so may result in fuel leaking from the fuel system. CAUTION To disconnect the fuel lines: 5.4.1 Shut off the engine by moving the throttle through the detent to the off position (a).

  • Page 32: Shoe Hardware

    BS 60/BS 70-2 Maintenance Shoe Hardware See Graphic: wc_gr000055 On new machines, or after replacing shoe, check and tighten shoe hardware (a) after the first 5 hours of operation. Inspect hardware every week thereafter. Torque hardware as specified. Carburetor Adjustments See Graphic: wc_gr004670 Refer to Technical Data for correct idle and operating rpm.

  • Page 33: Storage

    Maintenance BS 60/BS 70-2 Storage 5.7.1 Drain the fuel from the tank. 5.7.2 Start the engine and run it until remaining fuel is used. 5.7.3 Remove the spark plug. Pour approximately 30 ml (1 oz.) of clean SAE 10W30 engine oil into the cylinder through the spark plug opening. 5.7.4 Pull the starter rope slowly to distribute oil in the engine.

  • Page 34: Troubleshooting

    BS 60/BS 70-2 Maintenance Troubleshooting Problem / Symptom Reason / Remedy Engine does not start, or • No fuel in tank. stalls. • Spark plug fouled. • Fuel valve closed. Engine does not accelerate, is • Improper fuel mix. Too much oil. hard to start, or runs •...

  • Page 35: Technical Data

    Technical Data BS 60/BS 70-2 Technical Data Rammer Item Number: BS 60-2 BS 60-2 BS 70-2 0009388 0009391 0009397 0009417 0009418 0009399 0009421 0009424 0009425 0009427 Rammer Engine Model WM80 type Engine Speed - full 4400 ± 100 4600 ± 100 Engine Speed - idle 1800 ±...

  • Page 36: Sound Measurements

    Products are tested for hand/arm vibration (HAV) level in accordance with ISO 5349, EN1033, and EN500-4 where applicable. • HAV BS 60-2 = 7.6 m/s • HAV BS 70-2 = 6.8 m/s Refer to Section Proper Operation for further details.
  • Page 37 Vibrationsstampfer Apisonadoras Vibratorias Pilonneuses Vibrantes BS 60-2, BS 60-2i, BS 70-2, BS 70-2i Type - Typ - Tipo - Type Item number of equipment / Artikelnummer / Número de referencia de la máquina / Numéro de référence du matériel :...
  • Page 38 Wacker Construction Equipment AG · Preußenstraße 41 · D-80809 München · Tel.: +49-(0)89-3 54 02 - 0 · Fax: +49 - (0)89-3 54 02-3 90 Wacker Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : (262) 255-0500 · Fax: (262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations ·...
