Item Number / Artikel-Nummer / Número de referencia / Numéro de référence :
This manual is divided into the sections listed below:
Diese Betriebsanleitung ist in folgende Kapitel eingeteilt:
Este manual está compuesto por las siguientes secciones:
Ce manuel contient les sections suivantes:
Operation (English)
1A
Betrieb (Deutsch)
1B
Operación (Español)
1C
Opération (Français)
1D
2
Machine Parts / Maschinenteile / Repuestos de la máquina / Pièces de la machine
This manual provides information and procedures to safely operate and maintain this WACKER model. For your
own safety and protection from injury, carefully read, understand and observe the safety instructions described
in this manual. THE INFORMATION CONTAINED IN THIS MANUAL WAS BASED ON MACHINES IN PRODUCTION
AT THE TIME OF PUBLICATION. WACKER CORPORATION RESERVES THE RIGHT TO CHANGE ANY PORTION
OF THIS INFORMATION WITHOUT NOTICE.
Diese Betriebsanleitung enthält Informationen und Verfahren, um dieses WACKER Gerät sicher zu bedienen und zu
warten. Für Ihre Sicherheit und zur Verhinderung von Verletzungen, diese Betriebsanleitung bitte genau durchlesen
und die Angaben befolgen. DIE HIERIN ENTHALTENEN INFORMATIONEN SIND AKTUELL ZUM ZEITPUNKT DER
VERÖFFENTLICHUNG. ÄNDERUNGSRECHT VORBEHALTEN.
Este manual contiene información y procedimientos que son necesarios para operar y mantener esta máquina
WACKER. Para su propia seguridad y protección, lea por favor este manual cuidadosamente y observe todas las
instrucciones de seguridad descritas en este manual. TODA LA INFORMACION EN ESTE MANUAL SE BASA EN
MAQUINAS EN PRODUCCION VEGENTE A PARTIR DE LA FECHA DE PUBLICACION. TODOS DERECHOS
RESERVADOS POR WACKER CORPORACION.
Ce manuel fournit des informations et des procédures destinées à utiliser et à entretenir en toute sécurité cette machine
WACKER. Pour votre propre sécurité et afin d'éviter tout accident, lisez, comprenez et respectez soigneusement les
consignes de sécurité décrites dans ce manuel. LES INFORMATIONS CONTENUES DANS CE MANUEL SONT
BASEES SUR LES MACHINES EN COURS DE PRODUCTION AU MOMENT DE LA PUBLICATION. WACKER
CORPORATION SE RESERVE LE DROIT DE MODIFIER TOUTE PARTIE DE CES INFORMATIONS SANS
PREAVIS.
0007567, 0007566
! WARNING
Engine exhaust, some of its constituents, and certain vehicle
components contain or emit chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm.
1040SD71
i
BS65Y
Advertisement
Table of Contents
Related Manuals for Wacker Neuson bs65y
Summary of Contents for Wacker Neuson bs65y
- Page 1 BS65Y Item Number / Artikel-Nummer / Número de referencia / Numéro de référence : 0007567, 0007566 This manual is divided into the sections listed below: Diese Betriebsanleitung ist in folgende Kapitel eingeteilt: Este manual está compuesto por las siguientes secciones:...
- Page 2 BS65Y Nameplate / Typenschild / Placa de Identificación / Plaque signalétique A nameplate listing the Model Number, Item Number, Revision, and Serial Number is attached to each unit. Please record the information found on this plate so it will be available should the nameplate become lost or damaged. When ordering parts or requesting service information, you will always be asked to specify the model, item number, revision number, and serial number of the unit.
-
Page 3: Patent Pending
BS65Y This machine may be covered by one or more of the following patents: Dieses Gerät ist unter einem oder mehreren der folgenden Patente geschützt: Puede ser que las patentes a continuación sean válidas para esta máquina: Cette machine peut être protégée sous les brevets d’invention ci-dessous : WACKER MACHINES PROTECTED BY ONE OR MORE OF THESE U.S. -
Page 4: Emission Control System Information
BS65Y A manufacturer of an aftermarket part assumes the EMISSION CONTROL SYSTEM responsibility that the part will not adversely affect emis- INFORMATION sion performance. The manufacturer or rebuilder of the part must certify that use of the part will not result in a Source of Emissions failure of the engine to comply with emission regulations. -
Page 5: Emission Control System Warranty
BS65Y Emission Control System Warranty Your new WACKER engine complies with the U.S. EPA emissions regulations. WACKER provides the same emission warranty coverage for engines sold in all 50 states. YOUR WARRANTY RIGHTS AND OBLIGATIONS All States WACKER must warrant the emission control system on your engine for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your engine. -
Page 6: To Obtain Warranty Service
BS65Y TO OBTAIN WARRANTY SERVICE: You must take your WACKER product along with proof of original purchase date, at your expense, to any WACKER authorized dealer during their normal business hours. Claims for repair or adjustment found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used. -
Page 7: Safety Information
OPERATION BS65Y Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. -
Page 8: Operating Safety
BS65Y OPERATION Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions and familiarize yourself with the location and proper use of all instruments and controls. Inexperienced operators should receive instruction from someone familiar with the equipment before being allowed to operate the rammer. -
Page 9: Operator Safety While Using Internal Combustion Engines
OPERATION BS65Y Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling! Failure to follow the safety guidelines described below could result in severe injury or death. ! DANGER NEVER smoke while operating rammer. -
Page 10: Technical Data
BS65Y OPERATION Technical Data Engine speed - full 4500 ± 200 Engine speed - idle 1500 ± 100 Clutch engagement 2800 ± 100 Cylinder head compression-cold 120–140 (8.0–9.7) psi (kg/cm Spark plug - Gap Champion RL86C: 0.035 (0.8–0.9) in. (mm) Bosch WR 8 AC: 0.02 (0.5) -
Page 11: Recommended Fuel
OPERATION BS65Y 1002SD27 1002SD08 1014SD91 1005SD68 Before Starting Recommended Fuel 1. Read safety instructions at the beginning of this This rammer engine requires a two-cycle gasoline/oil manual. mixture. 2. Fill tank with proper fuel mixture. Note: Use 25:1 mixture for first tank of fuel only. Use 3. -
Page 12: Proper Operation
BS65Y OPERATION 1.11 To Stop 1. Place throttle in “IDLE” 2. Shut off engine by closing fuel valve on tank. 1.12 Proper Operation 1. Open throttle completely , then adjust for the smoothest operation. Do not overthrottle. Best com- paction is achieved when rammer is running smoothly. - Page 13 OPERATION BS65Y 1.14 Adjusting Ramming Stroke When adjusting the ramming stroke, observe the following precautions to avoid injury to yourself and others. WARNING - Adjust stroke with machine standing upright and resting on a firm, level surface. Do not adjust stroke if the machine is in an unstable position where it can easily tip or slide.
-
Page 14: Periodic Maintenance Schedule
BS65Y OPERATION 1.15 Periodic Maintenance Schedule Daily After Every Every Every before first week month 3 months starting hours 25 hrs. 100 hrs. 300 hrs. Check fuel level. Check oil level in sightglass. Check cannister type air filter. Replace filter element as required. - Page 15 OPERATION BS65Y 1.17 Low Maintenance Air Cleaner This air cleaner is self-cleaning and uses the movement of the machine to shake dust and dirt loose from the air cleaner element while the rammer is operating. Under normal operating conditions this element will not require cleaning and should not be removed from the machine.
-
Page 16: Shoe Hardware
BS65Y OPERATION 1.18 Lubrication 1. Change ramming system oil after first 50 hours of operation and every 300 hours thereafter. To drain oil, remove plug and tilt machine back until it is resting on handle. 2. With rammer on level surface, add oil through plug Proper ramming system lubrication is indicated when approximately 1/2–3/4 of the sightglass... -
Page 17: Long Term Storage
OPERATION BS65Y 1.21 Long-term Storage 1. Drain fuel from tank. 2. Start engine and run until remaining fuel is used. 3. Remove spark plug. Pour approximately 1 oz. (30 ml) of clean SAE 30W engine oil into cylinder through spark plug opening.
