Page 1: Quick Installation Guide
ACP-PNVDV-A1-DCR Intel ATOM Mini ITX Motherboard Quick Installation Guide Ed – 29 October 2012 Part No. E2017PNVD00R... - Page 2 Room 805, Building 9,No.99 Tianzhou Rd., 3F Ishiyama-Bldg, 1-6-1 Taito, Caohejing Development Area, Taito-ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax: +81-3-5807-2322 Fax:+86-21-5445-3266 Information: sales.japan@avalue.com.tw Information: sales.china@avalue.com.cn Service: service@avalue.com.tw Service: service@avalue.com.tw 2 ACP-PNVDV-A1-DCR Quick Installation Guide...
-
Page 3: Table Of Contents
Serial ATA power connector 1~2 (SATAP1/2)........18 2.3.20 CPU fan connector 1 (CPU_FAN1) ............18 2.3.21 Audio connector (JAUD1) ..............19 Signal Description – Audio connector (JAUD1)..........19 2.3.21.1 2.3.22 Primary IDE connector (IDE1) .............. 20 ACP-PNVDV-A1-DCR Quick Installation Guide 3... -
Page 4: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ACP-PNVDV-A1-DCR Intel ATOM Mini ITX Motherboard 1 x Quick Installation Guide for ACP-PNVDV-A1-DCR ... -
Page 5: Hardware Configuration
ACP-PNVDV-A1-DCR Quick Installation Guide 2. Hardware Configuration ACP-PNVDV-A1-DCR Quick Installation Guide 5... -
Page 6: Product Overview
ACP-PNVDV-A1-DCR Quick Installation Guide 2.1 Product Overview 6 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 7: Jumper And Connector List
3 x 1 header, pitch 2.00 mm JSTDP1~2 SATA Dom power jumper 1~2 3 x 1 header, pitch 2.00 mm JRTC1 Clear CMOS 3 x 1 header, pitch 2.00 mm Connectors Label Function Note Battery holder BAT1 ACP-PNVDV-A1-DCR Quick Installation Guide 7... - Page 8 LAN_USB connectors 1~2 LAN_USB1~2 VGA_COM1 VGA_COM connector 1 SATAP1~2 Serial ATA power connector 1~2 4 x 1 wafer, pitch 2.54mm CPU_FAN1 CPU fan connector 1 3 x 1 wafer, pitch 2.54mm MPCIE1 Mini-PCI connector 1 8 ACP-PNVDV-A1-DCR Quick Installation Guide...
-
Page 9: Setting Jumpers & Connectors
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3 Setting Jumpers & Connectors 2.3.1 AT/ATX power mode select (JAT/ATX1) ATX* * Default 2.3.2 Serial port 1 pin9 signal selector (JRI1) Ring* +12V Signal PIN PIN Signal PNRI#_A +12V Default PNRI#_A PNRI#_A NRI#_A ACP-PNVDV-A1-DCR Quick Installation Guide 9... -
Page 10: Serial Port 2 Pin9 Signal Selector (Jri2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.3 Serial port 2 pin9 signal selector (JRI2) Ring* +12V Signal PIN PIN Signal NRI#_B PNRI#_B * Default PNRI#_B +12V PNRI#_B 2.3.4 CF/IDE Master/SLAVE Selector (JCFMS1) CF-MASTER, IDE-SLAVE* CF-SLAVE, IDE-MASTER Signal IDE_SEL# Default CF_SEL# 10 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 11: Sata Dom Power Jumper 1 (Jstdp1)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.5 SATA Dom power jumper 1 (JSTDP1) SATA CABLE* SATA DOM Signal Default SATADIMP1 +V5_SATA1 2.3.6 SATA Dom power jumper 2 (JSTDP2) SATA CABLE* SATA DOM Signal * Default SATADIMP2 +V5_SATA2 ACP-PNVDV-A1-DCR Quick Installation Guide 11... -
Page 12: Clear Cmos (Jrtc1)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.7 Clear CMOS (JRTC1) Normal Operation * Clear CMOS Signal RTC_RST# * Default 2.3.8 Serial port 2 in RS-422/485 mode (J422_485) Signal PIN PIN Signal 485TXB- 485RXB- 485TXB+ 485RXB+ +V5_COM2 12 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 13: Serial Port Connector 2 (Jcom2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.9 Serial port connector 2 (JCOM2) Signal PIN PIN Signal NDCD#_B NRXD_B NTXD_B NDTR#_B NDSR#_B NRTS#_B NCTS#_B PNRI#_B 2.3.10 General purpose I/O connector (DIO1) Signal PIN PIN Signal SMB_CLK_V5 17 18 SMB_DAT_V5 ACP-PNVDV-A1-DCR Quick Installation Guide 13... -
Page 14: Keyboard/Mouse Connector (Kbms2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.11 Keyboard/Mouse connector (KBMS2) Signal PIN PIN Signal KB_DT KB_CK +V5_KBMS MS_DT MS_CK 2.3.12 Miscellaneous settings connector (JFTP1) Signal PIN PIN Signal +3.3V PWR_LED+ HDD_LED POWER Button SYS_RESET# 14 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 15: Low Pin Count Connector (Jlpc1)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.13 Low Pin Count connector (JLPC1) Signal PIN PIN Signal PCI_SERIRQ CLK_LPC LPC_AD3 LPC_FRAME# LPC_AD2 PLT_RST# LPC_AD1 +3.3V LPC_AD0 2.3.14 USB connector 1 (JUSB1) Signal PIN PIN Signal USB_D+ USB_D+ USB_D- USB_D- ACP-PNVDV-A1-DCR Quick Installation Guide 15... -
Page 16: Usb Connector 2 (Jusb2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.15 USB connector 2 (JUSB2) Signal PIN PIN Signal USB_D+ USB_D+ USB_D- USB_D- 2.3.16 SPI connector (SPI1) Signal PIN PIN Signal +3.3V SPI_CS0# SPI_CLK SPI_SO SPI_SI SPI_HOLD# 16 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 17: Dc-In Power Connector (Pwr2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.17 DC-IN power connector (PWR2) Signal Signal +VDC_INP +VDC_INP 2.3.18 System Fan connector (SYS_FAN1) Signal SYSFAN_PWR SYSFANIN ACP-PNVDV-A1-DCR Quick Installation Guide 17... -
Page 18: Serial Ata Power Connector 1~2 (Satap1/2)
ACP-PNVDV-A1-DCR Quick Installation Guide 2.3.19 Serial ATA power connector 1~2 (SATAP1/2) Signal SATAP1 +12V SATAP2 2.3.20 CPU fan connector 1 (CPU_FAN1) Signal CPUFAN_PWR CPUFANIN 18 ACP-PNVDV-A1-DCR Quick Installation Guide... -
Page 19: Audio Connector (Jaud1)
2.3.21.1 Signal Description – Audio connector (JAUD1) Signal Signal Description LINE2_SJD AUDIO Out (ROUT/LOUT) sense pin MIC2_JD MIC IN (MIC_RIN/LIN) sense pin ACZ_DET# Detect if there is Front Audio board contected FRONT-IO-SENSE Detect whether MIC2 or LINE2 is contected or not ACP-PNVDV-A1-DCR Quick Installation Guide 19... -
Page 20: Primary Ide Connector (Ide1)
IDE_ PDD10 IDE_ PDD4 IDE_ PDD11 IDE_ PDD3 IDE_ PDD12 IDE_ PDD2 IDE_ PDD13 IDE_ PDD1 IDE_ PDD14 IDE_ PDD0 IDE_PDD15 IDE_PDDREQ IDE_PDIOW# IDE_PDIOR# IDE_PIORDY IDE_SEL# IDE_PDDACK# IDE_PINTRQ IDE_PDA1 IDE_PDIAG IDE_PDA0 IDE_PDA2 IDE_PDCS1# IDE_PDCS3# IDE_ACT# 20 ACP-PNVDV-A1-DCR Quick Installation Guide...
