Avalue Technology RX610H User Manual

12th/13th gen intel core processors micro atx motherboard with intel h610e chipset
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RX610H
12th/13th Gen Intel® Core™ Processors Micro ATX
Motherboard with Intel® H610E Chipset
User's Manual
st
1
Ed –29 January 2024
Part No. E2047RX6H00R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX610H and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology RX610H

Summary of Contents for Avalue Technology RX610H

  • Page 1 RX610H 12th/13th Gen Intel® Core™ Processors Micro ATX Motherboard with Intel® H610E Chipset User’s Manual Ed –29 January 2024 Part No. E2047RX6H00R...

  • Page 2: Fcc Statement

    Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...

  • Page 3: Life Support Policy

    Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 RX610H User’s Manual...

  • Page 5: Table Of Contents

    2.3.18 LAN LED status connector (LANLED1) ..................28 3.BIOS Setup ........................29 Introduction ......................30 Starting Setup ......................30 Using Setup ......................31 Getting Help ......................32 In Case of Problems ....................32 BIOS setup ......................33 RX610H User’s Manual...
  • Page 6 3.6.4.2.1.2 PCI Express Root Port 2(x16 Slot 3) ..................66 3.6.4.2.1.3 PCI Express Root Port 4(X16 Slot 4 & M.2 E key) ..............67 3.6.4.2.1.4 PCI Express Root Port 5(x4 Key M) ..................68 3.6.4.2.2 SATA Configuration ....................... 69 3.6.4.2.3 USB Configuration ......................... 70 6 RX610H User’s Manual...
  • Page 7 Install ME Driver ...................... 80 Install Audio Driver (For Realtek ALC897 and ALC888S HD Audio) ....... 81 Install LAN Driver ....................82 Install Serial IO Driver ..................... 83 Install Intel_DTT ...................... 84 5. Mechanical Drawing ....................85 RX610H User’s Manual...

  • Page 8: Getting Started

    1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x RX610H Motherboard  1 x I/O Shield  8 RX610H User’s Manual...

  • Page 9: Document Amendment History

    User’s Manual 1.3 Document Amendment History Revision Date Comment January 2024 Avalue Initial Release RX610H User’s Manual...

  • Page 10: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to set up RX610H or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

  • Page 11: System Specifications

    1 x HDMI 2.0b 1 x Mic-In Audio 1 x Line-Out GPIO 1 x 8 bits GPIO Header with Shroud +5V, GND Onboard I/O COM1/2/4/5/6 support RS232 (COM1~2/4~6) 5 x RS-232 Headers with Voltage Selection (2.0mm Pitch) RX610H User’s Manual 11...
  • Page 12 1 x 1 x 4 pin, pitch 2.00mm connector for I2C (I2C) Other 1 x 1 x 2 pin, pitch 2.54mm connector for Chassis Intrusion Switch (JCASE1) 1 x 1 x 6 pin, pitch 2.54mm connector for PS/2 KB&MS (KBMS1) 12 RX610H User’s Manual...
  • Page 13 1 x Intel® I219-V Gigabit Ethernet Controller LAN Chipset 1 x Intel® I225-LM 2.5 Gigabit Ethernet Controller Intel® i219V 10/100/1000 Base-Tx GbE compatible LAN Spec. Intel® i225-LM: 10/100/1000/2500 Base-Tx GbE compatible Note: Specifications are subject to change without notice. RX610H User’s Manual 13...

  • Page 14: Architecture Overview-Block Diagram

    RX610H User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of RX610H. 14 RX610H User’s Manual...

  • Page 15: Hardware Configuration

    User’s Manual 2. Hardware Configuration RX610H User’s Manual 15...

  • Page 16: Product Overview

    RX610H User’s Manual 2.1 Product Overview 16 RX610H User’s Manual...

  • Page 17: Jumper And Connector List

    4 x 1 wafer, pitch 2.54mm CHA_FAN1 Chassis Fan Connector 4 x 1 wafer, pitch 2.54mm Chassis Fan Connector 4 x 1 wafer, pitch 2.54mm CHA_FAN2 Chassis Intrusion Header JCASE1 2 x 1 wafer, pitch 2.50mm RX610H User’s Manual 17...
  • Page 18 RJ45 Ethernet Connectors x 1 Gigabit Ethernet LAN1+ USB12 USB 3.2 Type A Connectors x 2 RJ45 Ethernet Connectors x 1 LAN2+ USB34 2.5 Gigabit Ethernet USB 3.2 Type A Connectors x 2 AUDIO1 Audio Phone Jack Lin-out, Mic-in 18 RX610H User’s Manual...
  • Page 19 User’s Manual LGA1700 CPU socket RX610H User’s Manual 19...

  • Page 20: Setting Jumpers & Connectors

    RX610H User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (CLCMOS1) Normal* Clear CMOS * Default 2.3.2 AT/ATX Power Mode Select (JPSON1) ATX* * Default 20 RX610H User’s Manual...

  • Page 21: Com Power Setting (Jcompwr1~6)

    Ring* JCOMPWR6 +12V JCOMPWR5 JCOMPWR4 JCOMPWR3 JCOMPWR2 JCOMPWR1 * Default 2.3.4 PCIe Selection (PCISEL1) This jumper allows you to switch PCIe bus between M.2 and PCIe slot. For PCIE slot* For E key M.2 * Default RX610H User’s Manual 21...

  • Page 22: Cpu Fan Connector (Cpufan1)

    RX610H User’s Manual 2.3.5 CPU fan connector (CPUFAN1) Signal +12V FAN_SPEED2 FAN_PWM1 2.3.6 System fan connector (CHA_FAN1) Signal +12V FAN_SPEED2 FAN_PWM2 22 RX610H User’s Manual...

  • Page 23: System Panel (F_Panel1)

    User’s Manual 2.3.7 System Panel (F_PANEL1) Signal PIN PIN Signal HHD LED+ HHD LED# PWR LED# PANSWIN# 2.3.8 ATX Power connector (ATX1) Signal Signal -12V PS_ON PWRER OK +5VSB +12V +12V RX610H User’s Manual 23...

  • Page 24: Atx Power Connector (Atx12V1)

    RX610H User’s Manual 2.3.9 ATX Power connector (ATX12V1) Signal Signal +12V +12V +12V +12V 2.3.10 Serial Port connectors (COM1~6) COM6 COM5 Signal PIN PIN Signal COM4 RI3xPOWERxJMP COM3 CTS# RTS# COM2 DSR# COM1 DTR# DCD# 24 RX610H User’s Manual...

  • Page 25: Serial Port Connectors (Sata1~4)

    Serial Port connectors (SATA1~4) SATA3 SATA4 SATA2 SATA1 ˋ4 Signal 2.3.12 LPT Port Connector (LPT1) Signal PIN PIN Signal LPT_STB# LPT_AFD# LPT_PD0 LPT_ERR# LPT_PD1 LPT_INIT# LPT_PD2 LPT_SLIN# LPT_PD3 LPT_PD4 LPT_PD5 LPT_PD6 LPT_PD7 LPT_ACK# LPT_ACK# LPT_PE LPT_SLCT RX610H User’s Manual 25...

  • Page 26: Usb3.2 Connector (Usb78)

    2.3.13 USB3.2 connector (USB78) Signal PIN PIN Signal USB+ USB- USB+ USB- USB3_TX+ USB3_TX- USB3_TX+ USB3_TX- USB3_RX+ USB3_RX- USB3_RX+ USB3_RX- 2.3.14 USB connectors (USB910/USB1112) USB910 USB1112 Signal PIN PIN Signal USB+5V USB+5V USB- USB- USB+ USB+ 26 RX610H User’s Manual...

  • Page 27: Front Audio Connector (Fp_Audio1)

    User’s Manual 2.3.15 Front Audio connector (FP_AUDIO1) Signal PIN PIN Signal MIC2L MIC2R +3.3V LINE2R MIC2_JD SENSEB LINE2_L LINE2_JD 2.3.16 Amplifier connector (JAMP1) Signal AMP_L- AMP_L+ AMP_R- AMP_R+ RX610H User’s Manual 27...

  • Page 28: Sm Bus Connector (Smb1)

    RX610H User’s Manual 2.3.17 SM bus connector (SMB1) Signal +3.3V SMB_ALT SMB_DATA SMB_CLK 2.3.18 LAN LED status connector (LANLED1) Signal PIN PIN Signal +3V_Daul +3V_Daul +3V_Daul +3V_Daul LEN1_LED +3V_Daul +3V_Daul 28 RX610H User’s Manual...

  • Page 29: Bios Setup

    User’s Manual 3.BIOS Setup RX610H User’s Manual 29...

  • Page 30: Introduction

    If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 30 RX610H User’s Manual...

  • Page 31: Using Setup

    Note: Some of the navigation keys differ from one screen to another.  To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. RX610H User’s Manual 31...

  • Page 32: Getting Help

    BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 32 RX610H User’s Manual...

  • Page 33: Bios Setup

    To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu. RX610H User’s Manual 33...

  • Page 34: Main Setup

    Use this menu for basic system configurations, such as time, date etc. BIOS Information Displays the auto-detected BIOS information.  System Date The date format is <Date>,<Month>,<Day>,<Year>.  System Time The time format is <Hour>,<Minute>,<Second>. 34 RX610H User’s Manual...

  • Page 35: Advanced Menu

    User’s Manual 3.6.3 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 3.6.3.1 CPU Configuration RX610H User’s Manual 35...

  • Page 36: Power & Performance

    Hyper-Threading Enable or disable Hyper-Threading technology Configuration options: [Enable] [Disable] 3.6.3.2 Power & Performance Power management control for CPU  Intel® Speedstep™ [Enabled] Allow more than two frequency range to be supported Configuration options: [Enable] [Disable] 36 RX610H User’s Manual...

  • Page 37: Pch-Fw Configuration

    When enabled, CPU will switch to minimum speed when all cores enter C state Configuration options: [Enable] [Disable]  Package C state limit Maximum package C state limit setting. CPU default: Leaves to factory default value Configuration options: [C0/C1] [C2] [C3] 3.6.3.3 PCH-FW Configuration RX610H User’s Manual 37...

  • Page 38: Trusted Computing

    Configuration options: [Lock] [Unlock] 3.6.3.4 Trusted Computing Security device settings  TPM Device Selection [dTPM] Select TPM device Configuration options: [dTPM] [PTT]  Security Device support [Disabled] Enable or Disable BIOS support security device Configuration options: [Enable] [Disable] 38 RX610H User’s Manual...

  • Page 39: Acpi Settings

    PCIE# wake from S5 [Disabled] Enable or disable PCIE wake the system from S5. Configuration options: [Disabled] [Enabled] Wake on Ring [Disabled]  Enable or disable wake on ring function under ACPI S3/S4/S5. Configuration options: [Disabled] [Enabled] RX610H User’s Manual 39...

  • Page 40: Nct6126D Super Io Configuration

    WatchDog count mode Selection Configuration options: [Second] [Minute]  WatchDog Timeout value Fill watchdog timeout value, 0 means disables  Chassis opened warning [Disabled] Select chassis intrusion enabled to Disabled Configuration options: [Disabled] [Enabled] ErP/EuP S5 Support [Disabled]  Configuration options: [Disabled] [Enabled] 40 RX610H User’s Manual...

  • Page 41: Serial Port 1 Configuration

    User’s Manual 3.6.3.6.1 Serial Port 1 Configuration  Serial Port [Enabled] Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] Change Setting [Auto]  Select an optimal settings for super IO device Configuration options: as below RX610H User’s Manual 41...

  • Page 42: Serial Port 2 Configuration

    RX610H User’s Manual 3.6.3.6.2 Serial Port 2 Configuration  Serial Port [Enabled] Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] Change Setting [Auto]  Select an optimal settings for super IO device Configuration options: as below 42 RX610H User’s Manual...

  • Page 43: Serial Port 3 Configuration

    Configuration options: [Disabled] [Enabled] Change Setting [Auto]  Select an optimal settings for super IO device Configuration options: as below COM Mode Select [RS232]  Configure the COM port Mode Configuration options: [RS232][RS485 Half Duplex][RS422 Full Duplex] RX610H User’s Manual 43...

  • Page 44: Serial Port 4 Configuration

    RX610H User’s Manual 3.6.3.6.4 Serial Port 4 Configuration Serial Port [Enabled]  Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled]  Change Settings [Auto] Select an optimal settings for super IO device Configuration options: as below 44 RX610H User’s Manual...

  • Page 45: Serial Port 5 Configuration

    User’s Manual 3.6.3.6.5 Serial Port 5 Configuration Serial Port [Enabled]  Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled]  Change Settings [Auto] Select an optimal settings for super IO device Configuration options: as below RX610H User’s Manual 45...

  • Page 46: Serial Port 6 Configuration

    RX610H User’s Manual 3.6.3.6.6 Serial Port 6 Configuration Serial Port [Enabled]  Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled]  Change Settings [Auto] Select an optimal settings for super IO device Configuration options: as below 46 RX610H User’s Manual...

  • Page 47: Parallel Port Configuration

    User’s Manual 3.6.3.6.7 Parallel Port Configuration  Parallel Port [Enabled] Enable or Disable parallel Port (LPT) Configuration options: [Disabled] [Enabled] Change Settings [Auto]  Select an optimal settings for super IO device Configuration options: as below RX610H User’s Manual 47...

  • Page 48: Hardware Monitor

    RX610H User’s Manual  Device mode [STD Printer Mode] Change the printer port mode Configuration options: as below 3.6.3.7 Hardware Monitor Display Hardware monitor information 48 RX610H User’s Manual...

  • Page 49: Smart Fan Function

    User’s Manual 3.6.3.7.1 Smart Fan Function  Smart FAN Function [Enabled] Smart fan function Enable/Disabled Configuration options: [Enabled] [Disabled] [Manual] 3.6.3.7.1.1 Smart FAN mode Configuration Setting different FAN on this motherboard RX610H User’s Manual 49...
  • Page 50 RX610H User’s Manual  SYS_FAN1/CPU_FAN1/CHA_FAN1 FAN Target Smart FAN target temperature Configuration options: Please see below picture  CPU_FAN1/CHA_FAN1/CHA_FAN2 MIN.FAN Speed (%) CPU or Chassis Smart FAN minimum settings Configuration options: Please see below picture 50 RX610H User’s Manual...

  • Page 51: S5 Rtc Wake Settings

    User’s Manual 3.6.3.8 S5 RTC wake settings  Wake system from S5 [Disabled] Enabled or Disabled system wake on alarm event Configuration options: [Enabled] [Disabled] 3.6.3.9 Serial Port Console Redirection Display CPU configuration RX610H User’s Manual 51...

  • Page 52: Console Redirection Settings

    Configuration options: [9600] [19200] [38400] [57600] [115200]  Bits per second[115200] Select data bits Configuration options: [7] [8] Parity[None]  A parity bit can be sent with the data bits to detect some transmission errors Configuration options: [None] [Even] [Odd] [Mark] [Space] 52 RX610H User’s Manual...
  • Page 53 With this mode enabled only text will be sent. Configuration options: [Enabled] [Disabled]  Resolution 100x31[Disabled] Enables or disables extended terminal resolution Configuration options: [Enabled] [Disabled] Putty Keypad[VT100]  Selects function key and keypad on putty Configuration options: [VT1000] [LINUX] [XTERMR6] [SCO] [ESCN] [VT400] RX610H User’s Manual 53...

  • Page 54: Intel Txt Information

    RX610H User’s Manual 3.6.3.10 intel TXT information Display Intel TXT information. This depends on CPU sku. 3.6.3.11 USB configuration 54 RX610H User’s Manual...
  • Page 55 User’s Manual  USB Mass Storage Driver Support[Enabled] Enable or Disable USB Mass Storage Driver Support Configuration options: [Enabled] [Disabled]  Mass Storage Devices[Auto] Mass Storage device emulation Type. “Auto” enumerates device according to its media format. RX610H User’s Manual 55...

  • Page 56: Network Stack Configuration

    Enabled or disabled IPv6 PXE boot Support Configuration options: [Enabled][Disabled]  PXE boot wait time Wait time in seconds to press ESC key to abort the PXE boot. Media detect count  Number of time the presence of media will be checked 56 RX610H User’s Manual...

  • Page 57: Ip Configuration

     Auto Configuration[Disabled] Allow user to set IP. DisabledIP won’ t set Every BootSets IP on every boot On demandUser has to set IP using IPConfig interface. 3.6.3.14 NVMe Configuration Display NVMe controller or Drive information RX610H User’s Manual 57...

  • Page 58: Remote Server Configuration

    Configuration options: [Disabled] [Enabled]  Auto Server searching [Enabled] Enabled to obtain DHCP server IP automatically. Disabled to provide Server IP manually. Need to do clear Enrollment, if server is changed to DHCP. Configuration options: [Enabled] [Disabled] 58 RX610H User’s Manual...

  • Page 59: Chipset

    User’s Manual 3.6.4 Chipset 3.6.4.1 System Agent (SA) Configuration  VT-d [Enabled] VT-d capability Configuration options: [Disabled] [Enabled] RX610H User’s Manual 59...

  • Page 60: Memory Configuration

    RX610H User’s Manual 3.6.4.1.1 Memory Configuration Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. 3.6.4.1.2 Graphics Configuration Graphic configuration settings 60 RX610H User’s Manual...
  • Page 61 Configuration options: [Auto] [disabled] [enabled]  PSMI Support [Disabled] PSMI eabled/Disabled Configuration options: [Disabled] [Enabled]  DVMT Pre-allocated [60M] Select DVMT 5.0 Pre-allocated (Fixed) Graphics memory size used by the internal graphics device. Configuration options: As below picture RX610H User’s Manual 61...
  • Page 62 RX610H User’s Manual 3.6.4.1.3 PCI Express Configuration Detect Non-compliance Device[Disabled]  Detect Non-compliance Device in PEG Configuration options: [Disabled] [Enabled] 3.6.4.1.3.1 PCI Express Root Port 2 (x16 slot1) 62 RX610H User’s Manual...

  • Page 63: Pch-Io Configuration

    Configuration options: [Auto] [Gen1] [Gen2] [Gen3] [Gen4] [Gen5] 3.6.4.2 PCH-IO Configuration  Lan1 Controller [Enabled] Enable or Disable onboard LAN1 Configuration options: [Disabled] [Enabled]  Lan1 PXE OpROM [Disabled] Enabled or Disabled boot option for LAN1 controller Configuration options: [Disabled] [Enabled] RX610H User’s Manual 63...
  • Page 64  Enabled Flash Protection Range Registers Configuration options: [Disabled] [Enabled]  GPIO Group Control[Disabled] Configure the digital GPIO pins Configuration options: [Disabled] [Enabled]  Amplifier GAIN(db)[15.3db] Select Amplifier GAIN value Configuration options: [15.3db] [21.2db] [27.2db] [31.8db] 64 RX610H User’s Manual...

  • Page 65: Pci Express Configuration

    PCI Express Root Port 1[Enabled]  Control the PCI Express Port Configuration options: [Disabled] [Enabled]  ASPM Support[Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM RX610H User’s Manual 65...

  • Page 66: Pci Express Root Port 2(X16 Slot 3)

    PCI Express Root Port 2[Enabled]  Control the PCI Express Port Configuration options: [Disabled] [Enabled]  ASPM 2[Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM 66 RX610H User’s Manual...

  • Page 67: Pci Express Root Port 4(X16 Slot 4 & M.2 E Key)

    PCI Express Root Port 4[Enabled]  Control the PCI Express Port Configuration options: [Disabled] [Enabled]  ASPM 4[Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM RX610H User’s Manual 67...

  • Page 68: Pci Express Root Port 5(X4 Key M)

    PCI Express Root Port 5[Enabled]  Control the PCI Express Port Configuration options: [Disabled] [Enabled]  ASPM 5[Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM 68 RX610H User’s Manual...

  • Page 69: Sata Configuration

    Detect non-compliance PCI express Device, If enabled, it will take more time at Post time. Configuration options: [Disabled] [Enabled] 3.6.4.2.2 SATA Configuration SATA Controller(s)[Enabled]  Enable or Disable SATA device Configuration options: [Enabled] [Disabled]  SATA Mode Selection[AHCI] Determines how SATA controller operate Configuration options: [AHCI] RX610H User’s Manual 69...

  • Page 70: Usb Configuration

    Enable or Disable SATA port 4 Configuration options: [Enabled] [Disabled] 3.6.4.2.3 USB Configuration USB12 Standby Power[Enabled]  Enable or Disable USB standby power Configuration options: [Disabled] [Enabled]  USB34 Standby Power[Enabled] Enable or Disable USB standby power Configuration options: [Disabled] [Enabled] 70 RX610H User’s Manual...

  • Page 71: Hd Audio Configuration

    Enable or Disable USB standby power Configuration options: [Disabled] [Enabled]  USB1112 Standby Power[Enabled] Enable or Disable USB standby power Configuration options: [Disabled] [Enabled] 3.6.4.2.4 HD Audio Configuration HD audio[Enabled]  Control Detection of the HD-Audio device. Configuration options: [Disabled] [Enabled] RX610H User’s Manual 71...

  • Page 72: Serial Io Configuration

    RX610H User’s Manual 3.6.4.2.5 Serial IO Configuration  I2C0 Controller[Enabled] Enabled/Disabled Serial IO Controller Configuration options: [Disabled] [Enabled] I2C2 Controller[Enabled]  Enabled/Disabled Serial IO Controller Configuration options: [Disabled] [Enabled] 72 RX610H User’s Manual...

  • Page 73: Security

    User’s Manual 3.6.5 Security Administrator Password  Set Administrator Password  User Password Set User Password RX610H User’s Manual 73...

  • Page 74: Boot

    Select boot mode LEGACY/UEFI Configuration options: [LEGACY] [UEFI]  UEFI USB Key Drive BBS Priorities Specifies the boot device priority sequence from available UEFI USB key Drives. UEFI Application Boot Priorities  Specifies the boot device priority sequence from available UEFI Application. 74 RX610H User’s Manual...

  • Page 75: Save & Exit

    Reset the system after saving the changes.  Restore Defaults Restore/Load default values for all the setup option.  Launch EFI Shell from filesystem device Attempts to launch EFI shell application from one of the available filesystem devices.  AMIFWUpdate Launches AMIFWUpdate RX610H User’s Manual 75...

  • Page 76: Mebx

    RX610H User’s Manual 3.6.8 MEBx 76 RX610H User’s Manual...

  • Page 77: Drivers Installation

    User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. RX610H User’s Manual 77...

  • Page 78: Install Chipset Driver

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next. Step 3. Click Install. Step 4. Complete setup Step 2. Click Accept. 78 RX610H User’s Manual...

  • Page 79: Install Vga Driver

    If the warning message appears while the installation process, click Continue to go on. Step 1. Click Begin installation. Step 3. Click Start. Step 2. Click Next to accept license Step 4. Click Finish. agreement. RX610H User’s Manual 79...

  • Page 80: Install Me Driver

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step 1. Click Next to continue setup. Step 3. Click Next. Step 2. Click Next. Step 4. Click Finish to complete setup. 80 RX610H User’s Manual...

  • Page 81: Install Audio Driver (For Realtek Alc897 And Alc888S Hd Audio)

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next to Install. Step 2. Click Finish to complete setup. RX610H User’s Manual 81...

  • Page 82: Install Lan Driver

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step 1. Click Next to continue installation. Step 3. Click Close. Step 2. Click OK. 82 RX610H User’s Manual...

  • Page 83: Install Serial Io Driver

    Continue to go Step 3. Click Next. Step 1. Click Next to continue setup. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. RX610H User’s Manual 83...

  • Page 84: Install Intel_Dtt

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go Step 1. Click Next to continue setup. Step 3. Click Next. Step 2. Click Yes. Step 4. Click Finish to complete setup. 84 RX610H User’s Manual...

  • Page 85: Mechanical Drawing

    User’s Manual 5. Mechanical Drawing RX610H User’s Manual 85...
  • Page 86 RX610H User’s Manual Unit: mm Unit: mm 86 RX610H User’s Manual...
