Page 2 (contents of its read-only memory). This manual, any copyrightable subject matter sold or provided with or in connection with the sale of the page printer, are protected by copyright. All rights are reserved. Copying or other reproduction of all or part of this manual, any copyrightable subject matter without the prior written consent of Kyocera Corporation is prohibited.
Page 3 Introduction IBM PROGRAM LICENSE AGREEMENT THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL REFUND.
Page 4 3. Limitation of Remedies IBM’s entire liability under this license is the following; 1) For any claim (including fundamental breach), in any form, related in any way to this license, IBM’s liability will be for actual damages only and will be limited to the greater of: a) the equivalent of U.S.$25,000 in your local currency;...
Page 5 FONTWARE/TrueDoc developed by BITSTREAM INC. is provided as part of this Printer by KYOCERA CORPORATION under license. KYOCERA, as a Licensee of BITSTREAM, grants you, the Sublicensee, non-exclusive right to use FONTWARE/TrueDoc installed in this Printer, if you agree to and at all times comply with the following items: 1. Ownership As the Sublicensee, you own the Printer in which FONTWARE/TrueDoc is originally installed, but BITSTREAM retains title to and ownership in the software program of FONTWARE/TrueDoc.
Page 6: Fcc Statement
FCC statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 7 Introduction To use equipment which does not comply with FCC rules is prohibited. The printer may be optionally installed with the following units: Conforming to the Class B limits DU-25 Duplexer HD-1 Hard Disk Unit PF-25 Paper Feeder (B5 to Ledger)
Page 8: Interface Connectors
Safety information Laser safety This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to Radiation Control for Health and Safety Act of 1968. This means that the printer does not produce hazardous laser radiation. Since radiation emitted inside the printer is completely confined within protective housings and external covers, the laser beam cannot escape from the printer during any phase of user operation.
Page 9 Introduction CAUTION Laser Radiation when remove the Laser Scanner Unit Cover in the printer. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS. * Use of controls or adjustments or performance of procedures other than those specified (Philippines) (Europe/Asia) (U.S.A./Canada)
Page 10: Ozone Concentration
) which may concentrate in the place of installation and cause an unpleasant smell. To minimize concentration of ozone gas to less than 0.1 ppm, we recommend you not to install the printer in a confined area where ventilation is blocked.
Page 11: Important Safeguards
Introduction IMPORTANT SAFEGUARDS 1. Read all of these instructions and save these instructions for later use. 2. Unplug this product from the wall outlet before cleaning. 3. Do not use this product near water. 4. Do not place this product on an unstable cart, stand, or table. The product may fall, causing 5.
Page 12 E - If the product has been dropped or the cabinet has been damaged. FS-6700 Kyocera Kyocera Electronics Inc.
Page 13: Ce Marking Directive
Kyocera Corporation, Printer Division 2-14-9 Tamagawadai, Setagaya Ward, Tokyo 158-8610, Japan Page Printer FS-6700 (as tested with enhancement optional units: PF-25, DU-25, and HD-1) EN 55 022:1994 Class B EN 61 000-3-2:1995...
Page 14: Declaration Of Conformity (Australia)
Conforms to the following product specifications. Description of device: This page printer model FS-6700 is the 20-ppm, up to A3 size paper adaptable, printer that utilizes plain paper, laser, dry toner etc. The printer can be equipped with several enhancement optional units such as the paper feeder PF-25, duplexer DU-25, etc.
Page 15: Canadian Department Of Communications Compliance Statement
Introduction Canadian Department of Communications compliance statement This Class B digital apparatus complies with Canadian ICES-003. Avis de conformité aux normes du ministère des Communications du Canada Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. ISO 7779 Maschinenlärminformationsverordnung 3.
Page 16: Prolonged Non-Use And Moving The Printer
Prolonged Non-Use and Moving the Printer Prolonged Non-use If you ever leave the printer unused for a long period of time, remove the power cord from the wall outlet. We recommend you consult with your dealer about the additional actions you should take to avoid possible damages that may occur when the printer is used next time.
Page 17 Introduction Note The magnet roller of the developer unit includes a powerful magnet. Do not allow wrist watches, floppy disks, credit cards or magnetic cards near the roller. 1. Remove the developer unit. 1 Remove the connector. 2. Place the developer unit in the protective package for transportation. Note Place the toner container and waste toner bottle in the plastic bag included in the toner kit.
Page 18: Energy Star
This printer is equipped with a sleep timer function that conforms with the standards of the ENERGY STAR Program. This function makes it possible to reduce the amount of electrical power consumed by the printer.
Page 19 Introduction Kyocera ECO-PRODUCT This product has been developed and manufactured with the express interest of reducing the impact on the environment. Using Kyocera's innovative cartridge free technology, Kyocera has created an advanced printing system that does not require the wasteful replacement and disposal of a cartridge. xviii...
Page 20: Amorphous Silicon Drum
(*See page 2-31.) Ultra long life modules The main modules in this laser printer such as the drum, developer unit and fuser unit, which are disposable in conventional printers, are specifically designed for extraordinarily long life and need no periodic replacement.
Page 21: High Speed Printing
This printer allows reductions between various paper sizes using the page setup function. Bitmapped and scalable typefaces In addition to its 80 internal bitmap fonts, the printer provides 45 fully-scalable resident typefaces that are equivalent to HPLJ fonts. The scalable typefaces can be used at any size desired up to 999.75 points, in 0.25-point increments.
Page 22 Please contact your Kyocera dealer. Memory card slot for option fonts, macros, forms, etc. Data in the memory card can be selectively read or written from the printer’s control panel. Simple Network Management Protocol (SNMP) compliance Offers network managers complete open system network management.
Page 23 Introduction Large memory capacity This printer comes standard equipped with 4 MB of memory. This can be extended up to 68 MB of memory through optional expansion of memory. Equipped with two expansion slots The printer’s expansion slots can be used to install an optional network interface board or hard disk unit.
Page 24: Table Of Contents
Contents Chapter 1 Installing the Printer... 1-1 Chapter 2 Operating the Laser Printer ... 2-1 Chapter 3 Fonts... 3-1 1.1. Positioning the Printer ... 1- 2 1.2. Unpacking and Inspection ... 1- 6 1.3. Names of Parts ... 1- 8 1.4.
Page 25 Introduction Chapter 4 Maintenance... 4-1 Chapter 5 Troubleshooting ... 5-1 Chapter 6 Symbol Set Tables ... 6-1 Appendix A Printer Specifications ... A-1 Appendix B Paper Selection ... B-1 Appendix C Host Computer Interface ... C-1 Index ... INDEX-1 Mode Select Menu ... Lastpage xxiv 4.1.
Page 26: Chapter 1 Installing The Printer
Chapter 1 Installing the Page Printer Chapter 1 Installing the Printer This chapter explains how to unpack and install the printer. The topics covered are: 1.1. Positioning the Printer ... 1- 2 1.2. Unpacking and Inspection ... 1- 6 1.3. Names of Parts ... 1- 8 1.4.
Page 27: Positioning The Printer
1.1. Positioning the Printer Clearance Allow at least the necessary minimum clearance around the printer (see below). A total space of 103 cm by 65 cm by 151 cm (41 by 26 by 59 inches) is needed. 30 cm (12 inches)
Page 28: Places To Avoid
Chapter 1 Installing the Page Printer Places to Avoid Avoid installing the printer in locations subject to: Direct drafts of hot or cold air Direct drafts from outside (Avoid locations near doors leading outside.) Sudden temperature or humidity changes Sources of high temperature, for example, near stoves or radiators...
Page 29: Basic Requirements
3 meters (10 feet). Place the printer on a sturdy table or desk. Do not place the printer on an unstable cart, stand, or table. The printer may fall, causing injury, or serious damage to the printer.
Page 30: Power Supply
Power Supply The printer should not be on the same power circuit as an air conditioner, fluorescent light, copier, or shredder, because these devices generate electrical noise on the power line. If it must share a power circuit with equipment like this, a high-frequency noise filter or isolation transformer is advisable.
Page 31: Unpacking And Inspection
Save the box and other packing materials in case you have to repack the printer for transportation at a later date.
Page 32 To remove the printer from the box, grasp the handholds on either side of the printer. Lift the printer from the carton as shown below. If necessary, have two people lift the printer. Notes Always use these handholds whenever you lift or move the printer.
Page 33: Names Of Parts
1.3. Names of Parts 1.3. Names of Parts This section takes you on a guided tour of the printer, pointing out its major parts. The part names introduced here will be used throughout this manual. Front View Face-down Paper Full Sensor...
Page 34: Interior View
Parallel Interface Connector* ( Toner Container Main Charger Unit *: To protect the printer against static discharge, the connector must be covered with the supplied protective cap when not in use. Chapter 1 Installing the Page Printer Rear Cover Serial Interface...
Page 35: Setting Up And Interfacing
1.4. Setting Up and Interfacing Before you can use the printer for the first time, you must set up the printer by installing the printer components and interfacing with the computer. The steps to be followed in setting up are: 10.
Page 36: Install The Toner Container
1. Open the Top Cover 1. Remove the packing tape from the printer. 2. Open the printer top cover all the way. 2. Install the Toner Container 1. Take the toner container from the toner kit. 2. With the side where the toner kit name and precautions are printed facing down, thoroughly...
Page 37 1.4. Setting Up and Interfacing 3. The bottom of the toner container is sealed with a sealing strip. Peel off the seal on the toner Note Be sure to peel the seal off the toner container before the toner container is fitted into the developer unit.
Page 38: Close The Top Cover
5. When the toner container is installed correctly on the developer, push the top of the container unit (“PUSH HERE”) until it locks in. Note Make sure that the toner container is properly locked in the printer. Top Cover 3. Close the Top Cover Close the top cover.
Page 39: Install The Waste Toner Bottle
1.4. Setting Up and Interfacing 4. Install the Waste Toner Bottle The waste toner bottle is in the toner kit supplied with the printer. The waste toner bottle must be installed in the printer. Install the waste toner bottle in the printer as follows.
Page 40 Chapter 1 Installing the Page Printer 3. Insert the waste toner bottle with the bottle tilted slightly towards you as shown in the figure. Waste Toner Bottle 4. Ensuring that it is correctly inserted, close the side cover. Note Although the waster toner bottle will be tilted slightly toward you, it will install properly when the side cover is closed.
Page 41: Adjusting The Paper Guides Of The Paper Cassette
By adjusting the position of the paper guides and paper stopper inside the cassette included with this printer, the cassette may be set to supply paper of standard sizes from A5 size to ledger size. The cassette is set to accommodate A4 or letter size when shipped from the factory.
Page 42 Chapter 1 Installing the Page Printer 1. Open the cassette cover. Cassette Cover 2. Adjust the paper guides. Adjust by pressing the lock levers as shown in the figure and aligning the paper guides to the paper size to be used.
Page 43 1.4. Setting Up and Interfacing 3. Check the position of the paper guides and release the lock levers. 4. Align the paper stopper to the correct position for the paper size to be used and firmly push it Paper stopper 1-18 into place in the order 1, 2.
Page 44: Add Paper
Notes 1. Push the bottom plate until it locks. Before adding paper, remove the paper cassette all the way from the printer. Be sure to add paper only after all paper inside the paper cassette has run out. Adding paper before paper in the cassette has run out may result in paper jams.
Page 45 1.4. Setting Up and Interfacing 2. Set the paper in the cassette. The paper size must match the cassette size. Tap the edges of 1-20 the paper to align them neatly. Don’t put in more paper than the limit indicated on the cassette. (The cassette should hold approximately 250 sheets of paper with a 75 g/m ness.) The side of the paper that faces downward in the cassette is printed on.
Page 46 Chapter 1 Installing the Page Printer 3. Set the clips at the two corners as shown below. Clips Note Some types of paper (such as thick paper) may be hard to place in the cassette using this method. If this is the case, the process is facilitated by inserting the paper from the back, as shown in the figure below.
Page 47 1.4. Setting Up and Interfacing 4. Close the paper cassette cover. 5. Insert the paper cassette into the printer cassette slot. Push it straight as far as it will go. 1-22 Cassette Cover...
Page 48: Open The Paper Stopper On The Face-Down Output Tray (If Required)
8. Install the Face-up Output Tray (sold separately) Use the separately sold PT-3 face-up output tray if you want the printed pages stacked face-up (reverse order). Install the face-up output tray as shown in the figure. Chapter 1 Installing the Page Printer Face-up Output Tray (PT-3) 1-23...
Page 49: Connect The Printer To The Computer
9. Connect the Printer to the Computer The printer has two computer cable connectors and a slot for installing an option interface. The one marked “ ” is for a parallel (Centronics standard) interface. The one marked “IOIOI” is for a serial (RS-232C/RS-422A) interface.
Page 50: Parallel Interface
Chapter 1 Installing the Page Printer Parallel interface Plug one end of the cable into the connector marked Parallel ( ) on the printer. Close the clips on both sides to hold it in place. Plug the other end into a parallel (Centronics) interface connector on your computer. This connector is usually marked PRINTER .
Page 51: Attach The Power Cord
1. Switch on the printer’s power. The message display should indicate Self test. Note When the printer is first switched on after the toner container is installed, there will be a delay of several minutes (approx. 10 minutes) before the printer will be ready to print. During this period, the toner indicator 2.
Page 52: Test The Interface With The Computer
2. Boot the computer in DOS mode, or set the computer to DOS (prompt) MODE. 3. At the DOS prompt, type the following. If the printer prints a status page, the computer and printer are connected correctly. For details on the status page, refer to Chapter 2.
Page 53: Install The Printer Driver
LaserJet 5M at power-up. If you primarily use software that supports HP LaserJet 5M, or that supports the Kyocera printer itself, the factory setting is the one you want. If you primarily use software that supports another printer, it is convenient to change the printer’s power-up emulation mode.
Page 54 Chapter 1 Installing the Page Printer 2. Double click Add Printer . 3. Add Printer Wizard will be shown. Follow the instructions on your screen. When you have finished, the icon for the printer will appear in the Printers folder. 1-29...
Page 55 1.4. Setting Up and Interfacing Windows 3.1 To install the printer driver for Windows 3.1, proceed as follows: 10. When the driver is installed, click on Close to close Control Panel . 1-30 Insert the Kyocera Digital Library CD-ROM in your CD-ROM drive.
Page 56: Multi-Purpose Tray Feeding
1.5. Multi-Purpose Tray Feeding The multi-purpose tray is incorporated in the front of the printer. It can be used in one of three modes: the first mode, cassette mode or manual mode. First mode: (automatic manual feeding) Cassette mode: Manual mode:...
Page 57 4. Check that the printer is Ready. 5. Press the FEED key until the message display indicates MP tray and the multi-purpose tray 1-32 indicator on the printer symbol flashes, and Add paper appears on the message display. Sub Tray Paper Guides...
Page 58 (A4-R, Letter-R) from the control panel when using A4 size or letter size paper. The following pages explain the use of the multi-purpose tray in the First Mode, Casette Mode, and Manual Mode. Chapter 1 Installing the Page Printer Paper Limit Indicator 1-33...
Page 59: Setting Each Mode
The printer will not switch to light the multi-purpose tray indicator while the paper is fed manually using the automatic manual feeding mode. The automatic manual feed is not available if the printer is installed with the duplexer, and if the duplexer is selected for use.
Page 60 Change the paper size by pressing the + or – key and then press the ENTER key. >MP tray size 4. Press the EXIT key. Ready appears on the message display. Chapter 1 Installing the Page Printer 1-35...
Page 61: Manual Mode
If you want to abandon the manual feeding procedure, press the CANCEL key. The message display indicates Print Cancel ?. Press the ENTER key. The printer will return to Ready. CONTINUE is displayed. In this way the printer will print one sheet at a time.
Page 62: Feeding Envelopes
To avoid trouble, OHP film must be fed manually in the manner described above. Requirements regarding OHP film are also given in Appendix B. Note OHP film must be delivered face-up. Use the STACK key on the printer control panel to select the face-up tray. 1-37...
Page 63: Memory Card
A memory card is a microchip card containing, for example, nonresident fonts and/or macros, forms, etc. The printer reads the contents of the card into its internal memory when power is switched on. The presence of this data in the printer memory can be confirmed on the status printout.
Page 64: Handling Memory Cards
3. Switch printer power on. The printer reads the contents of the memory card during its power-up If the memory card information is deleted from the printer’s memory during the printing process, it can be reread by using the mode selection function explained on the last page in this manual.
Page 65: Memory Expansion Installation
It begins by explaining how to remove the main circuit board from the printer, and explains how to install a SIMM (single in-line memory module) on the main circuit board.
Page 66: Removing The Main Circuit Board
Withdrawing the Main Circuit Board from the Printer Note Be sure to remove the memory card first if inserted in the printer’s memory card slot. Withdraw the main circuit board completely from the printer as follows: 1. Turn the printer’s power off. Unplug the printer’s power cable and disconnect the printer from 2.
Page 67: Simm To Be Used
3. Pull the main circuit board all the way out of the printer. Note Before pulling the main board out, clean an area on the table, etc., at the back of the printer’s rear panel. Foreign objects, accidentally sticking to the back of the main board, can cause serious damage to the printer.
Page 68: Installing And Removing Simms
Chapter 1 Installing the Page Printer Installing and Removing SIMMs Installing SIMMs Insert the SIMM into the socket as shown below. 1. Insert the connector end of the SIMM into the socket. 2. Carefully push the board upright until it snaps into place. Make sure that the catches at the ends of the socket fit into the holes at the ends of the SIMM board.
Page 69: Testing The Expansion Memory
To test the expansion memory, proceed as follows: 1. Make sure the power switch is off. Plug the power cord into the printer and turn power on. 2. When the printer is on-line, press the STATUS key. 3. If the installation has been successful, the Total memory (Memory Allocation) of the status page 1-44 will show the expanded memory size corresponding to the amount of memory added.
Page 70: Chapter 2 Operating The Laser Printer
Chapter 2 Operating the Laser Printer Chapter 2 Operating the Laser Printer This chapter explains the printer’s control panel and operating procedures. It covers the fundamental information you will need to use the page printer. 2.1. Control Panel ... 2- 2 2.2.
Page 71: Control Panel
2.1. Control Panel 2.1. Control Panel The printer control panel comprises a message display, keys, and indicators, as shown below. Message Display ( Page 2-3) Paper Size Indicator Resolution Indicator Interface Indicator Symbolic Indicators ( Page 2-6) Copy Indicator Page 2-4, 5)
Page 72: Message Display
The message display gives information in the form of short messages. The seven messages listed below are displayed during normal warm-up and printing. Other messages appear when the printer needs the operator’s attention as explained in Chapter 5. Message The printer is self-testing after power-up.
Page 73: Resolution Indicator
The interface indicator shows which of the printer’s interfaces is currently active. It uses the following abbreviations: The PAR, SER, OPT1, or OPT2 indicator flashes when the printer is receiving and has received all the data, and then remains on. The printer gives priority to data coming in over the interface corresponding to the blinking indicator.
Page 74: Paper Size Indicator
Paper Size Indicator The paper size indicator indicates the paper size of the cassette currently installed in the printer or the paper size currently set for the multi-purpose tray. The following abbreviations are used to indicate the paper sizes. ISO A3 (29.7cm ISO A4 (21 cm ISO A5 (14.8 cm...
Page 75: Symbolic Indicators
Flashing: • Indicates there is insufficient toner. See Section 4.1. Toner indicator Lit: Indicates that the printer is out of toner. Replace with a new toner container. See Section 4.1. Flashing: Indicates the possibility that paper may be jammed at this Cassette feed point, open and remove any jammed paper.
Page 76: Control Keys
Control Keys The control panel keys are used to configure the printer. Note Settings made with these keys effect only the interface currently in use. ON LINE CONTINUE STACK FORM FEED CANCEL MODE Switches the printer on-line and off-line. 1. Depending on the message being indicated, there are cases where operation will continue after pressing the CONTINUE key.
Page 77 Most of the panel functions can also be controlled by PRESCRIBE IIe commands or commands generated by application software. The printer obeys the most recently received printer settings sent from the application software, or from the printer driver, which take priority over control panel settings.
Page 78: Operating Precautions
Operating Precautions Do not turn off power during printing. This may result in a paper jam or damage to the printer. Do not open covers on the printer or covers of optional equipment or move the printer during printing.
Page 79: Switching Power On
2.2. Operating Procedures Switching Power On Check that the power cord is securely plugged in at both ends. Check that the printer is connected to the computer (See page 1-24). 1. Push the power switch to the ON ( | ) position.
Page 80: Basic Printing Operations
1. Use the MODE key to set an emulation for the printer which conforms to the software being 2. Use the MODE key to select the font to use and paper direction.
Page 81: Selecting The Output Tray
Normally it is more convenient to use the face-down output tray. The optional PT-3 face-up tray must be installed in the printer to output pages face-up tray. When the message Ready or Add paper appears in the message display, the output tray will be switched every time the STACK key is pressed and the selected destination will appear in the message display as follows.
Page 82: Feed Selection
(Paper feeder’s cassette) Cassette (1) (Displayed when an optional feeder is installed) Cassette 2 (Displayed when a second optional feeder is installed) Cassette 3 (Printer’s multi-purpose tray) MP tray Cassette indicator Chapter 2 Operating the Laser Printer MP (multi-purpose) tray indicator 2-13...
Page 83: Switching Online/Offline
The printer continues to receive data even while the printer is offline while the message Processing is displayed. Press the ON LINE key to bring the printer online again. The printer will come online and the ON LINE indicator will light.
Page 84: Canceling Printing
When the ENTER key is pressed, the message Cancelling data appears in the message display and printing stops after the printer finishes printing the current page. Chapter 2 Operating the Laser Printer...
Page 85: Status Printout
Notes Status Printout It is possible to print out and check the printer’s current status including unit emulation, font, and memory usage. 1. Check that the ON LINE indicator lit and that the message Ready is displayed in the message 2.
Page 86: Sample Status Page
Sample Status Page Chapter 2 Operating the Laser Printer 2-17...
Page 87 3 Page information This information shows the currently selected resolution and number of copies. 4 Memory usage This information shows the amount of total memory installed in the printer and the amount of currently available memory. 5 Installation Options This shows the options currently installed in the printer.
Page 88 8 Fonts at startup (for each interface) This shows the font automatically selected when the printer starts up (default font). It is possible to set different fonts for the parallel interface and the serial interface. The figure on page 2-17 shows default settings.
Page 89: Mode Selection
The message Waiting may be displayed in the message display when you get to the end of a print job. This occurs when the software does not issue a final form feed to the printer indicating the end of the print data. In this case, pressing the FORM FEED key allows you to finish printing immediately.
Page 90: Mode Selection Menu
Serial setting has five sub items, and sets the following RS-232C/RS-422A parameters: Baud rate Data bit Stop bit Parity Protocol up to 999. Chapter 2 Operating the Laser Printer keys. The key moves to higher levels. Default Setting Parallel Nibble (high) 9600 None DTR (pos.) &...
Page 91 Size reduction settings [See page 2-26] landscape page orientations. The several operations can be performed from sub-menus on memory cards installed in the printer. Reads information from the option ROM installed in the printer’s main board. The several settings can be made from sub-menus when an optional hard disk unit is installed.
Page 92 Alarm (buzzer) setting Service (for service personnel) *: These items are available only when the printer is installed with the applicable option unit/kit. For items with the > mark on the message display, the the sub items which give access to more items to change the relevant settings.
Page 93: Parallel Interface Mode
Nibble (high) Auto Normal High speed After setting the interface, be sure to reset the printer or turn the power off at least once. The new setting will be enabled thereafter. 2-24 Description High speed data communication is used in compliance with the IEEE 1284 standard.
Page 94: Emulation Selection
2.5. Emulation Selection The following emulations can be selected for this printer. The emulation selected is stored even while the printer’s power is off. KC-GL Emulation The following settings can be made from the sub-menu when KC-GL emulation is selected.
Page 95: Reduction
2.6. Reduction (Page Set) 2.6. Reduction (Page Set) Make settings on the page set menu to print at a reduced size. This menu is used to set the source paper size and the paper size to use after reduction. These settings can be made from within programs or files using the PRESCRIBE SPSZ command.
Page 96 Ledger size 17 inches) (14.8 21 cm) (18.2 25.7 cm) 29.7 cm) (25.7 36.4 cm) (29.7 42 cm) Chapter 2 Operating the Laser Printer Reduction/Enlargement Ratio 100% CS 98% 100% LG 98% 100% LT 98% 100% LD 98% 100% A5 98%...
Page 97: Sleep Timer Setting
Pressing a key on the control panel, opening and closing a cover, or sending data to the printer while it is displaying Sleeping will cause the printer to display Please wait and it will begin warming up.
Page 98: Selecting Sleep Timer Mode
Selecting Sleep Timer Mode 1. Pressing the MODE key will put the printer in Mode Select mode. 2. Press + or – to select Others >. 3. Press the 4. Press the + key several times to display >Sleep timer and press the ENTER key. A cursor 5.
Page 99: Selecting Dump Received Data Mode
2.8. Dumping Received Data 2.8. Dumping Received Data It is possible to print data received by the printer as hexadecimal code for the purposes of debugging programs and files. Selecting Dump Received Data Mode 1. Pressing the MODE key will put the printer in Mode Select mode.
Page 100: Kir Level
2.9. KIR Level This printer incorporates the KIR (Kyocera Image Refinement) smoothing function. KIR provides high quality printing by providing a software-type improvement to the resolution. Print a status page to find out the current printing mode. Notes Set the print density to 03 when setting the KIR mode. For details on print density, see page 2-37.
Page 101 Optimized stripes Dark vertical stripes White vertical stripes 2-32 Status page KIR Checking Lines KIR Setting The current KIR setting is optimal. The KIR mode currently set is too strong. Set the KIR mode to Off. Try printing the test pattern again. If you still get dark vertical stripes, adjust the print density control to a lighter setting.
Page 102: Selecting Kir Mode
Selecting KIR Mode 1. Pressing the MODE key will put the printer in Mode Select mode. 2. Press + or – to select Others >. 3. Press the 4. Press the + or – key to display >KIR mode and then press the ENTER key. A ? will flash and 5.
Page 103: Selecting Ecoprint Mode
Note The Ecoprint setting has no effect on the print speed. Selecting Ecoprint Mode 1. Pressing the MODE key will put the printer in Mode Select mode. 2. Press + or – to select Others >. 3. Press the 4. Press the + or – key to display >Ecoprint mode and then press the ENTER key. A ? will 5.
Page 104: Resource Protection
HP LaserJet 5M to another or vice versa. Note The printer requires 10 MB or more of memory in order to set resource protection. (14 MB or more is required when a DU-25 duplexer is installed.) >Resource prot.
Page 105: Selecting Resource Protection Mode
2.11. Resource Protection Selecting Resource Protection Mode 1. Pressing the MODE key will put the printer in Mode Select mode. 2. Press + or – to select Others >. 3. Press the 4. Press the + or – key to display >Resource prot. and then press the ENTER key. A ? will 5.
Page 106: Selecting Print Density Mode
When using the KIR function, please use the “ 03 ” setting. For details on adjusting the KIR mode, see page 2-31. Selecting Print Density Mode 1. Pressing the MODE key will put the printer in Mode Select mode. 2. Press + or – to select Others >. 3. Press the 4.
Page 107: Setting The Audio Warning (Buzzer)
The audio alarm is set to On when leaving the factory. If the alarm is turned Off, the buzzer will sound according to the type of printer error as given in the following table.
Page 108 Add paper *: These error messages are displayed if the relevant option is fitted. ##: The number displayed will vary depending on the error. Please refer to Chapter 5. Chapter 2 Operating the Laser Printer Alarm Frequency Remark short beeps —...
Page 109: Selecting Buzzer Mode
After the audio alarm has been set to Off, even if the PRESCRIBE IIe FRPO INIT command is executed, the printer will not return to the initial (On) alarm setting. To set the audio alarm to On, reset using the mode select menu from the control panel.
Page 110: Inserting Memory Cards
It is possible to set the partitions on the memory card which you wish to execute for the printer at power-on by using the PRESCRIBE FRPO I0 command. For details on the FRPO command, see Appendix C.
Page 111: Operating A Memory Card
Follow the precautions below when handling memory cards. Operating a Memory Card The following operations on memory cards inserted into the printer’s memory card slots are possible. 2-42 Memory cards are sensitive to static electricity. Before handling a memory card, be sure to eliminate any static electricity which may have built up on your body or clothing by touching a metallic object.
Page 112: Reading Fonts From A Memory Card
Each operation is described below. Reading Fonts from a Memory Card Fonts can be read into the printer’s internal memory from optional font cards. The font read can then be selected from the printer’s control panel. Font cards are automatically read into the printer when the printer’s power is turned on.
Page 113: Reading Macros From A Memory Card
If the name of a macro on the memory card is the same as that in printer memory, the macro data on the memory card with the conflicting name will not be registered.
Page 114: Reading Data (Partitions) From A Memory Card
Press the CANCEL key to stop reading data. appear in the message display and the selected data will be read into the printer. After data has been read, the message display will return to Ready.
Page 115: Writing Data (Partitions) To A Memory Card
Data sent from the computer can be written on a memory card. Data written on the card can be read into printer memory by key operations from the control panel of the printer. Assuming the card has enough memory capacity, up to 127 partitions can be written on a single card.
Page 116 5. Press the FORM FEED key. The printer will automatically print the data just written (example below). This printout can be used to check the name (partition name) under which data was written and confirm that it was written properly.
Page 117: Deleting Data From A Memory Card
4. Press ENTER key while the data name you wish to delete is shown. The message display will The message display will return to Ready. Formatting Memory Cards It is necessary to first format a new memory card before it can be used by the printer. Formatted memory cards can then be written with data. Notes 2-48 memory card contains data.
Page 118 3. Pressing the ENTER key again will cause Processing to appear in the message display and the memory card will be formatted. The printer will print memory card formatting information (example below) after initialization is finished. Use this to check that the memory card has been formatted properly.
Page 119: Printing A List Of Data Names (Partitions)
2.14. Memory Cards Printing a List of Data Names (Partitions) This operation prints the contents (data names, data size, etc.) of the memory card inserted in the memory card slot. 1. Bring up the menu >List of Partitions on the message display. 2.
Page 120: Chapter 3 Fonts
Chapter 3 Fonts Chapter 3 Fonts This chapter describes the types of fonts you can use with the printer, including the printer’s resident fonts, and symbol sets. 3.1. Resident Fonts ... 3-2 3.2. List of Fonts ... 3-3 3.3. Symbol set ... 3-8...
Page 121: Scalable Fonts
The printer provides three types of resident fonts: bitmap fonts, scalable (outline) fonts, and KPDL fonts. Also, fonts may be downloaded to the printer’s memory from a memory card or disk. These fonts are referred to as downloadable or soft fonts . The printer accepts as many downloadable fonts as its user available memory permits.
Page 122: Kpdl Fonts
3.2. List of Fonts This section contains a full list of the printer’s resident fonts. You can print the same font list from the printer by using the printer’s control panel key. To print a list of fonts, refer to Mode Select Menu , List of Resident fonts .
Page 123: Resident Scalable Fonts
3.2. List of Fonts Resident Scalable Fonts (1)
Page 124 Chapter 3 Fonts Resident Scalable Fonts (2)
Page 125 List of Fonts KPDL Fonts (1)
Page 126 Chapter 3 Fonts KPDL Fonts (2)
Page 127: Symbol Set
Each character is assigned to a particular character code. The page printer offers not only a large selection of bitmap and scalable fonts but also a large selection of symbol sets (also referred to as character sets). This is because the printers the Kyocera page printer emulates have a number of their own symbol sets for printing in different languages and other purposes.
Page 128 Table 3.1. Bitmap Fonts Symbol sets SSET value SSET ID ISO-60 Norway ISO-15 Italian ECMA-94 Latin 1 ISO-11 Sweden ISO-6 ASCII ISO-4 U.K. ISO-69 France ISO-21 Germany US Legal ISO-17 Spain HP Roman-8 IBM PC-8 IBM PC-8 (D/N) IBM PC-850 Chapter 3 Fonts Symbol set...
Page 129 3.3. Symbol Set Table 3.2. Scalable Fonts Symbol sets 3-10 SSET value SSET ID ISO-60 Norway ISO-15 Italian ECMA-94 Latin 1 ISO-11 Sweden ISO-6 ASCII ISO-4 U.K. ISO-69 France ISO-21 Germany US Legal ISO Latin 2 ISO-17 Spain PS math ISO Latin 5 Windows Latin 5 MS publishing...
Page 130 SSET value SSET ID Math 8 HP Roman-8 Windows Latin 2 PC-1004 PC-Turkish Windows PS text IBM PC-8 IBM PC-8 (D/N) Macintosh IBM PC-850 Pi font PC-852 Latin 2 Winbalt Windows Latin 1 PC-775 Chapter 3 Fonts Symbol set 3-11...
Page 131: Chapter 4 Maintenance
This printer is designed to provide years of trouble-free service without the necessity of printer module replacement. However, you must replace the toner container in the printer with a replacement container from a new toner kit. Also, to ensure good print quality, various parts inside the printer must be cleaned at regular intervals.
Page 132: Toner Kit Replacement
* Turning the Ecoprint mode ON conserves toner. Refer to Chapter 2 for details. ** In the case of a new printer in which a toner kit has been installed for the first time, the number of pages that can be printed will be 5,000 or less.
Page 133: Toner Kit To Be Used
Also be sure to replace the waste toner bottle when replacing the toner containter. After toner kit replacement, be sure to clean the inside of the printer. For details, refer to 4.2. Do not leave floppy disks etc. lying around while performing this maintenance procedure. This procedure tends to raise a little toner dust which can harm magnetic recording media.
Page 134 2. Press the toner container release lever (Green) to release the old toner container from the Note Keep the toner container as level as possible while removing. Old Toner Container printer. Remove the old toner container as gently as possible. Toner Container Release Lever (Green)
Page 135 3. Put the old toner container in the plastic bag supplied with the toner kit. Dispose of the toner container. Note The old toner container may be incinerated without the risk of generating harmful gas. Plastic Bag 4. Take the new toner container from its bag. With the label side down, thoroughly shake the toner container (in the direction of the arrow) ten times or more to loosen and mix the toner inside.
Page 136 4.1. Toner Kit Replacement 5. The bottom of the toner container is sealed with a plastic strip. Carefully pull the sealing strip off 6. Install the toner container on the developer as shown in the diagram. Note Be sure to peel off the seal on the toner container before installing the toner container on the developer unit.
Page 137 8. Close the top cover as shown below. Note It is necessary to clean the inside of the printer after replacing the toner container. If the toner container is replaced when the message Replace Toner Clean printer is displayed, the message Clean printer Press CONTINUE will be displayed after replacement.
Page 138: Replace The Waste Toner Bottle
4.1. Toner Kit Replacement Replace the Waste Toner Bottle Note When replacing the toner container, the used waste toner bottle in the printer should also be replaced with a new one from the new toner kit. 1. Open the printer side cover.
Page 139 Chapter 4 Maintenance 3. Cap the waste toner bottle after removing from the printer. Old Waste Toner Bottle 4. To avoid toner spilling, place the capped waste toner bottle in the plastic bag supplied before forwarding to proper disposal. Old Waste Toner Bottle...
Page 140 4.1. Toner Kit Replacement 5. Locate the new waste toner bottle in the toner kit, and install in the printer as shown below. New Waste Toner Bottle 6. After ensuring that the bottle is correctly installed, close the side cover.
Page 141: Cleaning
In addition to the maintenance procedures described on the following pages, the charger wire in the drum unit and paper feed unit should be cleaned from time to time, or whenever print quality problems occur. To avoid print quality problems, the following printer parts must be cleaned with every toner container replacement. Note...
Page 142 4.2. Cleaning 2. Pull the cleaning knob (Green) slowly in and out a few times. This pulls a cleaning pad inside Cleaning the Grid Clean the grid at the time of toner kit replacement. 1. Take the grid cleaner from protective bag in the new toner kit, and remove the cap. Note The grid cleaner pad is impregnated with water.
Page 143 2. Attach the grid cleaner to the printer with the pad uppermost, as shown in the diagram. 3. After attaching the grid cleaner, repeat the action of slowly pulling out and then pushing back in the main charger unit at least 5 times. It is easier to pull out the main charger for the first time if it is raised slightly, as shown in the figure.
Page 144: Paper Feed Unit
4.2. Cleaning 4. When the grid is clean, remove the grid cleaner from the printer and dispose of it. The grid 5. After cleaning the charger wire and grid, push the cleaning knob all the way in and close the...
Page 145 2. Use the supplied cleaning brush to clean the entire length of the saw-toothed separator located behind the transfer roller two or three times. Store the cleaning brush somewhere safe as it will be required again in the future. Transfer Roller Paper Feed Unit 3.
Page 146: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Chapter 5 Troubleshooting This chapter explains how to handle printer problems which may or may not occur. The procedures are easy to follow. If a problem persists after you have completed the appropriate troubleshooting procedures, call for the assistance of a service person.
Page 147: General Guide
If the printing is abnormal With the printer on-line and ready, press the STATUS key to print a status page. You can also optimize print quality using the KIR test pattern printed at the bottom of the status page. To adjust the print status, see Chapter 2.
Page 148: Power Problems
Chapter 5 Troubleshooting 5.2. Power Problems Note The printer power rating must be within the voltage range in your country. If in doubt, consult your dealer. If nothing happens when you switch the printer’s power on, you have a power problem. The symptoms are a dark control panel, no printing, and no fan sound.
Page 149: Interface Problems
5.3. Interface Problems 5.3. Interface Problems If the printer prints a status page correctly but does not print data from the computer correctly (or at all), there may be an interface problem. Check the interface (network) cable. Make sure the cable is plugged in securely at both ends.
Page 150: Print Quality Problems
Completely blank printout Check the developer unit. Open the printer top cover and check that the developer unit is inserted correctly and check that the developer’s connector is connected properly. Call for the assistance of a service person. All-black printout Check the Main Charger Unit Open the printer side cover and check that the main charger unit is correctly installed.
Page 151: Black Or White Vertical Streaks
5.4. Print Quality Problems Dropouts, horizontal streaks, stray dots Clean the charger wire. Open the printer side cover. Pull the green main charger wire cleaning knob slowly in and out a few times. See Section 4.2. Note the spacing of the defects.
Page 152: Faint Or Blurred Printing
The image is smeared Clean the charger wire Open the printer’s side cover. Pull the green main charger wire cleaning knob slowly in and out a few times. See Section 4.2. Faint or blurred printing Check the control panel. If the Toner low TK-20 Clean printer message is displayed and the install a new toner kit.
Page 153: Grey Background
Display the print density menu from the control panel and select a lighter density setting. See Section 2.12. Clean the main charger wire. Open the printer’s side cover. Pull the green main charger wire cleaning knob slowly in and out a few times. See Section 4.2. Check the main charger unit installation.
Page 154: Dirt On The Top Edge Or Back Of The Paper
Dirt on the top edge or back of the paper Check the paper chute and the ramp. Draw out the paper feed unit and check for toner on the paper ramp. Clean the paper ramp (see Section 4.2.) using the wiper supplied, or a soft, dry, lint-free cloth. Check the transfer roller.
Page 155: Indicators And Messages
Table 5.1 Symbolic Indicators 5-10 Indicator Condition • The printer has run low on toner. The toner should be Flashing replaced as soon as possible. See Section 4.2. • The toner is being replenished. Please wait. Install a new toner kit. See Section 4.1. (Toner Empty) There is a paper jam.
Page 156: Maintenance Messages
Maintenance Messages Table 5.2 Maintenance Messages Message Top cover Open the top cover, then close tightly. Open Side cover Open the side cover, then close tightly. Open Paper feed unit Open the paper feed unit, then close tightly. Open Face-down tray The face-down tray has become full.
Page 157 This message is displayed when the optional harddisk unit is accidentally installed into the OPT1 slot. Be sure to install the harddisk unit in the OPT2 slot. Be sure to turn off the printer’s power before removing the incorrectly installed harddisk.
Page 158 Call service Mechanical error (n=0, 1, 2, ...)-Call a service person. The personEn:0123456 printer does not operate when a message beginning with E is displayed. The total number of pages printed is also indicated. Call service Controller error (n=0, 1, 2, ...)-Call a service person. The...
Page 159: Error Messages
RAM). Press the CONTINUE key to resume printing. You can abandon printing by the CANCEL key. The data transferred to the printer was too complex to print on a Print overrun page. Press the CONTINUE key to resume printing. (The page Press CONTINUE may break in some pages.) You can abandon printing by the...
Page 160 MEMORY CARD again message was displayed. Remove the wrong memory card from the printer’s memory card slot and insert the correct memory card. The printer again reads it from the beginning of the data. Format error This message appears when the printer is in the ready state and...
Page 161 Check the data names on the memory card. 02: No memory card is installed in printer. Or, the memory card installed has a specification not supported by this printer. Be sure to install a memory card supported by this printer. See Section 2.14.
Page 162 Try deleting unnecessary Failed fonts and macros. This message is displayed when you attempt to use the printer’s I/F occupied control panel to change the environmental settings on the interface from which data are presently being received.
Page 163 Flashing FIT extinguishes automati- cally when the job times out; the printer receives the next data from the host computer; or if you press any key on the printer’s control panel. Try adding more memory in the printer to prevent this error.
Page 164: Correcting A Paper Jam
If paper is partially fed out into the tray, pull the paper out the rest Check the face-down output tray. of the way by hand, then open and close the printer’s top cover or the paper feed unit. Check the inside of the Open the printer’s rear cover.
Page 165 When pulling the paper, pull it gently so as not to tear it. Torn pieces of paper are difficult to remove and may be easily overlooked, deterring the jam recovery. The fuser unit inside the printer is hot. Do not touch it with your hands as it may result in burn injury. Remove jammed paper carefully.
Page 166 Chapter 5 Troubleshooting Paper Feed Unit Figure 5.3. Paper Cassette Figure 5.4. Registration Roller 5-21...
Page 167 5.6. Correcting a Paper Jam If you cannot find a paper jam by pulling out the paper feed unit and paper cassette as shown in Figures 5.2 through 5.4 on the previous pages, try checking inside the rear of the printer as shown below.
Page 168: Chapter 6 Symbol Set Tables
Symbol Set Tables Chapter 6 Chapter 6 Symbol Set Tables The following tables show all the characters included in the most common symbol sets available with the five emulations. 6.1. HP LaserJet 5M Symbol Sets ... 6-2...
Page 169: Hp Laserjet 5M Symbol Sets
6.1. HP LaserJet 5M Symbol Sets 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M HP Roman-8 (8U) LaserJet 5M ECMA-94 Latin 1 (0N)
Page 170 Symbol Set Tables Chapter 6 LaserJet 5M US Legal (1U) LaserJet 5M IBM PC-8 (10U) To have the printer print the characters of decimal numbers of 7 through 15, and 27, set the printer to the HP PCL transparent mode (ESC&p#X).
Page 171 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M IBM PC-8 (D/N) (11U) To have the printer print the characters of decimal numbers of 7 through 15, and 27, set the printer to the HP PCL transparent mode (ESC&p#X). LaserJet 5M IBM PC-850 (12U)
Page 172 Symbol Set Tables Chapter 6 LaserJet 5M Dutch801-RomanSWM (6N) LaserJet 5M PS Math (5M)
Page 173 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M PS Text (10J) LaserJet 5M Math8 (8M)
Page 174 Symbol Set Tables Chapter 6 LaserJet 5M Pi Font (15U) LaserJet 5M MS publishing (6J)
Page 175 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M Windows (9U) LaserJet 5M Desktop (7J)
Page 176 Symbol Set Tables Chapter 6 LaserJet 5M ISO Latin 2 (2N) LaserJet 5M ISO Latin 5 (5N)
Page 177 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M Dutch801-RomanSWM (19L) LaserJet 5M Dutch801-RomanSWM (26U) 6-10...
Page 178 Symbol Set Tables Chapter 6 LaserJet 5M Dutch801-RomanSWM (9J) LaserJet 5M Windows Latin 1 (19U) 6-11...
Page 179 6.1. HP LaserJet 5M Symbol Sets LaserJet 5M Windows Latin 2 (9E) LaserJet 5M Windows Latin 5 (5T) 6-12...
Page 180 Symbol Set Tables Chapter 6 LaserJet 5M PC-852 Latin 2 (17U) LaserJet 5M PC-Turkish (9T) 6-13...
Page 181 6.1. HP LaserJet 5M Symbol Sets Macintosh (12J) 6-14...
Page 182 LaserJet 5M International Characters ISO-6 US ASCII £ ISO-4 UK £ à ISO-69 French § ISO-21 German £ § ISO-15 Italian ¤ É ISO-11Swedish names £ § ISO-17 Spanish ISO-60 Norwegian v1 Symbol Set Tables Chapter 6 ‘ ç § é...
Page 183: Appendix A Printer Specifications
Appendix A Printer Specifications Appendix A Printer Specifications A.1. Printer Specifications ...A-2...
Page 184: A.1. Printer Specifications
A.1. Printer Specifications A.1.Printer Specifications Item Printing method Electrophotography, laser scan. Printing speed 20 pages/minute (A4 or letter-size paper, landscape feed) (when printing multiple 12.5 pages/minute (B4-size paper) copies of the same page) 11 pages/minute (A3-size paper) Resolution 2400 dpi equiv.
Page 185 Max. 51 dB (A) when printing (excl. peak values) Max. 38 dB (A) when idling Immeasurably low when sleeping (Measured at 1 m from the outside of the printer, main unit only) Dimensions 483 mm (19.0") wide (550 mm with paper cassette mounted) Weight 21 kg (46 lb.), main unit only...
Page 186: Appendix B Paper Selection
Paper Selection Appendix B Appendix B Paper Selection B.1. General Guidelines ... B- 2 B.2. Selecting the Right Paper ... B- 4 B.3. Special Paper ... B-10...
Page 187: B.1. General Guidelines
Before purchasing recycled paper, test a sample on the printer and check that printing quality is satisfactory. Be sure to select a brand of recycled paper which offers good printing quality and does not contain excessive levels of paper dust.
Page 188: Paper Specifications
Kyocera bears absolutely no responsibility for accidents resulting from the use of inappropriate paper which does not meet the specifications listed above. For paper, contact the licensed dealer of Kyocera from which you purchased the printer. 60 to 90 g/m (16 to 24 lbs./ream)
Page 189: B.2. Selecting The Right Paper
Use of paper in these conditions can lead to illegible printing, misfeeding, and paper jams, and can shorten the life of the printer. Select paper which has as smooth and even a surface as possible. Note that use of paper with a surface coating or other surface treatment may damage the drum or fuser unit.
Page 190: Paper Size
Paper Size Cassettes and the multi-purpose tray can handle the paper sizes listed in the following table. The printer automatically detects the paper size loaded in a cassette. Table B.2. Paper Sizes for Paper Feeding Paper ISO A3 ISO A4...
Page 191: Basis Weight
60 to 90 g/m Thickness The paper used with the printer should be neither extremely thick nor extremely thin. If you are having problems with multiple feeds and paper jams, the paper may be too thin. The paper may also be too thick if you are having problems with paper jams.
Page 192: Moisture Content
Moisture Content Moisture content is defined as the percent ratio of moisture to the dry mass of the paper. Moisture can affect feedability, electrostatic properties, and toner fusing characteristics. The moisture content of the paper varies with the relative humidity in the room. When the relative humidity is high and the paper absorbs moisture, the paper edges expand, becoming wavy in appearance.
Page 193 B.2. Selecting the Right Paper Stiffness Paper that is too limp or too stiff may fold or bend inside the printer, resulting in a paper jam. Curl Most paper has a natural tendency to curl in one direction or the other if it is stored unwrapped.
Page 194 We recommend that you avoid using paper listed below which has been specially treated, even if it meets basic specifications. If you wish to use such paper, test a sample on the printer and check that printing quality is satisfactory before purchasing.
Page 195: B.3. Special Paper
Since the composition and quality of special paper vary considerably, special paper is more likely than white bond paper to give trouble during printing. Special paper may be used with this printer if it meets the following conditions. Note that these types of paper differ greatly in their construction and quality, resulting in an increased chance of problems occurring during printing.
Page 196: Colored Paper
OHP film must be able to withstand the heat of fusing during the printing process. Specifications are as follows. Note Note that use of OHP film which does not meet these conditions may result in damage to the printer. Table B.3. OHP Film Specifications Item Tolerance of heat Must be able to withstand a temperature of at least 190 C.
Page 197 Envelopes which are particularly thick may wrinkle as they come out of the printer. Test a sample envelope on the printer and check that printing quality is satisfactory before purchasing.
Page 198 The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the printer. Adhesive paper sticking to the drum or rollers will damage the printer. Label paper must be manually fed.
Page 199 B.3. Special Paper Table B.4 lists the specifications for adhesive label paper. Table B.4 Adhesive Label Specifications Note Printing quality and possible trouble when printing labels are entirely the responsibility of the user. B-14 Item Weight of top sheet 44 to 74 g/m Composite weight 104 to 151 g/m Thickness of top sheet...
Page 200 Host Computer Interface This appendix describes the signals used in the laser printer’s parallel, RS-232C/RS-422A interfaces. It also lists pin assignments, signal functions, timings, connector specifications, and voltage levels. The RS-232C/RS-422A protocols are also covered. Finally, it explains the use of the printer in a multi-computer environment.
Page 201: C.1. Parallel Interface
C.1. Parallel Interface C.1.Parallel Interface Parallel interface communication modes The printer features the fast data transmission on the parallel interface. The parallel interface mode can be activated from the printer’s control panel (see Chapter 2) as follows: Note Use a parallel printer cable that complies with the IEEE1284 standards.
Page 202: Interface Signals
The pins of the parallel interface connector carry the signals listed in Table C.1. Asterisks in the table indicate signals that are active low. The table also indicates whether each signal is incoming or outgoing with respect to the printer. Table C.1. Parallel Connector Pin Assignments...
Page 203 [ ]: Signal names in the Auto mode (IEEE 1284). In the Auto mode, these signals are bi-directional. Detailed descriptions of the signals follow. Strobe* [nStrobe] (Pin 1) A negative-going Strobe* pulse causes the printer to read and latch the data on the Data 0 [1] to Data 7 [8] signal lines. In/out —...
Page 204: Appendix C Host Computer Interface
Appendix C Data 0 [1] to Data 7 [8] (Pins 2 to 9) These eight signals form the data byte sent from the host computer to the printer. Data 7 [8] is the most significant bit. Acknowledge* [nAck] (Pin 10) This negative-going pulse acknowledges the previous character received by the printer.
Page 205 C.1. Parallel Interface +5V DC (Pin 18) This line is connected to the printer’s +5V DC line (+5V 0.5V, 250 mA [Serial and Parallel total] maximum, fused). Prime [nInit] (Pin 31) This signal is used in the standard Centronics interface to enable the computer to reset the printer.
Page 206: C.2. Serial (Rs-232C/Rs-422A) Interface
FG - Frame Ground - (Pin 1) This pin is connected directly to the printer frame. TXD - Transmit Data - (Pin 2) This output carries asynchronous data sent by the printer to the computer. It is used mainly in handshaking protocols. In/out Signal —...
Page 207 All signals can transmit between the printer and the host computer to send each signals with a signal ground. +5V DC - (Pin 11) This line is connected to the printer’s +5V DC line (+5V 0.5V, 250 mA [Parallel and Serial total] maximum, fused). DTR - Data Terminal Ready - (Pin 20) This output is used as a buffer nearly-full handshake line.
Page 208 RS-422A interface The serial interface of this printer was set to RS-232C mode before leaving the factory. However, by changing the jumper connector on the main circuit board, the interface can be changed to RS-422A mode. Note The changing of the main circuit board jumper connector should be carried out only by a Kyocera authorized dealer or Kyocera certified technician.
Page 209: Serial (Rs-232C/Rs-422A) Interface
Withdrawing the Main Circuit Board from the Printer Note Be sure to remove the memory card first if inserted in the printer’s memory card slot. Withdraw the main circuit board completely from the printer as follows: 1. Turn the printer’s power off. Unplug the printer’s power cable and disconnect the printer from 2.
Page 210 3. Pull the main circuit board all the way out of the printer. Note Before pulling the main board out, clean an area on the table, etc., at the back of the printer’s rear panel. Foreign objects, accidentally sticking to the back of the main board, can cause serious damage to the printer.
Page 211: Verifying The Setting
Print the service status page to verify that the RS-422A mode has been correctly set. 1. Make sure the power switch is off. Plug the power cord into the printer and turn power on. 2. If the printer is on-line, select >>Print Status page in the Mode Select menu (refer to 3.
Page 212 These pins carry asynchronous data sent from the printer to the computer. (differential output) +5V DC (Pin 11) This line is connected to the printer’s +5V DC line (+5V 0.5V, 250 mA [Parallel and Serial total] maximum, fused). RS-422A interface voltage levels The interface signal voltage levels conform with the EIA RS-422A standard.
Page 213: Rs-232C/Rs-422A Protocol
C.3. RS-232C/RS-422A Protocol C.3.RS-232C/RS-422A Protocol A protocol is a set of rules the computer follows in sending data to the printer. The RS-232C/RS- 422A parameters are stored in battery backed-up memory. They are indicated on the status printout. They can be changed by the FRPO (firmware reprogram) command described in the Programming Manual .
Page 214 H4: Parity Parameter value Meaning None Even Ignore The factory setting is “None” (0 on the status printout). H5: Protocol logic Parameter value Combination of 1 and 3 below DTR/DSR, positive logic DTR/DSR, negative logic XON/XOFF ETX/ACK XON/XOFF recognized only as protocol The factory setting is 0.
Page 215: Prescribe Iie Frpo D0 Command
C.3. RS-232C/RS-422A Protocol H7: Buffer nearly-empty threshold This is a percentage from 0 to 99. The factory setting is 70. The factory settings of the buffer nearly-full and nearly-empty thresholds (H6 and H7) are subject to change without notification. The gap between the nearly-full and nearly-empty thresholds allows the computer to send a fairly large amount of data in a continuous stream.
Page 216: C.4. Rs-232C Cable Connection
Appendix C. If you have an IBM communication adapter cable type 1502067, you will have to resolder the wiring at the printer end of the cable. The procedure is as follows. 1. Unscrew the plastic cover from the printer end of the cable.
Page 217: Connecting The Printer To The Computer
The two RS-232C protocols are XON/XOFF and DTR. The printer performs both of them simultaneously, using positive logic for DTR. If you are uncertain as to the printer’s current parameter settings, you can reset them to the values listed above by following the manner described in the last page in this manual.
Page 218 8. Set the computer to the same parameters as the printer. On many computers this can be done by setting DIP switches before power is turned on. Another method is as follows: In DOS, enter the following commands: C>MODE COM1:96,N,8,1,P C>MODE LPT1:=COM1...
Page 219: Index
Index ATTENTION indicator ... 2-5 Bitmap fonts ... 3-2 Buzzer ... 2-38 CANCEL key ... 2-7 Cap ... 1-14, 4-9 Cassette mode ... 1-35 CD-ROM ... 1-6, 1-28 Charger wire ... 4-11, 5-6 Cleaning brush ... 4-15 Cleaning knob ... 4-12 Cleaning ...
Page 220 Parallel interface ... 2-4, 2-24, C-2 Partitions ... 2-45 Places to avoid ... 1-3 Plastic bag ... 4-3 Positioning the printer ... 1-2 Power cord ... 1-6, 1-26 Power supply ... 1-5 Power switch ... 2-10, 2-12 Print density ... 2-31, 2-37 Print quality problem ...
Page 221 Reduction ... 2-26 Registration roller ... 4-15 Resolution indicator... 2-4 Resource protection ... 2-35 Right paper ... B-4 RS-232C interface ... C-7 RS-422A interface ... C-9 Scalable fonts ... 3-2 Separator ... 4-15 Serial interface ... 2-4, C-7 Serial interface connector ... 1-24, C-13 Setting Up and interfacing ...
Page 222: Mode Select Menu
Emulation > >KC-GL KC-GL Pen width >KC-GL Page set [SPSZ] Continued on next page These items willl not show unless the printer is installed with the applicable option unit/kit. >Baud rate 9600 >Data bits >Stop bits >Parity None >Protocol DTR (pos.)&XON >Barcode mode...
Page 223 This timeout setting can be set in 5- second increments up to 495 seconds. * 7: This is the total number of pages printed by the printer up to the present time. * 8: Although Auto is the default setting and...
Page 224 (Continued from previous page) >Number of pages (* 7 ) printed 012345 >KIR mode >Ecoprint mode (* 8) >Page protect Auto (*9) >Resolution 600 dpi 300 dpi >Resource prot. Permanent Perm / Temp >Print density >Buzzer >Service > (* 10 ) >>Print Status Page >>Developer...

Kyocera FS-6700 User Manual

Chapter 1 Installing the Printer

Chapter 2 Operating the Laser Printer

Chapter 3 Fonts

Chapter 4 Maintenance

Chapter 5 Troubleshooting

Chapter 6 Symbol Set Tables

Appendix A Printer Specifications

Appendix B Paper Selection

Appendix C Host Computer Interface

Index

Mode Select Menu

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kyocera FS-6700

Summary of Contents for Kyocera FS-6700
